Corded Telephone
Model: CT202

Advertisement

Table of Contents
loading

Related Manuals for Motorola CT202

Summary of Contents for Motorola CT202

  • Page 1 Corded Telephone Model: CT202...
  • Page 2 Call Timer the display will automatically time the duration of all external calls. Your CT202 uses dynamic software in the redial and received calls list, if the phone numbers in the list have less than 16 digits then the number of entries stored in the received calls list is increased.
  • Page 3 This user guide provides you with all the information you need to get the most from your phone. To set up your phone, follow the simple instructions in ‘Getting Started’, on the next few pages. IMPORTANT Only use the telephone line cord supplied. Got everything? •...

  • Page 4: Table Of Contents

    1. Getting started ..............6 2. Getting to know your phone ..........8 3. Using the phone ..............11 Calls .......................11 3.1.1 Make a call ..................11 3.1.2 Pre-dial ....................11 3.1.3 End a call ....................11 3.1.4 Receive a call ..................11 Hold ........................11 Redial ......................11 Redial list ......................12 4.
  • Page 5 12. Recall and Dial mode............22 12.1 Change your dial mode .................22 13. Set the alarm ...............23 14. Calls lists ................24 14.1 Enter the Received calls list ................24 14.2 Dial a number from the Received calls list ............24 14.3 Enter the Redial list ..................24 14.4 Dial a number from the Redial list..............24 15.

  • Page 6: Getting Started

    Do not place your CT202 in the bathroom or other humid areas. Location You need to place your CT202 base within 2 metres of the telephone wall socket so that the cable will reach. The socket-outlet shall be installed near the equipment and shall be easily accessible.

  • Page 7: Overview Of Your Handset

    Overview of your handset A Earpiece To listen to your caller. Microphone To speak to your caller. C Curly cord socket Where you plug in your curly cord. Getting started...

  • Page 8: Overview Of Base

    2. Getting to know your phone Overview of the base A Hook switch Hangs up a call when pressed or when you replace the handset. Display See page 10 for an overview of display icons. C Pause When dialling or storing a number press to enter a pause (P). D Set Press and hold to open the menu.
  • Page 9 E Redial list Press to view last number dialled out and continue pressing to scroll through the 5 stored numbers. Hold During a call press to put your caller on hold. In standby mode, press to change the ringtone. G Recall Use to change the contrast of the display.
  • Page 10 Display Indicates when the received calls list is open. Indicates when the redial list is open. Indicates when the number you are viewing is a VIP number. Indicates when you have new calls. Indicates when you have more than 1 missed calls from the same number. Indicates when you have a voicemail waiting.

  • Page 11: Using The Phone

    3. Using the phone Calls 3.1.1 Make a call Lift the handset, when you hear the dial tone, dial the number. 3.1.2 Pre-dial 1. Enter the phone number (maximum 32 digits). If you make a mistake press . Lift the handset to dial the number. 2.

  • Page 12: Redial List

    Redial list At least the last 5 entries dialled are stored in the phone, the numbers can be up to 32 digits long. To dial a number from the Redial list 1. Press 2. Continue pressing to scroll to the entry you want. 3.

  • Page 13: Memory

    4. Memory You can store ten telephone numbers in the two touch memory; the numbers can be up to 16 digits long. Store a two-touch memory number with the handset on the base 1. Dial the number to be stored. 2.

  • Page 14: Dial A Two-Touch Memory Number Over The Hands-Free

    Dial a two-touch memory number over the hands-free 1. Press 2. Press one of the keypad buttons 0-9. 3. Press 4. The memory number will be dialled out. 5. Once the call is answered lift the handset to talk. NOTE Remember to make a note of your memory numbers for easy reference.

  • Page 15: Ringtone

    5. Ringtone Your CT202 has a choice of 24 ringtones and choose from 4 volume levels and crescendo. The default setting is level 4. Set the ringtone 1. Press . The current ringtone is played. 2. Press to scroll to the required ringtone. A sample of the ringtone is played.

  • Page 16: Date And Time

    6. Date and time If you have subscribed to a FSK type Caller ID Service, the date and time is set automatically when you receive your first call. If you do not have a FSK Caller ID service, you can set the date and time manually. Set the date and time 1.

  • Page 17: Area Code

    7. Area code You can set your local area code into the phone. When a number from that area code calls only the local number will be displayed and stored. If you then redial the number from the calls list while Auto IP is switched on, the Auto IP number will not be dialled. Store the area code 1.

  • Page 18: Pabx Access Code

    8. PABX access code If the CT202 is connected to a switchboard, you may need to enter a one-digit access code in the dialling sequence to be able to connect to the outside line. The access code will be displayed at the beginning of a number on the screen.

  • Page 19: Auto Ip

    9. Auto IP Allows you to store your IP code in the phone for lower cost call charges for a long distance call. Store a number 1. Press and hold for 3 seconds, the display shows SEt 1 dAtE. 2. Scroll SEt 4 AUtO 3.

  • Page 20: Vip

    10. VIP An important number in the calls list can be locked in the phone. A locked number cannot be deleted from the calls list unless all numbers are deleted. If the calls list is full and all numbers in the calls list are VIP numbers the oldest VIP number will be deleted. When a VIP number calls there is a dedicated ring tone.

  • Page 21: Display

    11. Display You can change the contrast of the display; there are 5 levels to choose from. 11.1 Change the display contrast Either: 1. Press , the display shows and the current contrast level (1-5). 2. Continue pressing until you see the contrast you require. Display...

  • Page 22: Recall And Dial Mode

    Recall is useful to access certain network services and PABX/switchboard services. The recall mode preset in the CT202 is suitable for your country network. Your phone is set to tone dialling. You should only need to change this if connected to an older type of switchboard / PABX which requires pulse dialling.

  • Page 23: Set The Alarm

    13. Set the alarm 1. Press and hold for 3 seconds, the display shows SEt 1 dAtE. 2. Scroll SEt 5 ALErt. 3. Press and the display shows 00-00 OFF. 4. Scroll to set the first digit and to confirm. 5.

  • Page 24: Calls Lists

    14. Calls lists If you have subscribed to a Caller ID service, and provided the identity of the caller is not withheld, the number of the caller will be displayed together with the date and time of the call (if provided by the network). When the list is full and a new call is received, the oldest non VIP entry will be deleted automatically.

  • Page 25: Help

    15. Help No dial tone • Use only the telephone line cord supplied. • Check that the telephone line cord is connected properly. Storing numbers • Once you have stored a number there is no confirmation tone. • A number cannot be deleted once stored, you can overwrite it with a new number. Memory numbers •...

  • Page 26: General Information

    16. General information IMPORTANT This product is intended for connection to analogue public switched telephone networks and private switchboards within Singapore. Important safety instructions Follow these safety precautions when using your phone to reduce the risk of fire, electric shock, and injury to persons or property: •...

  • Page 27: Product Disposal Instructions

    (“SUNCORP”) What Does this Warranty Cover? Subject to the exclusions contained below, SUNCORP warrants that this Motorola branded product (“Product”) or certified accessory (“Accessory”) sold for use with this product that it manufactured to be free from defects in materials and workmanship under normal consumer usage for the period outlined below.
  • Page 28 Motorola or SUNCORP, are excluded from coverage. Use of Non-Motorola branded Products and Accessories. Defects or damage that result from the use of Non-Motorola branded or certified Products or Accessories or other peripheral equipment are excluded from coverage. Unauthorized Service or Modification. Defects or damages resulting from service,...

  • Page 29: Technical Information

    How to Obtain Warranty Service or Other Information? To obtain service or information, please call: (65) 68412668. Email: support@alcom.com.sg You will receive instructions on how to ship the Products or Accessories at your expense and risk, to a SUNCORP Authorized Repair Center. To obtain service, you must include: (a) the Product or Accessory;...
  • Page 30 <This page has intentionally been left blank>...
  • Page 31 Suncorp declares that the following products: Brandname: Motorola Type: CT202 Descriptions: Corded telephone to which this declaration related is in conformity with the essential requirements of the following directives of the Council of the European Communities: Low voltage Directive (2006/95/EC) EMC Directive (2004/108/EC) R&TTE Directive (1999/5/EC)
  • Page 32 Manufactured, distributed or sold by Suncorp Technologies Ltd., official licensee for this product. MOTOROLA and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC. and are used under license. All other trademarks are the property of their respective owners.
