Page 2
Service Manual G2460PQU Revision List Version Date Revision History TPV Model Name Editors/ Redactor HKCAB568BVA1DNJ Mar-06-2012 Initial release TPV-BJ-Winner HKDAB56BBVA1DNJ...
Service Manual G2460PQU 1. Monitor Specifications 1.1 Product Features Model number G2460PQU Driving system TFT Color LCD 61.0 cm diagonal Viewable Image Size Pixel pitch 0.27675 mm(H) x 0.27675 mm(V) Panel R, G, B Analog Interface & Digital Interface &...
G2460PQU 2. Setup 2.1 Contents in Box Note: Not all signal cables (Audio, Analog, DVI, DP, USB and HDMI cables) will be provided for all countries and regions. Please check with the local dealer or AOC branch office for confirmation.
Service Manual G2460PQU 2.2 Setup Stand & Base Please setup or remove the base following the steps as below. Setup: Remove: 2.3 Adjusting Viewing Angle For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor's angle to your own preference.
Service Manual G2460PQU 2.4 Connecting the Monitor Cable Connections In Back of Monitor and Computer: To protect equipment, always turn off the PC and LCD monitor before connecting. 1. Connect the power cable to the AC port on the back of the monitor.
5. Reconnect the cables. Refer to the user's manual that came with the optional wall mounting arm for instructions on attaching it to the wall. Note : VESA mounting screw holes are not available for all models, please check with the dealer or official department of AOC.
Service Manual G2460PQU 3. Operation Instructions 3.1 Hotkeys Source / Auto / Exit Eco (DCR / i-Care) / < Volume / > Menu / Enter Power Power Press the Power button to turn on/off the monitor. Menu/Enter Press to display the OSD or confirm the selection.
Service Manual G2460PQU 3.2 OSD Setting Basic and simple instruction on the control keys. 1) Press the MENU-button to activate the OSD window. 2) Press < or > to navigate through the functions. Once the desired function is highlighted, press the MENU-button to activate it.
Page 12
Service Manual G2460PQU Luminance 1. Press (Menu) to display menu. 2. Press < or > to select (Luminance), and press to enter. 3. Press < or > to select submenu, and press to enter. 4. Press < or > to adjust.
Page 13
Service Manual G2460PQU Image Setup 1. Press (Menu) to display menu. 2. Press < or > to select (Image Setup), and press to enter. 3. Press < or > to select submenu, and press to enter. 4. Press < or > to adjust.
Page 14
Service Manual G2460PQU 4. Press < or > to adjust. 5. Press to exit. Picture Boost 1. Press (Menu) to display menu. 2. Press < or > to select (Picture Boost), and press to enter. 3. Press < or > to select submenu, and press to enter.
Page 15
Service Manual G2460PQU OSD Setup 1. Press (Menu) to display menu. 2. Press < or > to select (OSD Setup), and press to enter. 3. Press < or > to select submenu, and press to enter. 4. Press < or > to adjust.
Service Manual G2460PQU Exit 1. Press (Menu) to display menu. 2. Press < or > to select (Exit), and press to enter. 3. Press to exit. 3.3 LED Indicator status LED Color Full Power Mode Green or Blue Active-off Mode...
Service Manual G2460PQU 4. Interface description 4.1 Pin Assignments Pin No. Description Pin No. Description Red Input +5VDC Green Input Blue Input SDA- DDC-Serial Data Connection detect H Sync Red GND V Sync Green GND SCL- DDC-Serial Clock Blue GND Pin No.
Service Manual G2460PQU 5. Panel Feature This specification applies to the 24 inch-FHD color a-Si TFT-LCD Module M240HW01. The display supports the FDH-1920(H) X 1080(V) screen format and 16.7M colors (RGB 6-bits + Hi-FRC data). the light source of this TFT-LCD module is W-LED. All input signals are 4-channel LVDS interface and this module doesn’t contain a driver for backlight.
Service Manual G2460PQU 5.3 Absolute Max Ratings Absolute maximum ratings of the module are as follows: Parameter Symbol Unit Conditions Logic/LCD Drive Voltage [Volt] Note1,2 LED Current ILED [mA] Note1,2 Operating Temperature [℃] Note3 Glass surface temperature(Operation) [℃] Note3,4 Operation Humidity...
Service Manual G2460PQU 5.4 Electrical Characteristics 1) Power Specification Input power specifications are as following: 2) Signal Electrical characteristics Input signals shall be low or Hi-Z state when VDD is off. Please refer to specifications of SN75LVDS82DGG (Texas instruments) in detail.
Page 22
Service Manual G2460PQU ⑵ DC Characteristics 3) Backlight Unit Parameter guideline for LED driving is under stable conditions at 25 ℃ (Room Temperature): Note1: The specified current is input LED chip 100% duty current. Note2: The value showed in the table is one light bar’s operation voltage.
Service Manual G2460PQU 6. Block Diagram 6.1 LCD Block Diagram The LCD Monitor will contain main board, power board, key board which house the flat panel control logic, brightness control logic and DDC. The power board will provide AC to DC main board chips each voltage. and the Inverter voltage DC to AC to drive...
Service Manual G2460PQU 6.3 Power Board Block Diagram Fuse smoothing Rectifier Transformer Rectifier capacitor AC input 100-240V Rectifier IC-PWM Switching Rectifier Power adapter Part Sense resistor regulating Photo Couple Sampling DC-AC Resonance NET High Voltage 12V DC Switching MOS Transformer...
Service Manual G2460PQU 6.4 Software Flow Chart Software Flow Chart Start Initial_MCU Check if DataBuffer Is blank To Write default values Check if Sum is changed ? Brightness Contrast Language Read parameter_from Buffer InputType InputTimingStableCounter Init_GlobalVariables OsdCounter PowerDownCounter Initial_MCU Device...
G2460PQU T P V ( Top Victory Electronics Co . , Ltd. ) OEM MODEL Size G5121-M0D-000-0040 AOC G2460PQU 絬 隔 瓜 絪 腹 TPV MODEL Key Component 715G5121-M0D-000-0040 02.Sy stem Power PCB NAME 称爹 <称爹> Date Wednesday , September 12, 2012...
Page 27
T P V ( Top Victory Electronics Co . , Ltd. ) OEM MODEL Size G2460PQU 絬 隔 瓜 絪 腹 TPV MODEL 715G5121-M0D-000-0040 AOC G2460PQU Key Component 03.Input_D-SUB PCB NAME 称爹 <称爹> 715G5121-M0D-000-0040 Wednesday , September 12, 2012 Sheet Date...
Page 28
G2460PQU Custom T P V ( Top Victory Electronics Co . , Ltd. ) OEM MODEL Size G5121-M0D-000-0040 AOC G2460PQU 絬 隔 瓜 絪 腹 TPV MODEL 715G5121-M0D-000-0040 Key Component 04.Input_DVI PCB NAME 称爹 <称爹> Date Wednesday , September 12, 2012...
Page 29
( Top Victory Electronics Co . , Ltd. ) OEM MODEL Size G2460PQU 絬 隔 瓜 絪 腹 TPV MODEL HE5V FB106 120R G5121-M0D-000-0040 AOC G2460PQU 715G5121-M0D-000-0040 Key Component 06.Input_HDMI_S PCB NAME 称爹 <称爹> Date Wednesday , September 12, 2012 Sheet...
Page 30
T P V ( Top Victory Electronics Co . , Ltd. ) OEM MODEL Size G2460PQU G5121-M0D-000-0040 AOC G2460PQU 絬 隔 瓜 絪 腹 TPV MODEL Key Component 715G5121-M0D-000-0040 06.Input_DP PCB NAME 称爹 <称爹> Friday , September 21, 2012 Sheet...
Page 31
T P V ( Top Victory Electronics Co . , Ltd. ) OEM MODEL Size G2460PQU 絬 隔 瓜 絪 腹 TPV MODEL G5121-M0D-000-0040 AOC G2460PQU Key Component 06.Scalar_Input_GPIO PCB NAME 715G5121-M0D-000-0040 <称爹> 称爹 Date Wednesday , September 12, 2012 Sheet...
Page 32
T P V ( Top Victory Electronics Co . , Ltd. ) OEM MODEL Size G2460PQU G5121-M0D-000-0040 絬 隔 瓜 絪 腹 TPV MODEL AOC G2460PQU Key Component 08.Scalar_DDR3 PCB NAME 715G5121-M0D-000-0040 <称爹> 称爹 Date Wednesday , September 12, 2012 Sheet...
Page 33
T P V ( Top Victory Electronics Co . , Ltd. ) OEM MODEL Size G2460PQU 絬 隔 瓜 絪 腹 TPV MODEL 715G5121-M0D-000-0040 AOC G2460PQU Key Component 715G5121-M0D-000-0040 09.Scalar_Power_GND PCB NAME 称爹 <称爹> Date Wednesday , September 12, 2012 Sheet...
Page 34
T P V ( Top Victory Electronics Co . , Ltd. ) OEM MODEL Size G2460PQU G5121-M0D-000-0040 絬 隔 瓜 絪 腹 TPV MODEL AOC G2460PQU 715G5121-M0D-000-0040 Key Component 10.Scalar_PANEL I/F PCB NAME <称爹> 称爹 Wednesday , September 12, 2012 Sheet Date...
Page 35
120R 6A T P V ( Top Victory Electronics Co . , Ltd. ) OEM MODEL Size G2460PQU G5121-M0D-000-0040 AOC G2460PQU 絬 隔 瓜 絪 腹 TPV MODEL 715G5121-M0D-000-0040 Key Component 11.Audio_Power PCB NAME 称爹 <称爹> Date Wednesday , September 12, 2012...
Page 36
T P V ( Top Victory Electronics Co . , Ltd. ) OEM MODEL Size G2460PQU 絬 隔 瓜 絪 腹 TPV MODEL 715G5121-M0D-000-0050 AOC G2460PQU 715G5121-M0D-000-0040 Key Component 12.Audio_Processer PCB NAME <称爹> 称爹 Date Wednesday , September 12, 2012 Sheet Asus_3D_Single_Chip...
Page 37
Victory Electronics Co . , Ltd. ) OEM MODEL Size Custom FB616 120R 6A G2460PQU 絬 隔 瓜 絪 腹 TPV MODEL G5121-M0D-000-0040 AOC G2460PQU Key Component 13.Audio_Amp PCB NAME 715G5121-M0D-000-0040 称爹 <称爹> Date Wednesday , September 12, 2012 Sheet...
Page 38
T P V ( Top Victory Electronics Co . , Ltd. ) OEM MODEL Size G2460PQU 絬 隔 瓜 絪 腹 TPV MODEL G5121-M0D-000-0040 AOC G2460PQU Key Component 14.Emitter PCB NAME 715G5121-M0D-000-0050 称爹 <称爹> Date Wednesday , September 12, 2012 Sheet Asus VA27 series...
Service Manual G2460PQU 7.6 IR Board--- 715G5368T U040 SMBDAT DATA SMBCLK CN040 ALS-PDIC17-79NB/TR8 SMBCLK SMBDAT CONN T P V ( Top Victory Electronics Co . , Ltd. ) OEM MODEL Size AOC e2460Swh 絬 隔 瓜 絪 腹 G5368-T0F-000-0040-120316 TPV MODEL...
Service Manual G2460PQU 9. Maintainability 9.1 Trouble Shooting Main Board--- No Power No power Check flow chart For the no power Press power key and look if the picture is normal Please reinsert and make sure the AC 100-240V is normal Reinsert or check the power section Check 5V-CN101, 3.3V-U103-2;...
Page 49
Service Manual G2460PQU No picture (LED orange) No picture heck flow chart for the no signal Check signal wire Replace signal wire Check U103 Vout=3.3V; U104-out=1.8V replaceU103,U104,Q104, &around device check X401 waveform replace X401 Check CN402-HS/VS waveform Check Correspondent component...
Page 50
Service Manual G2460PQU Power Board--- No Power 5V/12V Check flow chart Check CN901 For the no power 100-240V Check AC supply Check rectified voltage-C905 Check FuseF901/ BD901 L902/BD901/C901/C902 Check voltage of IC901-8pin check component R905/R920 Check T901(1-3)out-Vcc Check D901/R910/C911 Check IC901-drive out...
Page 51
Service Manual G2460PQU No Backlight of panel Check flow chart for the Check voltage of C804-16V Inverter No Backlight Open C804 voltage-16V Return check Power Check ON/OFFsignal After Power off, check Check main board C804/C811/Q805/Q806 Check IC801—11pin=5V After Power off, check...
Service Manual G2460PQU Key Board--- OSD no working OSD is unstable or not Check flow chart working For the key board Is Key Pad Board connecting Connect Key Pad Board normally Is Button Switch normally Replace Button Switch Is Key Pad Board normally...
Service Manual G2460PQU 9.3 Factory mode adjustment After replacing the Main board and the Panel, Check if white-balance is within the specs, then re-writing DDC is necessary. Check for enter the Factory mode: Press button and hold, reinsert the Power cord, then, press MENU, the monitor will may enter Factory OSD Menu.
Service Manual G2460PQU 9.4 Writing DDC program step 1. Prepared the PC with Windows XP system, DDC recording device (12V) 2. Connect the DDC recording device and the PC through PC parallel port 3. setup―Port95nt‖ driver program to PC , 4.
Page 60
Service Manual G2460PQU R131 061G0402000 JT RST 0402 0.05R MAX 1/16W - R517 061G0402000 JT RST 0402 0.05R MAX 1/16W - R428 061G0402000 JT RST 0402 0.05R MAX 1/16W - R121 061G0402000 JT RST 0402 0.05R MAX 1/16W - R421 061G0402000 JT RST 0402 0.05R MAX 1/16W -...
Page 65
Service Manual G2460PQU R636 061G0603000 JT RST CHIP MAX 0R05 1/10W TZAI YUAN R123 061G0603000 JT RST CHIP MAX 0R05 1/10W TZAI YUAN R450 061G0603000 JT RST CHIP MAX 0R05 1/10W TZAI YUAN R646 061G0603000 JT RST CHIP MAX 0R05 1/10W TZAI YUAN...
Page 66
Service Manual G2460PQU R650 061G0805100 JT RST CHIP 10R 1/8W 5% TZAI YUAN R640 061G0805100 JT RST CHIP 10R 1/8W 5% TZAI YUAN R649 061G0805100 JT RST CHIP 10R 1/8W 5% TZAI YUAN R657 061G0805100 JT RST CHIP 10R 1/8W 5% TZAI YUAN...
Page 67
Service Manual G2460PQU C446 065G040210412K M CAP 0402 0.1UF 10% 16V X7R C454 065G040210412K M CAP 0402 0.1UF 10% 16V X7R C416 065G040210412K M CAP 0402 0.1UF 10% 16V X7R C481 065G040210412K M CAP 0402 0.1UF 10% 16V X7R C426 065G040210412K M CAP 0402 0.1UF 10% 16V X7R...
Page 68
Service Manual G2460PQU C423 065G040210412K M CAP 0402 0.1UF 10% 16V X7R C410 065G040210412K M CAP 0402 0.1UF 10% 16V X7R C740 065G040210412K M CAP 0402 0.1UF 10% 16V X7R C428 065G040210412K M CAP 0402 0.1UF 10% 16V X7R C456 065G040210412K M CAP 0402 0.1UF 10% 16V X7R...
Page 69
Service Manual G2460PQU C439 065G040210412K T CAP CHIP 0402 100nF 16V X7R C472 065G040210412K T CAP CHIP 0402 100nF 16V X7R C440 065G040210412K T CAP CHIP 0402 100nF 16V X7R C467 065G040210412K T CAP CHIP 0402 100nF 16V X7R C425...
Page 70
Service Manual G2460PQU C521 065G040210412K T CAP CHIP 0402 100nF 16V X7R C456 065G040210412K T CAP CHIP 0402 100nF 16V X7R C443 065G040210412K T CAP CHIP 0402 100nF 16V X7R C733 065G040210425K M CAP 0402 100NF 10% 25V X5R C484...
Page 71
Service Manual G2460PQU C508 065G040268132K Y CAP 0402 680pF 50V X7R +/-10% C716 065G040282132K Y CAP CHIP 0402 820P 50V X7R +/-10% C671 065G060310232K F CAP CHIP 0603 1NF K 50V X7R C643 065G060310232K F CAP CHIP 0603 1NF K 50V X7R...
Page 72
Service Manual G2460PQU C514 065G080510522K T CAP 0805 1UF 10% 25V X7R C516 065G080510522K T CAP 0805 1UF 10% 25V X7R C518 065G080510522K T CAP 0805 1UF 10% 25V X7R C511 065G080510522K T CAP 0805 1UF 10% 25V X7R C438...
Page 73
Service Manual G2460PQU C649 065G080522432K Y CAP CHIP 0805 220N 50V X7R +/-10% C654 065G080522432K Y CAP CHIP 0805 220N 50V X7R +/-10% C641 065G080522432K Y CAP CHIP 0805 220N 50V X7R +/-10% C664 065G080522432K Y CAP CHIP 0805 220N 50V X7R +/-10%...
Page 74
Service Manual G2460PQU FB506 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF FB512 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF FB503 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF FB509 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF FB701...
Page 77
Service Manual G2460PQU Q51G 100502 GLUE_RED_MALER 0.002 AIKEPCCJA9 KEY BOARD FOR AI SW004 077G603S AI CJ TACT SWITCH AI 2PIN SEALED SW003 077G603S AI CJ TACT SWITCH AI 2PIN SEALED SW005 077G603S AI CJ TACT SWITCH AI 2PIN SEALED SW001...
Page 87
Service Manual G2460PQU C759 065G040210412K M CAP 0402 0.1UF 10% 16V X7R C780 065G040210412K M CAP 0402 0.1UF 10% 16V X7R C781 065G040210412K M CAP 0402 0.1UF 10% 16V X7R C773 065G040210412K M CAP 0402 0.1UF 10% 16V X7R C750 065G040210412K M CAP 0402 0.1UF 10% 16V X7R...
Page 88
Service Manual G2460PQU FB747 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF FB740 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF FB745 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF FB744 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF FB746...
