Corded Telephone
Model: CT330

Advertisement

Table of Contents
loading

Related Manuals for Motorola CT330

Summary of Contents for Motorola CT330

  • Page 1 Corded Telephone Model: CT330...
  • Page 2 Caller ID shows you the number of who is calling and stores the number of the last 34 callers in a Calls list. Need help? If you have any problems setting up or using your CT330, please contact Customer Services on Services on (65) 68412668. Email: support@alcom.com.sg Alternatively, you may find the answer in the ‘Help’...
  • Page 3 This User Guide provides you with all the information you need to get the most from your phone. Before you make your first call you will need to set up your phone. Follow the simple instructions in ‘Getting Started’, on the next few pages. IMPORTANT Only use the telephone line cord supplied.

  • Page 4: Table Of Contents

    1. Getting started ..............6 2. Getting to know your phone ..........8 3. Using the phone ..............11 Calls .......................11 3.1.1 Make a call ..................11 3.1.2 Pre-dial ....................11 3.1.3 End a call ....................11 3.1.4 Receive a call ..................11 Hold ........................11 Redial ......................11 4.
  • Page 5 12. Calls lists ................21 12.1 Enter the Missed calls list ................21 12.2 Enter the Received calls list ................21 12.3 Enter the Redial list ..................21 12.4 Dial a number from the Missed or Received calls list or Redial list ....21 12.5 Delete a number from the Missed or Received calls list or Redial list ..21 12.6 Delete all numbers from the Missed or Received calls list or Redial list ..22...

  • Page 6: Getting Started

    Do not place your CT330 in the bathroom or other humid areas. Location You need to place your CT330 base within 2 metres of the telephone wall socket so that the cable will reach. The socket-outlet shall be installed near the equipment and shall be easily accessible.

  • Page 7: Date And Time

    Overview of your handset A Earpiece To listen to your caller. Microphone To speak to your caller. C Curly cord socket Where you plug in your curly cord. Date and time If you have subscribed to a FSK type Caller ID Service, the date and time is set automatically when you receive your first call.

  • Page 8: Getting To Know Your Phone

    2. Getting to know your phone Overview of the base A Display See next section for an overview of display icons. Received calls list / Scroll up Press to enter the Recevied calls list. Scroll up though ringtones and calls lists entries. C Delete / R1 Short recall (100ms) Press to delete an incorrect number.
  • Page 9 H Pause When dialling or storing a number press to enter a pause (P). Volume up / down Press to change the ringer volume in standby mode. Press to change the hands-free volume. J M1 Press when storing and dialling memory numbers. K M2 Press when storing and dialling memory numbers.
  • Page 10 Display Indicates when you are viewing the missed calls list. Indicates when you are viewing the received calls list. Indicates when you are viewing the redial list. Flashes when you have received a new call. Indicates when you have more than 1 missed call from the viewed number. Indicates when you have a voicemail waiting.

  • Page 11: Using The Phone

    3. Using the phone Calls 3.1.1 Make a call Lift the handset, when you hear the dial tone, dial the number. 3.1.2 Pre-dial 1. Enter the phone number (maximum 32 digits). If you make a mistake press X. > 2. Press to dial the phone number entered over hands-free.

  • Page 12: Memory

    4. Memory You can store 10 two-touch memory numbers and 2 one touch memory numbers under buttons; the numbers can be up to 16 digits long. Store a memory number 1. Dial the number to be stored. 2. Press 3. Press one of the numbers on the keypad 0-9, the number is stored.

  • Page 13: Dial A One-Touch Memory Number On Hands-Free

    Dial a one-touch memory number on hands-free 1. Press 2. The memory number will be dialled out. NOTE Remember to make a note of your memory numbers for easy reference. To change the phone number in the memory just overwrite the new number in the same location.

  • Page 14: Ring Tone

    5. Ring tone Your CT330 has a choice of 24 ringtones and choose from 4 volume levels and crescendo. Set the ringtone 1. Press . The current ringtone is played. 2. Press to scroll to the required ringtone. A sample of the ringtone is played.

  • Page 15: Date And Time

    6. Date and time If you have subscribed to a FSK type Caller ID Service, the date and time is set automatically when you receive your first call. If you do not have a FSK Caller ID service, you can set the date and time manually. NOTE I n either case year has to be manually set.

  • Page 16: Area Code

    7. Area Code You can set your local area code into the phone. When a number from that area code calls only the local number will be displayed and stored. To store the area code 1. Press , the display shows SEt 1 dAtE.

  • Page 17: Pabx Access Code

    8. PABX access code If the CT330 is connected to a switchboard, you may need to enter a one-digit access code in the dialling sequence to be able to connect to the outside line. The access code will be displayed at the beginning of a number on the screen.

  • Page 18: Display

    9. Display You can change the contrast of the display; there are 5 levels to choose from. Change the display contrast Either: 1. Press , the display shows SEt 1 dAtE. 2. Scroll SEt 4 LCd. 1. Press , the display shows and the current contrast level.

  • Page 19: Alarm

    10. Alarm Your CT330 has an alarm that once set will go off every day unless turned off. 1. Press , the display shows SEt 1 dAtE. 2. Scroll SEt 5 ALErt. 3. Press and the display shows 00-00 OFF.

  • Page 20: Recall And Dial Mode

    11. Recall and dial mode Recall is useful to access certain network services and PABX /switchboard services. Your CT330 has 2 recall buttons, X is the short flash time and is for long flash time. NOTE X Short flash is 100ms / Long Flash is 600ms.

  • Page 21: Calls Lists

    12. Calls lists If you have subscribed to a Caller ID service, and provided the identity of the caller is not withheld, the number of the caller will be displayed together with the date and time of the call (if provided by the network). When the list is full and a new call is received, the oldest non VIP entry will be deleted automatically.

  • Page 22: Delete All Numbers From The Missed Or Received Calls List Or Redial List

    12.6 Delete all numbers from the Missed or Received calls list or Redial list 1. Press to enter the Missed calls list, to enter the Received calls list or to enter the Redial list. 2. Press and hold X for 3 seconds. 3.

  • Page 23: No Dial Tone

    13. Help No dial tone • Use only the telephone line cord supplied. • Check that the telephone line cord is connected properly. Storing numbers • Once you have stored a number there is no confirmation tone. • A number cannot be deleted once stored, you can overwrite it with a new number. Help...

  • Page 24: General Information

    14. General information IMPORTANT This product is intended for connection to analogue public switched telephone networks and private switchboards within Singapore Important safety instructions Follow these safety precautions when using your phone to reduce the risk of fire, electric shock, and injury to persons or property: •...

  • Page 25: Product Disposal Instructions

    Consumer Products and Accessories Warranty Thank you for purchasing this Motorola branded product manufactured under license by Suncorp Technologies Limited, 3001-3005 China Resources Building, 26 Harbour Road, Wan Chai, Hong Kong. (“SUNCORP”)
  • Page 26 Motorola or SUNCORP, are excluded from coverage. Use of Non-Motorola branded Products and Accessories. Defects or damage that result from the use of Non-Motorola branded or certified Products or Accessories or other peripheral equipment are excluded from coverage. Unauthorized Service or Modification. Defects or damages resulting from service,...

  • Page 27: Connecting To A Switchboard

    How to Obtain Warranty Service or Other Information? To obtain service or information, please call: (65) 68412668. Email: support@alcom.com.sg You will receive instructions on how to ship the Products or Accessories at your expense and risk, to a SUNCORP Authorized Repair Center. To obtain service, you must include: (a) the Product or Accessory;...
  • Page 28 <This page has been intentionally left blank>...
  • Page 29 Suncorp declares that the following products: Brandname: Motorola Type: CT330 Descriptions: Corded telephone to which this declaration related is in conformity with the essential requirements of the following directives of the Council of the European Communities: Low voltage Directive (2006/95/EC) EMC Directive (2004/108/EC) R&TTE Directive (1999/5/EC)
  • Page 30 Manufactured, distributed or sold by Suncorp Technologies Ltd., official licensee for this product. MOTOROLA and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC. and are used under license. All other trademarks are the property of their respective owners.
