Bresser AstroBoy 8841000 Instruction Manual

Instruction Manual
60mm Goto Refractor Telescope

FEATURES

Alt-Azimuth Mount with computer control technology
•
Real-time GOTO and tracking features
•
4,000+ object database with 256 user-definable objects.
•
4 line, 20-character LCD hand controller with backlit LED buttons for easy operation
•
Dual-axis servomotor with optical encoders
•
Drive motor with 5-speed setting for precise tracking
•
Tabletop base
•
60mm achromatic refractor telescope for land and celestial objects observation
•
Also attaches to photo tripods with 6.35 mm (¼") camera screw
•

PACKAGE CONTENTS

Telescope mount
•
60mm Refractor telescope
•
Tabletop base
•
Hand Controller
•

Assembly Terms

1. Telescope Tube
2. Dovetail Lock
3. Hand Controller
4. Altitude Lock
5. Mount
6. Diagonal
7. Eyepiece
8. Tabletop Base
9. HBX Port (Hand controller)
10. On/Off switch
11. DC Power connection
NEVER USE A TELESCOPE TO LOOK AT THE SUN DIRECTLY!
Looking at or near the Sun will cause instant and irreversible damage to your eye.
Children should always have adult supervision while observing.
2
7
6
45º diagonal mirror
•
31.7mm (1.25") H20mm eyepiece
•
Plastic carrying case
•
1
4
5
3
8
9 10 11
