SDI to HDMI Scaler and Converter
Converts 3G/HD/SD-SDI-and-audio-with-
local-loopout to HDMI digital video (DVI-D)
with analog stereo audio.
Customer
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S.
Support
call 724-746-5500) • FREE technical support 24 hours a day, 7 days
Information
a week: Call 724-746-5500 or fax 724-746-0746 • Mailing address:
Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com • E-mail: info@blackbox.com
AVSC-SDI-HDMI

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AVSC-SDI-HDMI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Black Box AVSC-SDI-HDMI

Summary of Contents for Black Box AVSC-SDI-HDMI

  • Page 1 Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. Support call 724-746-5500) • FREE technical support 24 hours a day, 7 days Information a week: Call 724-746-5500 or fax 724-746-0746 • Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 Web site: www.blackbox.com • E-mail: info@blackbox.com...
  • Page 2 Disclaimer Black Box Network Services shall not be liable for damages of any kind, including, but not limited to, punitive, consequential or cost of cover damages, resulting from any errors in the product information or specifications set forth in this document and Black Box Network Services may revise this document at any time without notice.
  • Page 3 FCC and IC RFI Statements/NOM Statement FEDERAL COMMUNICATIONS COMMISSION AND INDUSTRY CANADA RADIO FREQUENCY INTERFERENCE STATEMENTS This equipment generates, uses, and can radiate radio-frequency energy, and if not installed and used properly, that is, in strict accordance with the manufacturer’s instructions, may cause inter ference to radio communication. It has been tested and found to comply with the limits for a Class A computing device in accordance with the specifications in Subpart B of Part 15 of FCC rules, which are designed to provide reasonable protection against such interference...
  • Page 4 NOM Statement 5. El aparato eléctrico no deberá ser usado cerca del agua — por ejemplo, cerca de la tina de baño, lavabo, sótano mojado o cerca de una alberca, etc. 6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales que sean recomendados por el fabricante.

  • Page 5: Safety Notice

    NOM Statement/Safety Notice 17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean derramados sobre la cubierta u orificios de ventilación. 18. Servicio por personal calificado deberá ser provisto cuando: A: El cable de poder o el contacto ha sido dañado; u B: Objectos han caído o líquido ha sido derramado dentro del aparato;...

  • Page 6: Table Of Contents

    2.1 Introduction ..................9 2.2 Features ..................9 2.3 What’s Included ................9 2.4 Hardware Description ..............10 Connection Diagram ................12 OSD Menu ...................13 Operation .....................15 Troubleshooting .................. 22 6.1 Contacting Black Box ..............22 6.2 Shipping and Packaging............. 22 724-746-5500 | blackbox.com Page 6...

  • Page 7: Specifications

    Chapter 1: Specifications 1. Specifications Approvals CE, FCC Audio Support Stereo PCM (48 kHz only up to 8 channel) CEC Channel Enclosure Metal wall mounting case with screws ESD Protection Human body model: ±19 kV (air-gap discharge) and ±12 kV (contact discharge); Core chipset: ±2 kV Firmware Update via USB Port...
  • Page 8 Chapter 1: Specifications 1. Specifications (continued) Environment Temperature Tolerance: Operating: 32 to 104° F (0 to 40° C); Storage: -4 to +140° F (-20 to +60° C) Relative Humidity: 20–90%, noncondensing Power Power supply: 5 VDC, 2 A; Consumption 5 Watts (max.) Dimensions 1.1"H x 3.6"W x 3.3"D (2.8 x 9.2 x 8.3 cm) Weight...

  • Page 9: Overview

    Scaling allows for changing resolutions to increase quality or improve compatibility. The SDI to HDMI Scaler and Converter (AVSC-SDI-HDMI) converts digital 3D/ HD/SD-SDI to HDMI digital video with analog stereo audio. With this module, 3G/HD/SD-SDI based devices such as Blu-ray disc players, PS3, DVD players, camcorders, or set-top boxes can connect to your PC LCD and PC speakers.

  • Page 10: Hardware Description

    Chapter 2: Overview 2.4 Hardware Description Figures 2-1 and 2-2 show the front and back panels of the scaler. Table 2-1 describes its components. 2 3 4 Figure 2-1. Front panel. Figure 2-2. Back panel. 724-746-5500 | blackbox.com Page 10...
  • Page 11 Chapter 2: Overview Table 2-1. Scaler components. Number Component Description SDI Local Loopout 3G/HD/SD-SDI local loopout DIP switch For firmware update: ON (UP): firmware update mode; OFF (DOWN): normal mode (2) LED indicators (1) Red LED for Power; (1) Green LED for Video Signal IR sensor Used to receive the IR commands from IR remote...

  • Page 12: Connection Diagram

    Chapter 3: Connection Diagram 3. Connection Diagram SDI cable Local monitor with SDI input AVSC-SDI-HDMI Front front (top) and back (bottom) Rear Camera with SDI cable SDI output HDMI cable Stereo audio cable Display with HDMI input Figure 3-1. Typical application.

  • Page 13: Osd Menu

    Chapter 4: OSD Menu 4. OSD Menu Table 4-1. OSD menu. Option Description Settings 1. Output Setup Output Mode RGB; YcbCr444; YcbCr422 Default Pattern Disable (Default); White; Cross; Hatch; Color; Gray; Windows; H-Ramp; W-HRamp; W-VRamp; Diagonal Audio source Stereo; S/PDIF 2.
  • Page 14 Chapter 4: OSD Menu Table 4-1 (continued). OSD menu. Option Description Settings 2. Image Edge Enhance Typ. (Default); (continued) Mid; Max; Sharpness 0–127 3. Adjustment Under/Over Scan -50%–50% (Default Off) Aspect Ratio 16:9 (Default); H-Mirror Off (Default); V-Mirror Off (Default); H-Shift -100–100 (Default 0) V-Shift...

  • Page 15: Operation

    Chapter 5: Operation 5. Operation Method A: Push-in Button See Figure 5-1. Down Up Menu Figure 5-1. Location of push buttons on the scaler. Method B: IR Remote Control Figure 5-2. Remote control. 724-746-5500 | blackbox.com Page 15...
  • Page 16 Chapter 5: Operation Table 5-1. IR remote control functions. Button Function FREEZE Freeze video ASPECT RATIO Aspect ratio change BLANK Blank video EXIT Exit OSD ENTER Enter key Up key LEFT Left key RIGHT Right key DOWN Down key MENU Menu on INPUT INFO Source resolution information...
  • Page 17 Chapter 5: Operation Method C: IR Remote Control through Mini-USB port Figure 5-3. 724-746-5500 | blackbox.com Page 17...
  • Page 18 Chapter 5: Operation Table 5-2. IR remote control through mini-USB port screen functions. Number in Figure 5-3 Function COM Port Selection COM Port Detection Button Output Setup Button Image Button Adjustment Button System Button Input/Output Resolution Info Refresh Input/Output Resolution Info Button Output Quick Selection Button 1.
  • Page 19 Chapter 5: Operation 3. Output Setup Button Figure 5-5. 4. Image Button Figure 5-6. 724-746-5500 | blackbox.com Page 19...
  • Page 20 Chapter 5: Operation 5. Adjustment Button Figure 5-7. 6. System Button Figure 5-8. System screen. 1) In-Sync Info: To view the current input resolution 2) Factory Reset Button 3) Firmware Update Button 724-746-5500 | blackbox.com Page 20...
  • Page 21 Chapter 5: Operation Figure 5-9. Firmware update screen. Follow these steps to update the firmware: STEP A: Unplug the Mini-USB connector from the device. STEP B: Set the DIP switch to ON (UP). STEP C: Connect the device to the PC via a USB to mini-USB cable. STEP D: Click the FW Update button in the software.

  • Page 22: Troubleshooting

    • Package it carefully. We recommend that you use the original container. • If you are returning the unit, make sure you include everything you received with it. Before you ship for return or repair, contact Black Box to get a Return Authorization (RA) number.
  • Page 23 NOTES 724-746-5500 | blackbox.com Page 23...
  • Page 24 Great tech support is just 60 seconds away at 724-746-5500 or blackbox.com. About Black Box Black Box provides an extensive range of networking and infrastructure products. You’ll find everything from cabinets and racks and power and surge protection products to media converters and Ethernet switches all supported by free, live 24/7 Tech support available in 60 seconds or less.
