Selecting Power Level - Surefire Powerselect 9AN Commander Manual

SELECTING POWER LEVEL

The 9AN Commander has two seperate lamp
assemblies within the bezel reflector. When
operating on the general use beam of 20 lu-
mens only one lamp assembly is activated. For
the high power 140 lumen beam both lamp
assemblies are activated
For 140 Lumen Beam
While holding the Head of the 9AN, turn the
Body of the 9AN clockwise until it is fully
screwed into the Head. The High Power beam
will be turned on when the Tail Cap switch is
activated.
For 20 Lumen Beam
While holding the Head of the 9AN, turn the
Body clockwise until it is fully screwed into
the Head and then unscrew approximately 1/
4 turn (90 degrees) counterclockwise. The
general use beam will be turned on when the
Tail Cap switch is activated.
