INSTRUCTIONS

14.RDS USER OPERATION

Press PTY, when PTY is on, it means there
is strong RDS signals output.
Press this button to choose radio
channels' name, please refer to details
user manual.
Press this button to close sound
output, re-press this button to
resume sound.
Press "SEL" to adjust other
functions, please refer to pic 3.
In the radio state, press APS" button, "
it will automatically seek radio
channels in the whole band and preset
the strongest radio channels.
For details of RDS operation, please refer to other instruction
Short press on this button to
decrease radio frequency;
longer press on this button to
seek radio channels frequency
decreased direction.
Short press on this button to
increase radio frequency;
longer press on this button to
seek radio channels frequency
increased direction.
Touch this area to
enter & exit main
menu.
Press this button to
adjust angles of the
monitor.
Press this button each time, it
will automatically execute the
following operation in an
order of FM1 → FM2 → FM3 →
AM1 → AM2
Press TA, when TA is on, it
means the unit is automatically
track RDS radio channels.
RDS
1. EON (RDS Mark)
Indicate main unit is on auto tracking RDS mode.
2. AF (RDS Auto Tracking Mark)
Indicate radio is auto tracking RDS channel.
3. TA (RDS Signal Increasing Output)
Indicate RDS channel have signal increasing output.
4. TP (RDS Channel Stereo Mark)
Indicate RDS channel is on stereo playing mode.
5. POP.M (RDS Channel Mark)
Indicate RDS channel name.
1. RDS Tracking System
Press AF button in FM mode, and then press
channel up and down, it will stop searching when RDS channel be founded, but "AF"
will keep remaining on the screen and waits for the next traffic emergency report.
2. RDS Tracking on Playing Mode
In playing mode, "AF" tracking system keeps on opening and waits for traffic emergency
report.
1) PTY: RDS button, press once will show music mode POP, press 1-6 function
memory button, every group have 2 channel.
POP M ROCK M EASY M
LIGHT M CLASSICS M OTHER M
JAZZ
COUNTRY NATION
2) Press PTY button twice and then press 1-6 function memory button, every
button have 3 channel.
NEWS AFFAIRS INFORMATION
EDUCATION DRAMA CULTURE
CHILDREN SOCIETT RELIGION
TRAVEL
Note: RDS channel in broken line is available.
AF: RDS auto search button, in radio mode also can press this button shortly auto
tracking RDS channel, press this button shortly can cancel RDS function.
TA: In RDS mode, press this button can output TA signal, and check RDS channel is
exist or not, if no RDS signal TFT will show "NO.TA.TP".
INSTRUCTIONS
/ last 2 minutes, RDS will auto search
SPORT
SCIENCE
PHONING
