- Page 1 Liteway 3 & 4 Plus Scooters Owners Manual & Service Record Liteway 4 Plus Liteway 3 Plus Electric Mobility Euro Limited, Canal Way, Ilminster , Somerset T 19 9DL Telephone: 01460 258100 www.electricmobility.co.uk Issue 1: 06/09...
- Page 2 Liteway 4 Plus Liteway 3 Plus Electric Mobility Euro Ltd offers these lightweight, manoeuvrable scooters for convenient indoor and outdoor use. They can be easily and quickly dismantled for transporting in the boot of a car. So long as your scooter is maintained and operated in accordance with this manual it should last for many years, and provide you with freedom and independence.
-
Page 3: Table Of Contents
Servicing & maintenance Diagnostic Table Troubleshooting guide Frequently asked questions Engineers checklist Guarantee & Warranty Technical information regarding EMI Technical specification - Liteway 3 Plus Technical specification - Liteway 4 Plus Brochure request Warranty Card - dealer information Service log... -
Page 4: Dealer Information
Canal Way, Ilminster, Somerset T 19 9DL Company Registration in England No. 2419231 Features and Layout Photo shows Liteway 4 Plus model scooter. The Liteway 3 Plus is a 3 wheel version. See the specification for differences. Fold down backrest... -
Page 5: Safety Information
3-wheeled scooters are more manoeuvrable, but marginally less stable, than equivalent 4-wheeled models. In fact, the Liteway 3 has two small front wheels close together to improve stability. However, the Liteway 3 plus is designed for use where stability is less important than manoeuvrability, for instance when used in the home. The Liteway 4 Plus is a 4 mph pavement scooter which can be rapidly taken apart for stowage in a car boot. -
Page 6: Safety Information
Safety Information General Warnings Warning ! The operation of scooters can endanger the life of the driver or third parties. ny driver should always be fully capable of operating this vehicle safely. Warning ! Sitting for long periods may increase the chance of thromboses or pressure sores. Users prone to such conditions are advised to take medical advice. - Page 7 Warning ! rmrests Do not use armrests as a support when getting in or out of your scooter. Make sure they are lowered and secure before your start off otherwise you might fall out. Warning ! Slopes On steep slopes the scooter could topple over. Never exceed the Maximum Safe Slope in the Technical Specification Sheet.
-
Page 8: Controls - Dashboard
Controls - Dashboard Before driving your vehicle it is important to familiarise yourself with the controls. Do not attempt to drive the vehicle before reading the rest of this Handbook. Dashboard Description 1. Battery Indicator: This instrument shows the level of charge in the batteries. When in the green area the batteries are fully charged. -
Page 9: Controls - Driving Controls/ Ccelerator
Controls – Driving controls/ ccelerator Finger control. To operate, turn on the ignition. Pull the right hand lever towards you and the machine moves forward. The more you pull the lever the faster the scooter goes. To brake, release the lever. gain the faster the lever is released the quicker you will stop. To reverse, pull the left lever towards you. -
Page 10: Rmrest Adjustment
rmrest adjustment When getting seated on the scooter lift the armrest up. When riding always have the armrest in the down position. void pinching fingers as you lower the armrest. If you require more room in the width of the seat undo the knobs at the rear of the seat. Slide the armrests in or out to suit. Tighten both knobs to clamp. -
Page 11: Driving The Vehicle
• Rotate the knurled knob clock- wise and ensure that it is tight and the retaining serrations are fully engaged • djust the tiller to suit your driving position, ensuring the tiller is firmly locked in place before driving off. Warning! Before driving, always check that the tiller is securely in the upright position. -
Page 12: Driving The Vehicle - Hazards
Driving the vehicle - hazards Warning! Before driving the scooter you should be aware that, under certain circumstances it could become unstable and tip over. Your scooter has been designed to operate on paved, even surfaces and should not be used on rough or rutted terrain. Do not exceed the maximum safe slope recorded in the Technical Specifications. -
Page 13: Transporting Your Scooter
Transporting your Scooter Warning! Dismantling the scooter involves lifting and handling heavy parts. Weights are given in the Technical Specification; consider if you need help in handling parts before you try to lift them. The Liteway 3 & 4 Plus have been specially designed to be easily dismantled and stowed in a car. Contact your dealer for advice on how best to transport your scooter in your particular vehicle Warning! Pinching or Crushing. -
Page 14: Ssembling Your Scooter
ssembling your Scooter following Transportation Warning! ssembling the scooter involves lifting and handling heavy parts. The Liteway Plus Scooters have been designed to be easily assembled. Your dealer should advise you on the best way to assemble your scooter. Warning! Pinching or Crushing. -
Page 15: Battery Charging
Battery Charging Warning! When charging batteries NEVER smoke, or do this in a place where there are naked flames such as gas-fired heaters as, under exceptional circumstances, batteries may give off gases that could ignite and explode. lways make sure that batteries are not damaged. Warning! When charging batteries NEVER connect or disconnect the charger while it is still connected to the mains. -
Page 16: Dditional Safety Information
The batteries are the lifeblood of your vehicle. Their characteristics can change depending on charging, temperature, usage and other factors. Listed below are guidelines to prolong battery life. fter using your vehicle always charge it at the end of the day even after a short journey. If you do not use your vehicle for a prolonged period, place it on charge once a week, overnight. -
Page 17: User Maintenance
User Maintenance It is important for safety that you carry out the following checks before use. Visually check the machine for damage. Visually check the tyres for damage. Check the steering moves freely. Check that the tiller is secure and that the tiller rotation knob is tight. Check the front chassis is securely attached to the rear chassis and to the transaxle. -
Page 18: Diagnostic Table
Scooter Diagnostic Functions Your Scooter Controller provides diagnostic information in the form of flash-codes. The lamp on the battery indicator flashes to indicate a problem has been detected. On switching on, the controller conducts a diagnostic test. While this test is in progress the lamp will flash and, if no fault is detected it will remain on. If there is a fault, the lamp will flash a sequence of flashes to indicate what the fault is. -
Page 19: Troubleshooting Guide
Troubleshooting Guide This table is a guide to fault finding. The fault may be a simple fix. If you have any doubts phone your dealer. Symptom Solution • Scooter does not move. • Batteries flat - check level. when power is switched on. •... -
Page 20: Frequently Asked Questions
dditional Information Owners Manual: Replacement copies are available from: Electric Mobility Euro Ltd. Canal Way, Ilminster, Somerset, T 19 9DL Telephone: 01460 258100. If you are visually impaired, please contact the Company to discuss your requirements. However, you should not drive a vehicle in a public place if you cannot see well enough to ensure your own, and others safety. Each vehicle comes with a copy of the BHT Highway Code. -
Page 21: Engineers Checklist
Engineer’s Checklist for Liteway 3 & 4 Plus Models Obtain all comments from the customer on the condition and serviceability of the scooter and then complete an Initial diagnostic road test. Record all defects to be corrected. Now check, test and complete the following: •... -
Page 22: Guarantee & Warranty
Mobility Euro Limited. ny description, specifications, samples, models, bulletins or similar materials used in connection with the sales of Electric Mobility Euro Limited products are for the sole purpose of identifying the equipment and are not to be construed as expressed warranties. This limited warranty applies only to the original purchaser of the equipment and is not transferable. -
Page 23: Technical Specification - Liteway 3 Plus
Technical Specification - Liteway 3 Plus Scooter Wheelchair type Class Class , B or C Class B Department of Transport Class Class 1 2 or 3 Class 2 Overall dimensions fully assembled length x width x height mm (in) 1050 (41) x 550 (22) x 930 (37) -
Page 24: Technical Specification - Liteway 4 Plus
Technical Specification - Liteway 4 Plus Scooter Wheelchair type Class Class , B or C Class B Department of Transport Class Class 1 2 or 3 Class 2 Overall dimensions fully assembled length x width x height mm (in) 1050 (41) x 550 (22) x 930 (37) Dimensions seat removed tiller folded length x width x height mm (in) 1050 (41) x 550 (22) x 430 (17) -
Page 25: Brochure Request
Brochure Request Do you have a friend or colleague that would be interested in an Electric Mobility product? If so cut out this coupon and send it to the address shown on the back of the manual. My Dealer’s Company name is: Please can I have a free no-obligation home demonstration. - Page 26 Electric Mobility Euro Ltd., FREEPOST (SWBI 1045), Ilminster, Somerset, T 19 9Z Electric Mobility Euro Ltd., FREEPOST (SWBI 1045), Ilminster, Somerset, T 19 9Z...
-
Page 27: Service Log
Service Log Notice for the Service Engineer. Please make sure this part is stamped and dated after each service. Dealer stamp - 1st Service Dealer stamp - 2nd Service Dealer stamp - 3rd Service Dealer stamp - 4th Service Dealer stamp - 5th Service Dealer stamp - 6th Service Dealer stamp - 7th Service Dealer stamp - 8th Service... - Page 28 Liteway 3 & 4 Plus Scooters Manufactured by Electric Mobility Euro Limited, Canal Way, Ilminster, Somerset T 19 9DL Telephone: 01460 258100 www.electricmobility.co.uk E. and O.E. Issue 1: 06/09...
