DETAILED OPERATING INSTRUCTIONS
•
Screw the high pressure hose (clockwise) on the back of the unit at the bottom Fig
10. The end of the hose must be inserted into the water outlet far enough so the
collar can thread onto the outlet threads until hand tight. Do not use pliers or vice
grips to tighten. If it takes fewer than six or so turns you have not properly tighte-
ned the high pressure hose fitting. It is easier to position the pressure washer in
front of you so to ensure that the threads are started correctly. Failure to properly
tighten the high pressure hose will result in the hose slipping or popping off im-
mediately upon turning the unit. Do not worry about damage if this occurs - just
reinstall and take extra care at screwing on the high pressure hose fitting.
•
Connect the other end of the high-pressure hose to the gun by inserting the brass
metal tip of the high-pressure hose into the fitting just ahead of the trigger guard.
It will lock into the gun with a "click". Fig 11 Confirm the hose is locked into the
spray gun by pulling slightly on the hose. The hose should be securely installed and
will not come out. To release the hose from the spray gun, press the blue button on
the underside of the gun toward the trigger guard. The hose will slide out from the
connection.
•
Activate the trigger of the gun by aiming the gun away from you and push the lock
from right to left.Fig 12 After doing so, squeeze or pull the trigger to make sure it
is locked and will not move. Get in the habit of leaving the safety lock to "on" when
the pressure washer is not in use. This ensures the gun is in "safe" mode until it is
ready for use.
•
While the spray gun is in the locked position, insert the turbo lance, the adjustable
spray lance, or the detergent bottle directly into the end of the spray gun by inser-
ting and pushing together and turning clockwise simultaneously. To remove push
together and turn counter clockwise. Release trigger when changing lances or the
detergent tank. Fig 13 Push safety button to lock the trigger before removing lance
or detergent tank to ensure that they do not accidentally eject with force during
installation.
•
When using the detergent bottle, fill it with a properly formulated detergent or
cleaner with water ratio according to instructions on the container. Fig 14 The de-
tergent bottle comes with a straw which is pressure fitted to the screw-on top.
Fig.15 If the straw is not there, look inside the bottle and attach it to the screw-on
top. Spray detergent or cleaner from the bottom up on vertical surfaces to prevent
detergent/ cleaner from running down into your stains and/or dirt. Your local har-
dware store will have power washer cleaners for different cleaning projects. The
cleaning solution should be the consistency of water to prevent clogging your de-
tergent bottle and nozzle.
