Page 1 HDX series User and Installation manual For HDX, HDX W12, HDX W14,HDX W18 and HDX W20 R5905032/15 16/06/2015...
Page 2 Product revision Software version: 1.10. Barco NV Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.82.11 Fax: +32 56.36.883.86 Support: www.barco.com/en/support Visit us at the web: www.barco.com Printed in Belgium...
Page 3 GNU-GPL code If you would like a copy of the GPL source code contained in this product shipped to you on CD, please contact Barco. The cost of preparing and mailing a CD will be charged. Guarantee and Compensation Barco provides a guarantee relating to perfect manufacturing as part of the legally stipulated terms of guarantee.
Page 5: Table Of Contents
Test patterns in adjustment mode....................74 R5905032 HDX SERIES 16/06/2015...
Page 6 10.4.2 Picture in Picture activation....................138 R5905032 HDX SERIES 16/06/2015...
Page 7 12.15.3 3D Sync Loop Through ..................... .206 R5905032 HDX SERIES 16/06/2015...
Page 8 14.13 Time and Date ........................279 R5905032 HDX SERIES 16/06/2015...
Page 9 E. Stacking HDX projectors ............... ..
Page 10 Table of contents R5905032 HDX SERIES 16/06/2015...
Page 11: Safety
Read this chapter attentively. It contains important information to prevent personal injury while installing and using a HDX projector. Furthermore, it includes several cautions to prevent damage to the HDX projector. Ensure that you understand and follow all safety guidelines, safety instructions and warnings mentioned in this chapter before installing your HDX projector. After this chapter, addi- tional “warnings”...
Page 12: Important Safety Instructions
ﬁxed wiring. • Never stack more than two (2) HDX projectors in a hanging conﬁguration (truss) and never stack more than three (3) HDX projectors in a base stand conﬁguration (table mount).
Page 13 ﬁre extinguishers. Never use water on an electrical ﬁre. Always have service performed on this projector by authorized Barco service personnel. Always insist on genuine Barco replacement parts. Never use non-Barco replacement parts as they may degrade the safety of this projector.
Page 14: Light Beam Hazard Distance (Hd)
If the product exhibits a distinct change in performance, indicating a need for service. • Replacement parts: When replacement parts are required, be sure the service technician has used original Barco replacement parts or authorized replacement parts which have the same characteristics as the Barco original part. Unauthorized substitu- tions may result in degraded performance and reliability, ﬁre, electric shock or other hazards.
Page 15: Hd In Function Of The Lens Throw Ratio (Tr)
(RZ) in the theater must be established. This can be done by using physical barrier, like a red rope as illustrated in image 1-2. Image 1-2 HD in function of the lens Throw Ratio (TR) TR (Throw Ratio) The ratio of the distance to the screen (throw) to the screen width. R5905032 HDX SERIES 16/06/2015...
Page 16: Important Warnings Concerning Hdx Flight Cases
Important warnings concerning stacking/transporting HDX rental ﬂight cases • Stack maximum two (2) HDX rental ﬂight cases high. Never higher. • Surface on which ﬂight case is standing must be level to ensure that the total load is evenly spread out among the four wheels.
Page 17: General
2. GENERAL About this chapter Read this chapter before installing your HDX projector. It contains important information concerning installation requirements for the HDX projector, such as minimum and maximum allowed ambient temperature, humidity conditions, required safety area around the installed projector, required power net, etc.
Page 18: Unpacking The Projector
Projector weight Do not underestimate the weight of the HDX projector. The projector weights about ±50 kg (±111 lb.) without lens. Be sure that the pedestal on which the projector has to be installed is capable of handling ﬁve (5) times the complete load of the system.
Page 19: Initial Inspection
Save all packing material until the inspection is completed. If damage is found, ﬁle claim with carrier immediately. The Barco Sales and Service ofﬁce should be notiﬁed as soon as possible.
Page 20: Hdx Flight Case
The HDX ﬂight case is designed to transport the HDX projector in a safe and secure manner. The four caster wheels, provided with breaks, and the four handles make the HDX ﬂight case easy to handle. The ﬂoor of the ﬂight case wagon is equipped with two small covered compartments to store the remote control and the rigging clamps.
Page 21: Rear Projection
Front projection, Ceiling mounted, in table position Rear projection The projector is installed, either in a table mount or ceiling mount conﬁguration, at the other side of the screen opposite the audience. AUDIENCE BACKSTAGE FLOOR Image 2-6 Rear projection R5905032 HDX SERIES 16/06/2015...
Page 22: Positioning The Projector
Off-Axis projection is obtained by shifting the lens up, down, left or right. Several parameters can be calculated determining the position in any installation. Formula to calculate the distance CD for On-Axis projection: CD = SH/2 + B - A R5905032 HDX SERIES 16/06/2015...
Page 23 Side to side tilt, however, must not exceed ±15°. This limit ensures that the lamp in the projector operates properly and safely. More tilting within area C is allowed but lamp ﬂicker can happen. 360° 15° 15° 15° 15° Image 2-10 Tilting allowed without problems No tilting allowed in this area R5905032 HDX SERIES 16/06/2015...
Page 24: Projector Air Inlets And Outlets
Air inlets and outlets Image 2-11 The HDX projector has 3 air inlet channels and 3 air outlets. The air outlets are located at the rear of the projector. The air inlets are located at the front of the projector.
Page 25: Installation Process Overview
Installation process overview Quick setup The following steps describe brieﬂy how to setup your HDX projector in a table mount front projection. Note that each step refers to a corresponding procedure, which is more detailed and illustrated. 1. Install the batteries of the remote control. See "RCU battery installation", page 23 2.
Page 26 2. General R5905032 HDX SERIES 16/06/2015...
Page 27: Physical Installation
Introduction The remote control unit (A) of the HDX projector is equipped with a rugged case (B) and an XLR adaptor (C). The remote control unit can be used wired via mini-jack or via rugged XLR. Note that the backlight, of the remote control unit, illuminate continuously when wire connected.
Page 28: Rcu Rugged Case Installation
How to install the rugged case of the remote control ? 1. Slide the bottom of the RCU into the rugged case and then pull the top of the rugged case over the top of the RCU as illustrated. R5905032 HDX SERIES 16/06/2015...
Page 29: Rcu Xlr Adaptor Installation
1. Connect a cable with XLR plug into the XLR adaptor. 2. Connect the other end of the cable with your HDX projector. 3. Push the XLR adaptor completely against the rugged case of the remote control unit, as illustrated in the left image below, for wired communication.
Page 30: Rcu Usage Possibilities
RCU with rugged case and XLR adaptor The RCU will send the commands via the cable connected with the XLR pushed in “WIRED” and wired adaptor to the projector. Backlight illuminates continuously when wire is connected. Infra red disabled. Image 3-8 R5905032 HDX SERIES 16/06/2015...
Page 31: Lenses
Scheimpﬂug adjustment 3.2.1 Available lenses Available lenses for the HDX projector projector The TLD HB (High Brightness) lens series can be used on the HDX projector projector. Image 3-9 Image 3-10 Image 3-11 R9852000: TLD HB ﬁxed lens (0.8 : 1) R9840770: TLD ﬁxed lens (1.2 : 1)
Page 32: Lens Selection
How to select the right lens 1. Determine the required screen width (SW). 2. Determine the approximate position of the projector in the room. 3. Start up the Lens Calculator on the Barco website: http://www.barco.com/en/tools/lenscalculator to determine the possible lenses for your conﬁguration.
Page 33: Lens Installation
2. Take the lens assembly out of its packing material and remove the lens caps on both sides. 3. Place the lens holder in the “unlocked” position by moving the lens lock handle (A) towards the lens power supply socket (B) as illustrated. Image 3-24 Lens installation, preparation R5905032 HDX SERIES 16/06/2015...
Page 34: Lens Removal
Neglecting this can damage the Lens Holder and Prism. 3.2.4 Lens removal How to remove 1. Support the lens with one hand while you unlock the lens holder by sliding the lock handle towards the “unlocked” position as illustrated. R5905032 HDX SERIES 16/06/2015...
Page 35: Lens Safety Cable
The lens safety cable must be used in any circumstances to protect a mounted lens in the lens holder when the projector is mounted above persons. Necessary parts Safety cable: R9801079 (Barco order number) How to mount the cable 1. Put the safety cable around the lens. Make sure the cable is mounted between the motor part and the mounting ﬂange...
Page 36 Secure the cable by ﬁxating the nut of the clamp. Image 3-30 Clamp position 3. Turn the cable with hook lock around the carry handle and hook the hook lock around the cable. R5905032 HDX SERIES 16/06/2015...
Page 37: Lens Shift, Zoom & Focus
Take into account that the lens focus may slightly drift while the lens is warming up from cold to operation temperature. This is a typical phenomenon for projection lenses used with high brightness projectors. The operation temperature of the lens is reached after approximately 30 minutes projection of average video. R5905032 HDX SERIES 16/06/2015...
Page 38: Scheimpﬂug Adjustment
1, 2 and 3 Scheimpﬂug adjustment nuts A, B, C and D Set screws a, b, c and d lock nuts 1, 2 and 3 are adjustment points. 4 is a locking point and NOT used during Scheimpﬂug adjustment. R5905032 HDX SERIES 16/06/2015...
Page 39: How To Adjust
Place the zoom lens in WIDE position (largest projected image) and adjust the focus by turning equally on nut 1, 2 and 3. c) Repeat steps “a” and “b” until the projected image is as sharp as possible. Image 3-37 Center focusing R5905032 HDX SERIES 16/06/2015...
Page 40 6. Sharpen bottom left corner of the screen by adjusting nut 1. Image 3-38 Left bottom focusing 7. Sharpen bottom right corner of the screen by adjusting nut 2. Image 3-39 Right bottom focusing 8. Sharpen top right corner of the screen by adjusting nut 3 R5905032 HDX SERIES 16/06/2015...
Page 41: Connecting The Projector With The Power Net
The amount of image movement in step 3 will determine how tight the nut in step 5 will need to be turned to return the image to its original position. Connecting the projector with the power net AUTION Use only the power cord provided with the projector. R5905032 HDX SERIES 16/06/2015...
Page 42: Alignment Of A Table Mounted Projector
1. Place the projector in the desired location. Take into account the zoom range of the used lens and the size of the screen. 2. Project one of the internal hatch patterns on the screen. 3. Turn the adjustable feet in or out until the projected hatch pattern has a perfect rectangle shape and is leveled. R5905032 HDX SERIES 16/06/2015...
Page 43: Mounting The Bottom Carry Handler
4x bolt M10 x 16 mm How to mount 1. Turn the projector upside down. 2. Turn out the 4 feet. Image 3-45 Remove feet 3. Turn out the feet of the carry handle as far as possible. R5905032 HDX SERIES 16/06/2015...
Page 44: Mounting The Top Carry Handler
5. Insert a bolt in each corner and turn in these bolts. Image 3-47 Insert bolts Mounting the top carry handler Purpose This carry handle can be used to transport the projector in an easy way. Necessary tools 8 mm Allen wrench R5905032 HDX SERIES 16/06/2015...
Page 45: Suspension Of The Projector With Rigging Clamps
Image 3-49 Rigging points Necessary tools • Open end spanner 24 mm • Open end spanner 17 mm Necessary parts 4 rigging clamps R5905032 HDX SERIES 16/06/2015...
Page 46 4. Place all four rigging clamps in open position. 5. Place the projector (upside down) under the truss installation and lower the truss until the support bars of the truss are nearby the rigging clamps mounted on the projector. R5905032 HDX SERIES 16/06/2015...
Page 47 Mount the 2 safety cables around the carry handle (push the hook through the loop and then around the truss so that there is not to much play (maximum 20 cm). If necessary turn the cable a few times around the truss before clasping the safety hook around the cable. R5905032 HDX SERIES 16/06/2015...
Page 48: Alignment Of A Ceiling Mounted Projector
1. Turn the adjustment knob on the carry handle until the projected hatch pattern is perfectly squared. Skew Image 3-56 Skew adjustment Tilt adjustment with the clamps 1. Adjust both front side clamp or both back side clamps to adjust the tilting. Always adjust by two to avoid deformation of the frame. R5905032 HDX SERIES 16/06/2015...
Page 49 3. Physical installation 2. Loosen the security nut on both clamps. 3. Adjust the adjustment nuts of both clamps until the desired tilting is reached. 4. Turn the safety nut on the rigging clamp against the rigging point R5905032 HDX SERIES 16/06/2015...
Page 50 3. Physical installation R5905032 HDX SERIES 16/06/2015...
Page 51: Input & Communication
XLR input port for remote control RS232/RS422 input port Dual Link DVI-I HDCP input Free input slot Button module Optional antenna for GSM RS232/RS422 input port Ethernet port Status and indication LEDs USB port 3G/Dual/HDSDI input - output Free input slot R5905032 HDX SERIES 16/06/2015...
Page 52: Input Source Connections
4. Input & Communication Input source connections DVI and 3G/HDSDI input This input module is standard delivered with the HDX projector. R9864000 3G/DUAL HDSDI DUAL LINK DVI-I HDCP SYNC SYNC SYNC OUT1 OUT2 INPUT Image 4-2 Dual Link DVI and 3G/Dual HDSDI input The yellow LED lights up when valid input sync is detected.
Page 53 BNC socket. Generates 3D synchronization signal to drive an infra red transmitter for active 3D glasses. In case an 3D syn- chronization signal is applied on the “3D SYNC IN” for a single channel 3D stream then the generated 3D output sync is derived from this applied sync. Input speciﬁcations R5905032 HDX SERIES 16/06/2015...
Page 54: Communication Connections
You can use the DMX input port to connect a DMX device (DMX console) to the projector. This way you can control the projector from that DMX device (console). The DMX output port can be connected with the next device in the loop. Description Earth R5905032 HDX SERIES 16/06/2015...
Page 55 The left one a Sub-D connector, the right one an USBB connector acting as RS input when connected to an USB input of a PC. You can use the RS232/RS422 input to connect a local PC to your HDX projector. By this way you can conﬁgure and control your HDX projector from your local PC.
Page 56: Usb Port
When a 100 MB network is detected IR received but not acknowledged green IR received and acknowledged orange WIFI sel When WiFi is selected green When WiFi is connected with an Ethernet See chapter “Getting started”, topic “Status LEDs” R5905032 HDX SERIES 16/06/2015...
Page 57: Utility-Accessory Outlet
Power 9 - 24 Volt DC With Setting in menu 9 / 12 / 24 @ 25W Note : do not overload ! Maximum 1A on 24V is allowed. The connector is a duplicated output of the DMX signal entering the projector over the 5 Pin XLR R5905032 HDX SERIES 16/06/2015...
Page 58 4. Input & Communication R5905032 HDX SERIES 16/06/2015...
Page 59: Getting Started
• switching to "pause" (blanked picture, full power for immediate restarting) • direct access to all connected sources. Terminology overview Overview The following table gives an overview of the different functionality of the keys. R5905032 HDX SERIES 16/06/2015...
Page 60 Use these buttons to obtain the desired picture level. PHASE Used to remove the horizontal instability of the image (usually for RGB source). It adjusts the phase of the pixel sampling clock relative to the incoming signal. FREEZE To freeze the actual projected image. R5905032 HDX SERIES 16/06/2015...
Page 61: Power On Projector
The projector starts up in standby. The menus are accessible via the local LCD panel. The start up screen is displayed on the local LCD panel and when fully started up, it changes to the overview screen. R5905032 HDX SERIES 16/06/2015...
Page 62 The background image of the startup screen and info screens can be changed with Projector Toolset with an installed HDX plug-in. Lamp overview Once the projector is started, press Lamp to get an overview of the lamp parameters such as : Image 5-4 Local screen, lamp R5905032 HDX SERIES 16/06/2015...
Page 63: Software Overview
Image 5-5 Local screen, about • Package version • Mgr software • GUI software Starting image projection via the standby key. 1. Press Stand by key once on the local keypad or on the remote control. R5905032 HDX SERIES 16/06/2015...
Page 64: Switching To Standby
How to power off 1. Press ﬁrst Standby. 2. Let cool down the projector until the fan speed decreases. At least 5 minutes. 3. Switch off the projector with the power switch. ’0’ must be pressed. R5905032 HDX SERIES 16/06/2015...
Page 65: Status Leds
LED) Red toggles on/off Error Orange toggles on/off Warning IR signal received Green IR signal acknowledged Using the RCU Pointing to the reﬂective screen 1. Point the front of the RCU to the reﬂective screen surface. R5905032 HDX SERIES 16/06/2015...
Page 66 IR sensor. 45° 45° 45° 45° 45° 45° Image 5-8 RCU to one of the IR sensors R5905032 HDX SERIES 16/06/2015...
Page 67: Projector Address
Every projector has a common address ’0’ or ’1’. The choice between ’0’ and ’1’ can be selected in Projector Control → Projector address → Common address. Source selection Source selection when no picture in picture is active Use the digit keys on the remote control or local keypad to activate the desired source. R5905032 HDX SERIES 16/06/2015...
Page 68 To select the source for the picture in picture window, press Window button until PiP window is activated and then select the desired source with the digit keys. To select the source for the main window, press Window button until the main window is activated and then select the desired source with the digit keys. R5905032 HDX SERIES 16/06/2015...
Page 69: Quick Set Up Adjustment
To toggle Text ON or OFF, press the TEXT key on the remote control or local keypad. Quick Lens Adjustment via LENS key Quick zoom/focus adjustment 1. Press the LENS key on the remote control or local keypad to open the Zoom/Focus Adjustment menu. R5905032 HDX SERIES 16/06/2015...
Page 70 Press the LENS key to call the list with available test patterns. Quick shift adjustment 1. Press the LENS key on the remote control or local keypad to open the Zoom/Focus Adjustment menu. Image 6-4 Zoom/Focus adjustment 2. Press ENTER to go to the Shift menu. R5905032 HDX SERIES 16/06/2015...
Page 71: Direct Lens Adjustment (Rcu)
Press on the PIP key on the remote control or the local keypad to activate the Load layout window. Use the ▲ ▼ key to scroll to the desired layout and press ENTER to activate. Select Main full screen to switch off PIP. R5905032 HDX SERIES 16/06/2015...
Page 72: Quick Language Selection
Select the desired language with the ▲ ▼ key and press ENTER to activate. The current active language is indicated with a selected radio button Image 6-9 Language selection Language selection via OSD 1. Press Menu to activate the menus and select Projector Control → Change Language. R5905032 HDX SERIES 16/06/2015...
Page 73 3. Select the desired language with the ▲ ▼ key and press ENTER to activate. The current active language is indicated with a selected radio button Image 6-10 Main menu, projector control Image 6-11 Projector control, change language Image 6-12 Language selection R5905032 HDX SERIES 16/06/2015...
Page 74 6. Quick set up adjustment R5905032 HDX SERIES 16/06/2015...
Page 75: Start Up Of The Adjustment Mode
To start up the adjustment mode, use the remote control or the local keypad. How to start up? 1. Press Menu on the remote control (RCU) or on the local keypad to start up the Adjustment mode. R5905032 HDX SERIES 16/06/2015...
Page 76: Navigation And Adjustments
Direct adjustment within the menu: Image 7-2 Image settings, contrast Use the ◄ or ► key to directly adjust the current value. Via bar scale adjustment : Once an item is selected, press ENTER to open the bar scale menu. R5905032 HDX SERIES 16/06/2015...
Page 77: Menu Memory
Scroll to the desired menu. Press the digit key behind which the menu must be stored for 5 seconds. When the creation is success- fully, a conﬁrmation message appears on the screen. E.g. : Image 7-4 Select Yes to conﬁrm the creation. To erase the shortcut, navigate to Projector Control → Buttons. R5905032 HDX SERIES 16/06/2015...
Page 78: Test Patterns In Adjustment Mode
MENU EXIT ENTER Image 7-6 Info button When no information is available for the selected item, the message No help available for this item is displayed. To return to the adjustment mode, press EXIT. R5905032 HDX SERIES 16/06/2015...
Page 79: Input
Input 2 DUAL SDI Input Locking Input on Main Window Input on Pip Window Input 1 Input 2 Input 3 Input 4 Free Run Free Run Options Minimum delay Native Resolution [On/Off] No Signal Color [black/blue] R5905032 HDX SERIES 16/06/2015...
Page 80: Input Selection
The Select Source menu is displayed with the actual available sources ﬁlled out. 3. Use the ▲ or ▼ key to select an input. Image 8-1 Main window Image 8-2 Input selection Image 8-3 Select source R5905032 HDX SERIES 16/06/2015...
Page 81: Advanced Settings
3. Use the ▲ or ▼ key to select an input Press ENTER to open the selection menu which will be different from input type to input type. Image 8-4 Main window Image 8-5 Advanced input settings Image 8-6 Advanced settings, input selection R5905032 HDX SERIES 16/06/2015...
Page 82: Dvi - Rgb Input
The Dual SD/HD/3G-SDI Input can accept standard-deﬁnition (SD), high-deﬁnition (HD) and 3 Gigabit-deﬁnition serial-digital-inter- face (SDI) signals . How to select Select SDI (SD / HD / 3G / Dual) and press ENTER to open the selections R5905032 HDX SERIES 16/06/2015...
Page 83 When Dual HD is selected, it is possible to use Swap links. If Swap links must be used, use the ▲ or ▼ key to select and press ENTER to accept. The check box will be checked. R5905032 HDX SERIES 16/06/2015...
Page 84: Cable Input
With locking to a speciﬁc input, a set of projectors can be kept in sync, no matter what input image is shown. Input locking is grayed out when 3D is active. Input locking is set automatically to the 3D source. R5905032 HDX SERIES 16/06/2015...
Page 85 Free run without changing the user settings. Once the sync is available, it applies again the user settings. Options for Free Run When free run is selected, radio button selected, then the Free Run Options become available. R5905032 HDX SERIES 16/06/2015...
Page 86: Minimum Delay
1. Press Menu to activate the menus and select Input → Minimum delay [On]. Image 8-19 Main menu Image 8-20 Input, minimum delay 2. Press ENTER to toggle between [On] and [Off]. [On] : images displayed with minimum delay [Off] : images displayed without minimum delay R5905032 HDX SERIES 16/06/2015...
Page 87: Native Resolution
1. Press Menu to activate the menus and select Input → Native Resolution [On]. 2. Press ENTER to toggle between [On] and [Off]. [On] : images displayed in native resolution [Off] : images scaled to ﬁll the complete screen R5905032 HDX SERIES 16/06/2015...
Page 88: No Signal
How to set the background color 1. Press Menu to activate the menus and select Input → No Signal. → Color. 2. Press ENTER to toggle between [Blue] or [black]. Image 8-24 Main menu Image 8-25 Input, no signal R5905032 HDX SERIES 16/06/2015...
Page 89: Background Logo
Image 8-28 Input, no signal Image 8-29 No signal, logo A dedicated logo can be loaded via Projector Toolset with a HDX plug-in installed. 8.7.3 Shutdown settings How to change the settings 1. Press Menu to activate the menus and select Input → No Signal. → Shutdown.
Page 90: Shutdown Retarding Time
The retarding time is the time between no signal is detected and the moment that the projector shuts down. How to set the retarding time 1. Press Menu to activate the menus and select Input → No Signal. → Shutdown time (min). Image 8-33 Main menu Image 8-34 Input, no signal R5905032 HDX SERIES 16/06/2015...
Page 91: Auto Dimming
Input, no signal Image 8-38 No signal, auto dimming 2. Press ENTER to toggle between [On] or [Off]. [On] : when no signal, auto dimming is started. [Off] : when no signal, no auto dimming is started. R5905032 HDX SERIES 16/06/2015...
Page 92: Edid
EDID ﬁle. The selection of the EDID ﬁle to be used is made in the Conﬁgure menu. Making your own custom EDID ﬁle(s) is done through Create. Custom EDID ﬁles can be deleted at any time. The Standard EDID includes two timings: 1920x1200@60Hz / 1920x1080@60Hz (for HDX, HDF and APOLLO projectors) and 2048x1080@60Hz / 1920x1080@60Hz (for HDQ projectors).
Page 93: Create Custom Edid File
You can create new custom EDID ﬁles and enter the desired input timings. How to create 1. Press Menu to activate the menus and select Input → EDID → Create. 2. Press ENTER to open the EDID creation menu. Image 8-44 Main menu Image 8-45 Input, EDID R5905032 HDX SERIES 16/06/2015...
Page 94 CVT MB: Coordinated Video Timings Minimum Blanking (not a standard) GTF: Generalized Timing Formula 6. Select the Options. If necessary, scroll down to see extra options. Select or clear the check boxes. Image 8-48 EDID ﬁle creation, options R5905032 HDX SERIES 16/06/2015...
Page 95: Delete A Custom Edid File
3. Use the ▲ or ▼ key to select the ﬁle which must be deleted. Press ENTER to delete. Image 8-52 EDID, delete list Image 8-53 Conﬁrmation A conﬁrmation window opens. 4. Select Yes to delete the ﬁle and press ENTER. R5905032 HDX SERIES 16/06/2015...
Page 96: Delete All Custom Edid File
L-R Synchronisation, Invert 3D sync out 8.9.1 About 3D modes The mentioned menu items in the mode explanation will be explained in detail in the next topics. Settings in the 3D menu are stored per input. R5905032 HDX SERIES 16/06/2015...
Page 97 The 3D Input Module is activated for Dual 3D channel: MENU > Input > 3D > Frame Sequential – Dual channel Possible sources: 2 x DVI , 2 x SDI. If two 3D Input Modules are installed: 2 x HDMI or 2 x DisplayPort. R5905032 HDX SERIES 16/06/2015...
Page 98: Supported Formats
HD formats only. HD formats only. HD formats only. (FHD3D) Max. resolution: Max. resolution: Max. resolution: Max. resolution: 1920x1080@30Hz or 1920x1080@30Hz or 1920x1080@30Hz or 1920x1080@30Hz or 1280x720@60Hz. 1280x720@60Hz. 1280x720@60Hz. 1280x720@60Hz. Progressive only Progressive only Progressive only Progressive only R5905032 HDX SERIES 16/06/2015...
Page 99: Activate 3D
3. For SDI (3G- Level B), IN1 or IN2 of the SDI input can be used. The input settings under MENU -> Input -> Advanced Settings -> SDI/HDSDI/3G must be set to ‘Input 1’ or ‘Input 2’, with or without Priority R5905032 HDX SERIES 16/06/2015...
Page 100: Auto Detection
Side-by-Side Side-by-Side or SENSIO ® Hi-Fi 3D SENSIO ® 3D Decoder – FFC Other Side-by-Side (Half) Top-and-Bottom Top-and-Bottom SENSIO 3D Decoder – FFC ® 4. NA:feedback from SENSIO Autodetect is not applicable in thes cases ® R5905032 HDX SERIES 16/06/2015...
Page 101: Input Type Selection
Top-and-Bottom (Half): One input contains 3D information with half of the resolution. • SENSIO 3D Decoder - FFC: HDMI/DisplayPort (only on 3D input module). ® • Line Alternating (3G-B): SDI only How to select 1. Press Menu to activate the menus and select Input → 3D R5905032 HDX SERIES 16/06/2015...
Page 102: Second Input
2 channels, the second source must be indicated in the 3D menu. This selection is only possible when a 2 channel 3D input is chosen. How to make selection 1. Press Menu to activate the menus and select Input → 3D → Second input. R5905032 HDX SERIES 16/06/2015...
Page 103: L-R Synchronisation, Field Dominance
ﬂashing is introduced and the coupling between the video input signal and the 3D SYNC IN signal must be determined. This setting is stored per input. How to activate 1. Press Menu to activate the menus and select Alignment → 3D Glasses → L/R Synchronisation. R5905032 HDX SERIES 16/06/2015...
Page 104: L-R Synchronisation, Invert 3D Sync Out
What can be done? This menu allows to set the 3D emitter output signal. With Invert 3D sync out we can swap the left and right 3D sync to eliminate a 3D output mismatch with the 3D emitters. R5905032 HDX SERIES 16/06/2015...
Page 105 Right Image 8-76 3D sync out How to toggle 3D SYNC OUT 1. Press Menu to activate the menus and select Alignment → 3D Glasses → L/R Synchronisation. Image 8-77 Main menu Image 8-78 Input, 3D R5905032 HDX SERIES 16/06/2015...
Page 106 [On] : 3D SYNC OUT is the inverted version of the 3D sync signal generated by the processing, allowing to swap left and right eye on the active glasses. [Off] : 3D SYNC OUT is a copy from the 3D sync signal generated by the processing. R5905032 HDX SERIES 16/06/2015...
Page 107: Image
Computer 9300K Video 6500K Film 5400K Broadcast 3200K Custom Balance Input Balance Black Balance White Balance Defaults Aspect ratio 16:9 2.35 1.88 1.85 1.78 1.67 16:10 Custom Timings Horizontal Total Pixels Active pixels Horizontal start Period R5905032 HDX SERIES 16/06/2015...
Page 108: Start Up The Image Adjustments
The contrast function is used to adjust the contrast between the light and the dark areas of the displayed image. It applies a gain to the red, green and blue signals. Contrast adjustment can be done with the Contrast key on the RCU or via the menu structure. R5905032 HDX SERIES 16/06/2015...
Page 109: Brightness
Brightness adjustment can be done with the Brightness key on the RCU or via the menu structure. How to adjust 1. Press Menu to activate the menus and select Image → Image Settings → Brightness. R5905032 HDX SERIES 16/06/2015...
Page 110: Saturation
The saturation function is used to adjust the color saturation levels. Saturation adjustment can be done with the Saturation key on the RCU or via the menu structure. How to adjust 1. Press Menu to activate the menus and select Image → Image Settings → Saturation. R5905032 HDX SERIES 16/06/2015...
Page 111: Phase
When displaying computer patterns or graphics (RGB or YUV signals) which are very detailed (tilting, vertical stripes, etc. ), jitter in picture (mis-sampling) may occur, causing horizontal stripes in portions of the screen. When this jitter occurs, adjust ’Phase’ for optimum image. R5905032 HDX SERIES 16/06/2015...
Page 112 2. Press ENTER to select. Image 9-19 Phase adjustment 3. To change the value directly in the Image Settings window, use the ◄ or ► key or a numeric key 0-9, to adjust as a % of the full range. R5905032 HDX SERIES 16/06/2015...
Page 113: Color Temperature (Fixed Values)
1. Press Menu to activate the menus and select Image → Image Settings → Color Temperature. Image 9-21 Image adjustments Image 9-20 Main menu, Image Image 9-22 Image settings, color temperature 2. Press ENTER to select. R5905032 HDX SERIES 16/06/2015...
Page 114: Color Temperature (Custom Values)
Next to these 5 ﬁxed temperatures, a custom setup is also possible. 9.3.6 Color temperature (custom values) How to set up 1. Press Menu to activate the menus and select Image → Image Settings → Color Temperature. Image 9-26 Image adjustments Image 9-25 Main menu, Image R5905032 HDX SERIES 16/06/2015...
Page 115: Input Balance
Another value that is subject to alteration is the amplitude of the signal, resulting in an altered “Gain” of the signal (“white level” or contrast). The alterations of the three color signals will happen independently i.e. the colors will end to be unbalanced, image 9-30 0.7V Black level Image 9-29 R5905032 HDX SERIES 16/06/2015...
Page 116: Adjusting The Input Balance
The source in question must be able to generate a white signal, ideally a 100% white (background) full screen pattern The source in question must be able to generate a black signal, ideally a 100% black (background) full screen pattern R5905032 HDX SERIES 16/06/2015...
Page 117 Image 9-33 How to adjust 1. Press Menu to activate the menus and select Image → Image Settings → Input Balance. Image 9-35 Image adjustments Image 9-34 Main menu, Image R5905032 HDX SERIES 16/06/2015...
Page 118 Performing White input balance 1. Connect the source you want to project. 2. Press Menu to activate the menus and select Image → Image Settings → Input Balance. Image 9-39 Image adjustments Image 9-38 Main menu, Image R5905032 HDX SERIES 16/06/2015...
Page 119: Image Settings, Defaults
With the defaults button, all image settings for a speciﬁc source are returned to the default values. How to return to the defaults 1. Press Menu to activate the menus and select Image → Image Settings → Defaults. R5905032 HDX SERIES 16/06/2015...
Page 120: Aspect Ratio
What can be done? The aspect ratio setting forces the projector to project an image using a deﬁned aspect ratio. Aspect ratio Description Standard television format 16:9 Wide screen television format / anamorphic format R5905032 HDX SERIES 16/06/2015...
Page 121 1. Press Menu to activate the menus and select Image → Aspect Ratio. Image 9-48 Image, aspect ratio Image 9-47 Main menu, Image 2. Press ENTER to select. 3. Use the ▲ or ▼ key to select the desired aspect ratio. R5905032 HDX SERIES 16/06/2015...
Page 122: Timings
If not, adjust until full image height is displayed (no missing lines). • Total pixels: Total horizontal pixels in the source. If the value is wrong, sampling mistakes (small vertical bars in the projected image) will be seen in the image. R5905032 HDX SERIES 16/06/2015...
Page 123: Advanced Timings, Clamp Delay - Clamp Width
The time between the trailing edge of the sync pulse and the leading edge of the clamp pulse, in pixels. Can be any value between 0 and 255. The width of the clamp pulse can be any value between 0 and 255. Clamp width R5905032 HDX SERIES 16/06/2015...
Page 124 1. Press Menu to activate the menus and select Image → Timings → Advanced settings. Image 9-57 Image, timings Image 9-56 Main menu, Image Image 9-58 Timings, advanced settings 2. Press ENTER to select. Image 9-59 Clamp delay R5905032 HDX SERIES 16/06/2015...
Page 125: Image File Services
1. Press Menu to activate the menus and select Image → Image File Services → Manual Load. Image 9-61 Image, image ﬁle services Image 9-60 Main menu, Image Image 9-62 Image ﬁle services 2. Press ENTER to select. R5905032 HDX SERIES 16/06/2015...
Page 126: File Load Filter
File load ﬁlter 2. Press ENTER to toggle between [All] and [Fit]. 9.6.4 Delete a ﬁle What can be done ? A custom image ﬁle can be deleted. Be aware that an active ﬁle can’t be deleted. R5905032 HDX SERIES 16/06/2015...
Page 127 If no custom ﬁles are available, a message that no custom ﬁles are available is displayed. 3. Use the ▲ or ▼ key to select the ﬁle to delete. Image 9-70 Delete custom ﬁle 4. Press ENTER to delete the selected ﬁle. No recovery possible ! R5905032 HDX SERIES 16/06/2015...
Page 128: Delete All Custom Files
Delete all 3. If Yes is selected, press ENTER to delete all custom ﬁles. If No is selected, press ENTER to return to the Image File Services menu without deleting any custom ﬁle. No recovery possible ! R5905032 HDX SERIES 16/06/2015...
Page 129: Rename Custom Files
If no custom ﬁles are available, a message that no custom ﬁles are available is displayed. Image 9-78 Rename, list of ﬁles 3. Use the ▲ or ▼ key to select the ﬁle to rename and press ENTER. R5905032 HDX SERIES 16/06/2015...
Page 130: Copy Custom File
1. Press Menu to activate the menus and select Image → Image File Services → Copy. Image 9-81 Image, image ﬁle services Image 9-80 Main menu, Image Image 9-82 Image ﬁle services, copy 2. Press ENTER to select. The available custom ﬁles are displayed. R5905032 HDX SERIES 16/06/2015...
Page 131: Image File Service Options, Load File
Image ﬁle service options, Load ﬁle How to set 1. Press Menu to activate the menus and select Image → Image File Services → Options → Load File. Image 9-87 Image, image ﬁle services Image 9-86 Main menu, Image R5905032 HDX SERIES 16/06/2015...
Page 132: Image File Service Options, Auto Picture Alignment
2. Press ENTER to toggle between [Off], [Always] or [Load File]. Off : auto picture alignment deactivated. Always : auto picture alignment is always activated. Load ﬁle: when new ﬁle is loaded for the selected source. R5905032 HDX SERIES 16/06/2015...
Page 133: Save Custom Settings
A splash image can be uploaded via Projector Toolset. For more information about uploading a splash image, consult Projector Toolset’s user guide. Enable or disable the splash image 1. Press Menu to activate the menus and select Image → Splash image R5905032 HDX SERIES 16/06/2015...
Page 134 Image 9-100 Main menu, Image 2. Select Timeout(sec) Image 9-102 Splash screen, time-out 3. Press ENTER to open the edit mode. Enter the time with 2 digits, e.g. 05 or 15. Note: Maximum timeout = 15 seconds. R5905032 HDX SERIES 16/06/2015...
Page 135 9. Image Image 9-103 Time-out, input R5905032 HDX SERIES 16/06/2015...
Page 136 9. Image R5905032 HDX SERIES 16/06/2015...
Page 137: Layout
Layout ﬁles determine the size and the position of the main and PiP window on the screen. Some pre-deﬁned layouts are available in the projector but custom layouts can be created and saved for future use. A source number and lens settings can be associated with the layout settings. R5905032 HDX SERIES 16/06/2015...
Page 138: Main Window
Image 10-5 Select source 3. Use the ▲ or ▼ key to select the desired source and press ENTER. The radio button of the selected source is checked and the source is linked with the main window. R5905032 HDX SERIES 16/06/2015...
Page 139: Main Window Size
How to change the size 1. Press Menu to activate the menus and select Layout → Main window → Size. Image 10-8 Layout, main window Image 10-7 Main menu, layout Image 10-9 Main window, size 2. Press ENTER to select. R5905032 HDX SERIES 16/06/2015...
Page 140: Main Window Position
The main window can be repositioned on the screen. The upper left corner is the reference. Image 10-12 Positioning the window How to position 1. Press Menu to activate the menus and select Layout → Main window → Position. R5905032 HDX SERIES 16/06/2015...
Page 141: Pip Window
Select No if you want to quit without saving the current position. 10.4 PiP window Overview • Introduction to PIP • Picture in Picture activation • PiP window, source selection • PiP window, Size • PiP window, position R5905032 HDX SERIES 16/06/2015...
Page 142: Introduction To Pip
10.4.2 Picture in Picture activation How to activate 1. Press Menu to activate the menus and select Layout → PiP window → PiP window [On] / [Off]. Image 10-20 Layout, PiP Window Image 10-19 Main menu, layout R5905032 HDX SERIES 16/06/2015...
Page 143: Pip Window, Source Selection
3. Use the ▲ or ▼ key to select the desired source and press ENTER. The radio button of the selected source is checked and the source is linked with the PiP window. PiP source and main source can be the same input. R5905032 HDX SERIES 16/06/2015...
Page 144: Pip Window, Size
Remark: During adjustment of the window size, scaling artifacts can be visible. Image 10-27 Size PIP window remark How to resize 1. Press Menu to activate the menus and select Layout → PiP window → Size. Image 10-29 Layout, PiP Window Image 10-28 Main menu, layout R5905032 HDX SERIES 16/06/2015...
Page 145: Pip Window, Position
The picture in picture window can be positioned on any place on the display just by changing its start coordinates. The reference is the upper left corner of the window. How to position 1. Press Menu to activate the menus and select Layout → PiP window → Position. R5905032 HDX SERIES 16/06/2015...
Page 146 A Save Layout window opens. Image 10-37 Save layout 5. Use the ▲ or ▼ key to select Yes and press ENTER to save. Select No if you want to quit without saving the current position. R5905032 HDX SERIES 16/06/2015...
Page 147: Layout File Services
Layout ﬁle services, load 2. Press ENTER to select. The Load layout overview window opens. Image 10-41 Load layout ﬁle list 3. Use the ▲ or ▼ key to select the desired ﬁle and press ENTER to activate. R5905032 HDX SERIES 16/06/2015...
Page 148: Rename Layout File
Note: Digits can be entered with the digit keys on the remote control or the local keypad. When a digit is entered in that way, the next character will be selected automatically. Arrow key left (◄) has the backspace functionality. 10.5.3 Delete layout ﬁle Only custom created layouts can be deleted. The current selected custom layout cannot be deleted. R5905032 HDX SERIES 16/06/2015...
Page 149: Delete All Layout Files
4. Use the ▲ or ▼ key to select Yes and press ENTER to delete the custom layout. Select No if you want to quit without deleting the custom ﬁle. 10.5.4 Delete all layout ﬁles Only custom layout ﬁles can be deleted. The current selected custom layout cannot be deleted. R5905032 HDX SERIES 16/06/2015...
Page 150: Copy Or Save As Layout File
The current loaded layout, custom layout or custom created layout, can be copied into a new ﬁle. How to copy / save as 1. Press Menu to activate the menus and select Layout → Layout File Services → Copy/Save as. R5905032 HDX SERIES 16/06/2015...
Page 151: Lens Behavior
Switching from a custom ﬁle (layout) to a standard ﬁle (layout) will not change the current lens settings. How to set the lens behavior 1. Press Menu to activate the menus and select Layout → Lens behavior. R5905032 HDX SERIES 16/06/2015...
Page 152 5. If you have to calibrate the lens, select Yes and press ENTER to start the calibration. During the calibration, a message is displayed. This message disappears when the calibration is ﬁnished. Image 10-63 Lens calibration message R5905032 HDX SERIES 16/06/2015...
Page 153: Lamp
CLO mode. Once the CLO mode setting is switched to Off, the installed lamp power mode setting will be used. How to switch 1. Press Menu to activate the menus and select Lamp → Power → Mode. R5905032 HDX SERIES 16/06/2015...
Page 154: Lamp Power
This function is a duplicate of the Auto dimming in the Input menu. How to set up 1. Press Menu to activate the menus and select Lamp → Power → Auto Dimming No Signal. R5905032 HDX SERIES 16/06/2015...
Page 155: Auto Dimming When Over-Temperature
In the illustration below, a normal light output curve is shown over the ﬁrst 1000 hours, image 11-16. By using CLO and setting the target to 60% of the maximum light output, one will be able to operate during approximately 500 hours with a constant light output, image 11-17. R5905032 HDX SERIES 16/06/2015...
Page 156 1. Press Menu to activate the menus and select Lamp → Power → CLO mode. Image 11-18 Image 11-19 Main menu, lamp Lamp, power Image 11-20 Power, CLO mode 2. Press ENTER to toggle between [On] or [Off]. R5905032 HDX SERIES 16/06/2015...
Page 157: Clo Targets
These parameters are useful in case of a service request. How to display 1. Press Menu to activate the menus and select Lamp → Identiﬁcation. Image 11-25 Image 11-26 Main menu, lamp Lamp, identiﬁcation 2. Press ENTER to select. Image 11-27 Lamp identiﬁcation R5905032 HDX SERIES 16/06/2015...
Page 158: Z-Axis Adjustment
How to display the light output 1. Press Menu to activate the menus and select Lamp → Z-axis. Image 11-28 Image 11-29 Main menu, lamp Lamp, Z-axis 2. Press ENTER to display the current light output. Image 11-30 Current light output R5905032 HDX SERIES 16/06/2015...
Page 159: Alignment
Auto Front Auto Rear Lens Zoom / Focus Shift Mid Position Calibrate lens at startup Calibrate Warping Status Warp adjust Opacity Warp ﬁle service Alternative Side Keystone Blanking Bottom Left Right Contrast/Intensity Intensity Gamma Internal Patterns R5905032 HDX SERIES 16/06/2015...
Page 160: Orientation
: automatic rear, projector detects itself if it is ceiling or table mounted and projects always a readable image. How to set the correct orientation 1. Press Menu to activate the menus and select Alignment → Orientation. R5905032 HDX SERIES 16/06/2015...
Page 161: Lens Adjustment, Zoom - Focus
1. Press Menu to activate the menus and select Alignment → Lens. Image 12-4 Main menu, alignment Image 12-5 Alignment, lens 2. Use the ▲ or ▼ key to select zoom/focus and press ENTER to activate. R5905032 HDX SERIES 16/06/2015...
Page 162: Lens Adjustment, Shift
1. Press Menu to activate the menus and select Alignment → Lens. Image 12-8 Main menu, alignment Image 12-9 Alignment, lens 2. Use the ▲ or ▼ key to select Shift and press ENTER to activate. Image 12-10 Lens, shift R5905032 HDX SERIES 16/06/2015...
Page 163: Lens Adjustment, Mid Position
Lens will be shifted horizontally and vertically to its mid position. 12.6 Calbrate lens at startup About calibrating lens Each time the projector is started, a homing procedure (calibration) can be executed so that the projector exactly knows the lens position. R5905032 HDX SERIES 16/06/2015...
Page 164: Calibrate Lens
2. Use the ▲ or ▼ key to select Calibrate lens at startup and press ENTER to toggle between [on] and [off]. Image 12-17 Calibrate lens at startup 12.7 Calibrate lens Lens calibration is a time consuming operation. How to calibrate 1. Press Menu to activate the menus and select Alignment → Lens. R5905032 HDX SERIES 16/06/2015...
Page 165: Warping
A Lens Calibration window opens. Select ﬁrst the desired calibration options by checking the check box before the option and then select Yes to start the calibration procedure. Image 12-21 Calibrate lens conﬁrmation 12.8 Warping Not all models are equipped with a warping unit. For these models, the warping unit is optional. R5905032 HDX SERIES 16/06/2015...
Page 166: About Warping
12.8.2 Warp activation - deactivation What can be done ? The Warp functionality can be activated or deactivated. With 3D activated, warping can be enabled for sources up to 30 Hz per eye. Above this frequency, warping is disabled. R5905032 HDX SERIES 16/06/2015...
Page 167: Start Up Manual Adjustment
It opens more and more panes depending on the selection. When manual warping was done before the menu opens with the same layout as it was last used. A warp grid and adjustment points is displayed on the screen. The maximum grid is 32 points by 32 points. R5905032 HDX SERIES 16/06/2015...
Page 168: Warp Adjustment Principle
Hardware reset of warp module 12.8.4 Warp adjustment principle Description Warping adjustment enables the relocation of pixel groups in an image in order to introduce spacial distortion. To make the procedure comprehensible, there are some rules and features. R5905032 HDX SERIES 16/06/2015...
Page 169 7 and lower. In 2 x 2 mode, we only have one level, including all four (2 x 2) anchor points, being the image corners. This mode is especially used to correct horizontal and vertical keystone. R5905032 HDX SERIES 16/06/2015...
Page 170 1 1 1 Image 12-36 Geometry adjustment: 5 x 5 mode This logic can be extrapolated for the lower modes and levels, being level seven to level 21, however in practice these modes and levels are rarely used. R5905032 HDX SERIES 16/06/2015...
Page 171: Setting The Warping Level
How to select a predeﬁned number of steps 1. Use the ▲ or ▼ key to go to the Warp adaptation steps area. The current selection is indicated in yellow. 2. Use the ◄ or ► key to select the desired steps. R5905032 HDX SERIES 16/06/2015...
Page 172: Making Selections And Adjustments
Warp mode. keystone, horizontal linearity, points, scale, shift, rotation, rotation point. Warp adaptation: this pane changes according to the warp mode selection. 2. Within a pane, use the ◄ or ► key to select the desired function. 3. Press ENTER to activate this function. R5905032 HDX SERIES 16/06/2015...
Page 173: Keystone Correction Workﬂow
2. Select the desired warp area. Depending on the selected area only the points in that area will be adjusted. 3. Select keystone. 4. Select within Warp Adaptations, Horizontal or Vertical to adjust the corresponding keystone. R5905032 HDX SERIES 16/06/2015...
Page 174: Linearity Adjustment, Workﬂow
ENTER when an item is selected and use the 4 arrow keys to adjust. Image 12-45 Warping, Linearity 5. Adjust the horizontal and vertical linearity. To ﬁne tune this adjustment, select a speciﬁc area and add extra anchor points by changing the warp level. R5905032 HDX SERIES 16/06/2015...
Page 175: Selecting And Changing The Position Of A Speciﬁc Point
How to scale 1. Select the 2 x 2 adjustment level. See "Setting the warping level", page 167. The default selected anchor point is the left top corner of the image. 2. Select the desired warp area. R5905032 HDX SERIES 16/06/2015...
Page 176: Shifting The Image
The image can be rotated around a predeﬁned point. This is considered as an equal rotation of the 4 corner points in 2 x 2 mode and with the full area selected. The default rotation point is the center of the image. R5905032 HDX SERIES 16/06/2015...
Page 177 Image 12-53 Warping, scaling 4. Continue with the rotation. Rotate around the rotation point 1. Select the 2 x 2 adjustment level. See "Setting the warping level", page 167. 2. Select full image as warp area. R5905032 HDX SERIES 16/06/2015...
Page 178: Hardware Reset
About the opacity of the OSD menus During the warp adjustment process the OSD menu is displayed on top the warp grid. To see the grid and the grid points, reduce the opacity of the OSD menu. R5905032 HDX SERIES 16/06/2015...
Page 179: Warp File Service, Load File
2. Use the ◄ or ► key to change the opacity. 12.8.16 Warp ﬁle service, load ﬁle What can be done? A predeﬁned warp conﬁguration can be loaded in the warp board as active warp conﬁguration ﬁle. R5905032 HDX SERIES 16/06/2015...
Page 180: Warp File Service, Save To File
Warp ﬁles 3. Use the ▲ or ▼ key to select the desired ﬁle. 12.8.17 Warp ﬁle service, save to ﬁle What can be done? The current warp settings are saved in the current active ﬁle R5905032 HDX SERIES 16/06/2015...
Page 181: Warp File Service, Save As
What can be done? The current settings can be saved into a new ﬁle. How to save 1. Press Menu to activate the menus and select Alignment → Warping → .Warp File Service → .Save as. R5905032 HDX SERIES 16/06/2015...
Page 182: Warp File Service, Rename File
4. Press ENTER to ﬁnalize the save as action. 12.8.19 Warp ﬁle service, rename ﬁle How to rename? 1. Press Menu to activate the menus and select Alignment → Warping → .Warp File Service → .Rename. R5905032 HDX SERIES 16/06/2015...
Page 183: Warp File Service, Delete File
Arrow key left (◄) has the backspace functionality. 5. Press ENTER to ﬁnalize the rename action. 12.8.20 Warp ﬁle service, delete ﬁle How to delete 1. Press Menu to activate the menus and select Alignment → Warping → .Warp File Service → .Delete. R5905032 HDX SERIES 16/06/2015...
Page 184: Warp File Service, Delete All Files
12.8.21 Warp ﬁle service, delete all ﬁles What can be done? All custom created warp ﬁles can be deleted. How to delete 1. Press Menu to activate the menus and select Alignment → Warping → .Warp File Service → .Delete All. R5905032 HDX SERIES 16/06/2015...
Page 185: Warp Board Reset
In some circumstances the hardware of the warping get stuck. A hard reset of the board is the only solution. With Warp board reset, the board is reset but the current values remain in the board. How to reset the board 1. Press Menu to activate the menus and select Alignment → Warping → .Warp board reset. R5905032 HDX SERIES 16/06/2015...
Page 186: Warp Board And Values Reset
How to reset board and values 1. Press Menu to activate the menus and select Alignment → Warping → .Warp board and values reset. R5905032 HDX SERIES 16/06/2015...
Page 187: Alternative Side Keystone
For 3D sources with a frequency higher than 30 Hz/eye, the warp unit cannot be used anymore. Therefor, for these source the alternative side keystone can be used. How to adjust 1. Press Menu to activate the menus and select Alignment → Warping → .Alternative Side Keystone. R5905032 HDX SERIES 16/06/2015...
Page 188: Blanking Adjustment
(or noise). A ’0’ on the bar scale indicates no blanking. Which blanking adjustments are available ? • top blanking • bottom blanking • left blanking • right blanking R5905032 HDX SERIES 16/06/2015...
Page 189 The reset function brings all blanking settings back to zero. How to adjust 1. Press Menu to activate the menus and select Alignment → Blanking. Image 12-101 Main menu, alignment Image 12-102 Alignment, blanking 2. Press ENTER to select. R5905032 HDX SERIES 16/06/2015...
Page 190: Contrast-Intensity
Contrast enhancement Contrast enhancement 3. Use the ▲ or ▼ key to select Contrast Enhancement. Use the ◄ or ► key to change the contrast enhancement until the desired value is reached (adjustable between 0 and 5) R5905032 HDX SERIES 16/06/2015...
Page 191: Gamma
How to select a pattern 1. Press Menu to activate the menus and select Alignment → Internal Patterns. Image 12-110 Image 12-111 Main menu, alignment Main menu, alignment 2. Press ENTER to select the pattern list. R5905032 HDX SERIES 16/06/2015...
Page 192: Color Space
This color space is measured at the factory and stored inside the projector. How to select a color standard 1. Press Menu to activate the menus and select Alignment → Color Space. R5905032 HDX SERIES 16/06/2015...
Page 193 American standard. Custom The user can deﬁne the x and y coordinates for red, green and blue which forms the corners of the color space. By changing the coordinates, the color reproduction can be changed. Custom2 R5905032 HDX SERIES 16/06/2015...
Page 194: Scenergix
12.14.1 Introduction Why ScenergiX ? When working in a multichannel setup the HDX and its Soft Edge possibilities enable an image blending that gives the appearance of a single view, thus achieving realistic immersion for the majority of wide screen applications.
Page 195: Preparations
Color Matching (Color Temperature, Color Standard, Input Balance, Gamma) 12.14.3 Scenergix activation How to activate 1. Press Menu to activate the menus and select Alignment → Scenergix. Image 12-121 Main menu, alignment Image 12-122 Alignment, Scenergix 2. Press ENTER to select. R5905032 HDX SERIES 16/06/2015...
Page 196: Scenergix Pattern
To make the Scenergix adjustment more easy, an internal pattern can be displayed. How to select 1. Press Menu to activate the menus and select Alignment → Scenergix → Scenergix Pattern. Image 12-124 Main menu, alignment Image 12-125 Alignment, Scenergix Image 12-126 Scenergix, pattern activation R5905032 HDX SERIES 16/06/2015...
Page 197: Scenergix Adjustment Lines
Adjustment lines can be activated when Scenergix pattern is [On]. How to display 1. Press Menu to activate the menus and select Alignment → Scenergix → Adjust lines. Image 12-128 Main menu, alignment Image 12-129 Alignment, Scenergix R5905032 HDX SERIES 16/06/2015...
Page 198: Data Doubling
The overlap area can be adjusted with the Scenergix tools. Hor. Hor. Start 1 Start 2 Size 2 Size 1 Vert. Start 1&2 Projector 2 Projector 1 Image 12-131 Data doubling Source R5905032 HDX SERIES 16/06/2015...
Page 199: White Level Adjustment (Blending Area)
4. Do the same for Horizontal Size, Vertical Start and Vertical Size. 5. Repeat this action for he second projector. 12.14.7 White level adjustment (blending area) How to set 1. Press Menu to activate the menus and select Alignment → Scenergix → White level. R5905032 HDX SERIES 16/06/2015...
Page 200 3. Use the ▲ or ▼ key to select one of the four size adjustments and press ENTER to select Use the ◄ or ► key to change the border of the blending area to the desired position (value between 0 and 255) R5905032 HDX SERIES 16/06/2015...
Page 201 12. Alignment Image 12-140 Width selections 4. Set ﬁrst the width for the ﬁrst projector and repeat for the second one. Image 12-141 Width set up for projector 1 R5905032 HDX SERIES 16/06/2015...
Page 202: Black Level Adjustment
After the area is set, use TEXT key to remove the area border lines when adjusting the black level. How to set the leakage area width 1. Press Menu to activate the menus and select Alignment → Scenergix → Black level. R5905032 HDX SERIES 16/06/2015...
Page 203 Image 12-147 Black level, area 3. Use the ▲ or ▼ key to select one of the four size adjustments. Use the ◄ or ► key to move the green border line to the desired position. R5905032 HDX SERIES 16/06/2015...
Page 204 Use the Reset item to reset all area values. How to adjust 1. Press Menu to activate the menus and select Alignment → Scenergix → Black level. Image 12-149 Main menu, alignment Image 12-150 Alignment, Scenergix R5905032 HDX SERIES 16/06/2015...
Page 205: Scenergix Reset
Image 1 Image 12-153 Black level adjustment Use the Reset item to set all values back to zero. 12.14.9 Scenergix Reset What can be done? All Scenergix values can be set back to the default values. R5905032 HDX SERIES 16/06/2015...
Page 206: Glasses
The right image is projected, the right shutter is open, allowing the right eye to see the right image. The ideal situation is when the opening/closing times of these shutters are in sync with the blanking time of DLP mirrors. R5905032 HDX SERIES 16/06/2015...
Page 207 Active Blanking Time Left Shutter Open Closed Right Shutter Open Closed Image 12-158 Shutters closing too late and/or opening too early cause Cross-Talk Closing these shutters too quickly and/or opening too slowly will cause Color Artifacts. R5905032 HDX SERIES 16/06/2015...
Page 208 1. Press Menu to activate the menus and select Alignment → 3D Glasses . Image 12-160 Main window Image 12-161 Alignment, 3D glasses 2. Press ENTER. 3. Use the ▲ or ▼ key to select Dark Time Adjustment R5905032 HDX SERIES 16/06/2015...
Page 209: Left-Right Output Reference Delay
Right Delay Time With output reference delay Left 3D Sync Right Image 12-163 3D Output reference delay How to set the delay 1. Press Menu to activate the menus and select Alignment → 3D Glasses . R5905032 HDX SERIES 16/06/2015...
Page 210: Sync Loop Through
12.15.3 3D Sync Loop Through What can be done? The incoming 3D sync signal can routed to the 3D sync output connector. How to activate 1. Press Menu to activate the menus and select Alignment → 3D Glasses. R5905032 HDX SERIES 16/06/2015...
Page 211: Upper Limit For Triple Or Double Flash
The Upper limit for double ﬂash can be set. When the input frame rates are below this limit, the result will be displayed at double frame rate. How to set the limit 1. Press Menu to activate the menus and select Alignment → 3D Glasses. R5905032 HDX SERIES 16/06/2015...
Page 212: High End Systems Mirror
Almost any image can be displayed on almost any place in the room using the pan and tilt adjustments. Settings storing per layout is possible. Projector control activation 1. Press Menu to activate the menus and select Alignment → High End Systems Mirror. R5905032 HDX SERIES 16/06/2015...
Page 213 1. Use the ▲ or ▼ key to select Coarse Pan or Coarse Tilt. Image 12-176 Projector Controlled 2. Use the ◄ or ► key to change the value between -128 and 128. 3. Use the ▲ or ▼ key to select Fine Pan or Fine Tilt. R5905032 HDX SERIES 16/06/2015...
Page 214 1. To change the store settings, use the ▲ or ▼ key to select Store settings per layout and press ENTER to toggle between [No] and [Yes]. Image 12-177 Store settings [No] : settings are stored globally. [Yes] : settings are stored per layout. R5905032 HDX SERIES 16/06/2015...
Page 215: Projector Control
DHCP [On] [Off] IP address Subnet mask Default gateway Wireless Status DHCP IP address Subnet mask IR Control IR front IR back IR side Address Universe Mode Art DMX [On/Off] Output voltage enable Output voltage level Monitor Shutdown R5905032 HDX SERIES 16/06/2015...
Page 216: Individual Projector Address
1. Press Menu to activate the menus and select Projector Control → Projector Address → Projector Address. Image 13-1 Main menu, projector control Image 13-2 Projector control, projector address Image 13-3 Projector address 2. Press ENTER to activate the address input. R5905032 HDX SERIES 16/06/2015...
Page 217: Projector Common Address
1. Press Menu to activate the menus and select Projector Control → Projector Address → Common Address. Image 13-5 Main menu, projector control Image 13-6 Projector control, projector address Image 13-7 Projector address, common address 2. Press ENTER to activate the address input. Image 13-8 Projector common address R5905032 HDX SERIES 16/06/2015...
Page 218: Serial Communication
The communication protocol for the communication between the projector and a computer can be set to RS232 or RS422. How to set up 1. Press Menu to activate the menus and select Projector Control → Serial Communication. R5905032 HDX SERIES 16/06/2015...
Page 219: Network
IP address must be entered. DHCP lets a network administrator supervise and distribute IP addresses from a central point and automatically sends a new IP address when a computer is plugged into a different place in the network. R5905032 HDX SERIES 16/06/2015...
Page 220: Wired Dhcp Set Up
ﬁeld to any IP-Address on the subnet. 13.5.2 Wired DHCP set up How to set up 1. Press Menu to activate the menus and select Projector Control → Network. Image 13-15 Main menu, projector control Image 13-16 Projector control, network R5905032 HDX SERIES 16/06/2015...
Page 221: Wired Ip Address Set Up
[Off] : DHCP is deactivated. A ﬁxed address must be used. 13.5.3 Wired IP address set up How to set up 1. Press Menu to activate the menus and select Projector Control → Network. Image 13-18 Main menu, projector control Image 13-19 Projector control, network R5905032 HDX SERIES 16/06/2015...
Page 222: Wired Subnet Mask Set Up
13.5.4 Wired subnet mask set up Subnet for Wired and Wiﬁ must be different ! How to set up 1. Press Menu to activate the menus and select Projector Control → Network. R5905032 HDX SERIES 16/06/2015...
Page 223 2. Use the ▲ or ▼ key to select Subnet Mask under Wired and press ENTER to activate the input box. Image 13-25 Fill subnet mask Image 13-26 Fill subnet mask 3. Use the ▲ or ▼ key to change the selected character. R5905032 HDX SERIES 16/06/2015...
Page 224: Wired Default Gateway Set Up
Image 13-27 Main menu, projector control Image 13-28 Projector control, network Image 13-29 Network, default gateway 2. Use the ▲ or ▼ key to select Default Gateway under Wired and press ENTER to activate the input box. R5905032 HDX SERIES 16/06/2015...
Page 225: Wireless Network Activation
Before a wireless network can be used, the status must be set to On. How to activate 1. Press Menu to activate the menus and select Projector Control → Network → Wireless setup. Image 13-31 Main menu, projector control Image 13-32 Projector control, network R5905032 HDX SERIES 16/06/2015...
Page 226: Wireless Access Points Selection And Setup
13.5.7 Wireless access points selection and setup These menu items are only accessible when wireless network status is set to [on]. Scan for access points 1. Select Scan access points and press ENTER to start the scan. R5905032 HDX SERIES 16/06/2015...
Page 227 Access to a wireless secured access point 1. Use the ▲ or ▼ key to select Passphrase. For a secured network, a passphrase should be entered before getting access to the wireless network. Image 13-37 Image 13-38 Passprhrase, selection Passphrase, entry R5905032 HDX SERIES 16/06/2015...
Page 228: Wireless Dhcp Set Up
Can only be used with a wireless network module installed. How to set up 1. Press Menu to activate the menus and select Projector Control → Network → Wireless Setup . Image 13-40 Main menu, projector control Image 13-41 Projector control, network R5905032 HDX SERIES 16/06/2015...
Page 229: Wireless Fixed Ip Address Set Up
Can only be used with a wireless network module installed. How to set up 1. Press Menu to activate the menus and select Projector Control → Network → Wireless Setup. Image 13-44 Main menu, projector control Image 13-45 Projector control, network R5905032 HDX SERIES 16/06/2015...
Page 230: Wireless Subnet Mask Set Up
Can only be used with a wireless network module installed. Subnet for Wired and Wiﬁ must be different ! How to set up 1. Press Menu to activate the menus and select Projector Control → Network → Wireless Setup. R5905032 HDX SERIES 16/06/2015...
Page 231 3. Use the ▲ or ▼ key to select Subnet Mask and press ENTER to activate the input box. Image 13-53 Wireless Subnet Mask, input 4. Use the ▲ or ▼ key to change the selected character. R5905032 HDX SERIES 16/06/2015...
Page 232: Wireless Default Gateway Set Up
Image 13-57 Image 13-56 Wireless default gateway Network, wireless 2. Press ENTER to open the Wireless menu. 3. Use the ▲ or ▼ key to select Subnet Mask and press ENTER to activate the input box. R5905032 HDX SERIES 16/06/2015...
Page 233: Ir Control Switching
IR receiver will be processed. How to activate or deactivate 1. Press Menu to activate the menus and select Projector Control → IR control. Image 13-59 Main menu, projector control Image 13-60 Projector control, IR control R5905032 HDX SERIES 16/06/2015...
Page 234: Dmx
Before a projector can execute DMX commands, a unique address, called DMX address, should be given to the projector. This address can vary from 1 to 512. How to set the DMX address 1. Press Menu to activate the menus and select Projector Control → DMX → Address. R5905032 HDX SERIES 16/06/2015...
Page 235 Use the ◄ or ► key to select another character. Note: Digits can be entered with the digit keys on the remote control or the local keypad. When a digit is entered in that way, the next character will be selected automatically. R5905032 HDX SERIES 16/06/2015...
Page 236: Dmx Universe
How to set a DMX universe 1. Press Menu to activate the menus and select Projector Control → DMX → Universe. Image 13-67 Main menu, projector control Image 13-68 Projector control, DMX Image 13-69 DMX, universe 2. Press ENTER to select. R5905032 HDX SERIES 16/06/2015...
Page 237: Dmx Mode
Depending on the DMX application the correct mode has to be selected. How to set the mode 1. Press Menu to activate the menus and select Projector Control → DMX → Universe. Image 13-71 Main menu, projector control Image 13-72 Projector control, DMX R5905032 HDX SERIES 16/06/2015...
Page 238: Art-Net Dmx
Art-Net DMX [Off] : DMX via Ethernet is disabled. How to toggle 1. Press Menu to activate the menus and select Projector Control → DMX → Art-Net DMX. Image 13-74 Main menu, projector control Image 13-75 Projector control, DMX R5905032 HDX SERIES 16/06/2015...
Page 239: Front Xlr Output Voltage Control
DMX Art-Net, set level to 0 V How to enable or disable 1. Press Menu to activate the menus and select Projector Control → DMX → Output voltage enable. Image 13-77 Main menu, projector control Image 13-78 Projector control, DMX R5905032 HDX SERIES 16/06/2015...
Page 240 1. Press Menu to activate the menus and select Projector Control → DMX → Output voltage level. Image 13-80 Main menu, projector control Image 13-81 Projector control, DMX Image 13-82 Front XLR output voltage level 2. Press ENTER to toggle between [0 Volt], [9 Volt], [12 Volt] and [24 Volt]. R5905032 HDX SERIES 16/06/2015...
Page 241: Monitor
1. Press Menu to activate the menus and select Projector Control → DMX → Monitor. Image 13-83 Main menu, projector control Image 13-84 Projector control, DMX Image 13-85 DMX monitor 2. Press ENTER to open the overview list. Image 13-86 DMX overview list R5905032 HDX SERIES 16/06/2015...
Page 242: Dmx Shutdown
The retarding time is the time between no DMX is detected and the moment that the projector shuts down. How to set the retarding time 1. Press Menu to activate the menus and select Projector Control → DMX → Shutdown Time. R5905032 HDX SERIES 16/06/2015...
Page 243: Buttons
In ECO standby only the microcontroller, communication interface and local (or remote) control are operational. All other electronics are powered down. How to set 1. Press Menu to activate the menus and select Projector Control → Buttons → Standby. R5905032 HDX SERIES 16/06/2015...
Page 244: Shortcut Keys
The allocated shortcut keys can be cleared within this menu. How to clear a shortcut key 1. Press Menu to activate the menus and select Projector Control → Buttons → Shortcut keys. Image 13-96 Main menu, projector control Image 13-97 Projector control, buttons R5905032 HDX SERIES 16/06/2015...
Page 245: Menu Position
Left-top • Left-mid • Left-bottom How to change the position 1. Press Menu to activate the menus and select Projector Control → Menu Position. Image 13-100 Main menu, projector control Image 13-101 Projector control, menu position R5905032 HDX SERIES 16/06/2015...
Page 246: Local Lcd
3. Use the ◄ or ► key to change the back lighting of the local LCD panel. 4. Use the ▲ or ▼ key to select Time out. Image 13-106 Local LCD, time out 5. Press ENTER to toggle between [Off], [10], [30], [60] or [120]. R5905032 HDX SERIES 16/06/2015...
Page 247: Language Selection
All available languages are indicated in the language of the country. The current active language is indicated by checked radio button. How to change the language 1. Press Menu to activate the menus and select Projector Control → Change Language. Image 13-107 Main menu, projector control Image 13-108 Projector control, change language R5905032 HDX SERIES 16/06/2015...
Page 248: Scheduler
Edit a task • Delete task • Scheduler, on or off 13.12.1 Add a task to the list How to add 1. Press Menu to activate the menus and select Projector Control → Scheduler → Add task. R5905032 HDX SERIES 16/06/2015...
Page 249 1. When selected, press ENTER to select the day. 2. Use the ▲ or ▼ key to change the current setting. Use the ◄ or ► key to jump to the next part of the date and time setting. R5905032 HDX SERIES 16/06/2015...
Page 250 To repeat the task with a given sequence again and again, check the check box in front of Inﬁnite. Routine setup, occurrences For a limited number of loops, set up the occurrences: 1. Select Occurrence and press ENTER. 2. Use the ◄ or ► key to change the occurrence. R5905032 HDX SERIES 16/06/2015...
Page 251: Edit A Task
1. Select Apply and press ENTER to create the task. The task is added to the list of tasks. 13.12.2 Edit a task What can be done? An existing task in the list of tasks can be edited and saved with the same name. R5905032 HDX SERIES 16/06/2015...
Page 252 Scheduler, edit task 2. Press ENTER to open the task selection list. Image 13-121 Task selection list 3. Use the ▲ or ▼ key to select the desired task and press ENTER The edit task window opens. R5905032 HDX SERIES 16/06/2015...
Page 253: Delete Task
A task stored in the list of tasks can be deleted from that list. How to delete 1. Press Menu to activate the menus and select Projector Control → Scheduler → Delete task. Image 13-123 Main menu, projector control Image 13-124 Projector control, scheduler R5905032 HDX SERIES 16/06/2015...
Page 254: Scheduler, On Or Off
When switched on, the tasks in the list will be executed on the given time. How to toggle the scheduler 1. Press Menu to activate the menus and select Projector Control → Scheduler → Scheduler [On]/[Off]. Image 13-128 Main menu, projector control Image 13-129 Projector control, scheduler R5905032 HDX SERIES 16/06/2015...
Page 255: Gsm Conﬁguration, Activation
PUK code to unblock the SIM card. How to conﬁgure 1. Press Menu to activate the menus and select Projector Control → GSM conﬁguration → GSM pincode. R5905032 HDX SERIES 16/06/2015...
Page 256 PIN code entered 4. Select OK and press ENTER to conﬁgure the software. Replacing a SIM card with a new one 1. Before removing the current mounted SIM card, select Projector Control → GSM conﬁguration → GSM pincode R5905032 HDX SERIES 16/06/2015...
Page 257: Gsm Conﬁguration, Subscription
When subscripted for notiﬁcations, the projector will send out SMS messages when notiﬁcations occur with severity “Critical”, “Error” or “Warning”. How to subscribe via the OSD menu 1. Press Menu to activate the menus and select Projector Control → GSM conﬁguration → Sms subscriptions. R5905032 HDX SERIES 16/06/2015...
Page 258 This procedure can be repeated for subscriber 2 and 3. 5. Select OK and press ENTER to conﬁgure the subscription. How to unsubscribe via the OSD menu 1. Press Menu to activate the menus and select Projector Control → GSM conﬁguration → Sms subscriptions. R5905032 HDX SERIES 16/06/2015...
Page 259: Flex, Light Output Conﬁguration
Via Projector Toolset when connected via an Ethernet connection with the projector. See Projector Toolset’s user guide (R5905073, index 04), chapter “FLEX, light output control”. • Via the OSD menu of the projector itself • Via an SMS message send to a projector equipped with an optional GSM board. R5905032 HDX SERIES 16/06/2015...
Page 260: Light Output Conﬁguration Via Osd Menu
Image 13-152 Successful conﬁgured If the code is incorrect, the message: “Invalid attempt!”, is displayed: Image 13-153 Invalid attempt After 3 invalid attempts, the message: “Invalid attempt! Try again after 300 seconds” is displayed. Image 13-154 R5905032 HDX SERIES 16/06/2015...
Page 261: Conﬁgure Projector's Light Output Via Sms
Activation code can be generated with Projector Toolset. See Projector Toolset’s user guide, chapter “Communication”, “Mobile settings”. 2. Send this message to the GSM number associated with the projector. The receiving projector analyses the message and creates a return SMS. This message is sent back to the requested cell phone. R5905032 HDX SERIES 16/06/2015...
Page 262: Request For Information
The receiving projector analyses the message and execute the command. It creates a return SMS with the following message: “Lamp ignition enable” or “Lamp ignition disabled” or “Lamp ignition admission failed”. This message is sent back to the requested cell phone. R5905032 HDX SERIES 16/06/2015...
Page 263: Service
Convergence Blue Green on Blue Red on Blue Factory Defaults USB Memory Save custom settings Load custom settings Reset Formatter Reﬁll Mode Save Custom Settings Special HD Camera Mode Auto Dimming when Overtemperature Time and Date R5905032 HDX SERIES 16/06/2015...
Page 264: Identiﬁcation
1. Press Menu to activate the menus and select Service → Identiﬁcation. Image 14-1 Main menu, service Image 14-2 Service, identiﬁcation Image 14-3 Identiﬁcation 2. Use the ▲ or ▼ key to scroll through the menu. R5905032 HDX SERIES 16/06/2015...
Page 265: Diagnosis
< the current has a lower version than the reference software. How to display an overview 1. Press Menu to activate the menus and select Service → Diagnosis → Versions. Image 14-4 Main menu, service Image 14-5 Service, diagnosis Image 14-6 Diagnosis, versions R5905032 HDX SERIES 16/06/2015...
Page 266: Measurements
How to display an overview 1. Press Menu to activate the menus and select Service → Diagnosis → Measurements. Image 14-8 Main menu, service Image 14-9 Service, diagnosis Image 14-11 Measurements, voltages Image 14-10 Diagnosis, measurements R5905032 HDX SERIES 16/06/2015...
Page 267: Logging
Projector hosts two log ﬁles: one managed bythe Main controller and one speciﬁc for the Lamp power supply. How to display the logging 1. Press Menu to activate the menus and select Service → Diagnosis → Logging. R5905032 HDX SERIES 16/06/2015...
Page 268 2. Use the ▲ or ▼ key to select Main Controller to get a logging of the main controller or to select Lamp Power Supply to get a logging of the lamp power supply. Image 14-20 Main controller logging Image 14-21 Lamp power supply logging R5905032 HDX SERIES 16/06/2015...
Page 269: Board Id
Image 14-25 Overview board IDs 14.3.5 Notiﬁcation About notiﬁcations Notiﬁcations are warnings and errors displayed on the local LCD or on the OSD since power on of the projector. Once powered off, the notiﬁcation logging is cleared. R5905032 HDX SERIES 16/06/2015...
Page 270: Tilt Sensor
Using a projector with an abnormal rotation can severely damage the lamp. How to check the tilt sensor 1. Press Menu to activate the menus and select Service → Diagnosis → Tilt sensor. R5905032 HDX SERIES 16/06/2015...
Page 271: Internal Service Patterns
The status pane indicates if the projector is used with an allowed rotation. 14.4 Internal Service Patterns How to select 1. Press Menu to activate the menus and select Service → Internal Service Patterns. R5905032 HDX SERIES 16/06/2015...
Page 272 Input patterns Input items in the Internal Service Patterns menu are only shown when the corresponding slot contains an input board. Image 14-37 Internal service patterns, input Press ENTER to display the list of possible patterns. R5905032 HDX SERIES 16/06/2015...
Page 273 Use the ▲ or ▼ key to select an option and press ENTER to select. The checkbox in front of that item will be checked. Osd patterns Image 14-42 Internal service patterns, OSD Press ENTER to display the list of possible patterns. R5905032 HDX SERIES 16/06/2015...
Page 274 Pmp out test patterns To change the options for the selected pattern, use he ► key to open these options. The number of options can change for the different patterns. Image 14-46 Pmp out internal service test patterns options R5905032 HDX SERIES 16/06/2015...
Page 275: Convergence
1 pixel, an electronic realignment is possible. Mechanical realignment of the convergence can only be done by a qualiﬁed service technician. How to display the convergence settings 1. Press Menu to activate the menus and select Service → Convergence. R5905032 HDX SERIES 16/06/2015...
Page 276 4. Use the ▲ or ▼ key to adjust vertical and the ◄ or ► key to adjust vertical convergence. Adjust until the crossing of the center Green (Red) convergence pattern coincide with the diagonal line of the center Blue con- vergence pattern. R5905032 HDX SERIES 16/06/2015...
Page 277: Factory Defaults
2. If you want to restore also one of the items in the list, check the check box in front of that item. Select Yes to restore the factory settings. Select No to stop the restore process. R5905032 HDX SERIES 16/06/2015...
Page 278: Usb Memory
When no USB stick is available, a message will be shown: No USB device is found. The name of the custom settings ﬁles contains the serial number of the projector from which ti is downloaded. Load custom settings 1. Press Menu to activate the menus and select Service → USB Memory. R5905032 HDX SERIES 16/06/2015...
Page 279: Reset Formatter
A reset formatter is necessary when e.g. a color is missing, artifacts are visible in the image or image is frozen and the formatter test patterns cannot be displayed. How to reset 1. Press Menu to activate the menus and select Service → Reset Formatter. R5905032 HDX SERIES 16/06/2015...
Page 280: Reﬁll Mode
When all necessary preparations are taken, the reﬁll mode activates automatically the reﬁll process. For more information about the reﬁll process, consult the Service manual. How to start the reﬁll mode 1. Press Menu to activate the menus and select Service → Reﬁll Mode. R5905032 HDX SERIES 16/06/2015...
Page 281: Save Custom Settings
When settings are changed when the lamp is off, a manual Save custom settings must be executed to save the changes. When the message Saving data is displayed, never switch off the projector. How to save 1. Press Menu to activate the menus and select Service → Save Custom Settings. R5905032 HDX SERIES 16/06/2015...
Page 282: Special Hd Camera Mode
Valley Worldcam. It shouldn’t be used in any other circumstances as it would cause image ﬂicker and dimmed images with normal sources. Default position : [Off] How to switch 1. Press Menu to activate the menus and select Service → Special HD Camera Mode. Image 14-73 Main menu, service Image 14-74 Service, special HD camera mode R5905032 HDX SERIES 16/06/2015...
Page 283: Auto Dimming When Over-Temperature
[Off] : No dimming is started when over-temperature is detected. 14.13 Time and Date How to set 1. Press Menu to activate the menus and select Service → Time and Date. Image 14-77 Main menu, service Image 14-78 Service, time and date R5905032 HDX SERIES 16/06/2015...
Page 284 Note: Digits can be entered with the digit keys on the remote control or the local keypad. When a digit is entered in that way, the next character will be selected automatically. 4. Press ENTER to accept the changes. Repeat for other values in the same way. R5905032 HDX SERIES 16/06/2015...
Page 285: Maintenance
2. Clean the housing of the projector with a damp cloth. Stubborn stains may be removed with a cloth lightly dampened with a mild detergent solution. 5. Pressurized air cans are not efficient if there is too much dust on the surface, the pressure is too low R5905032 HDX SERIES 16/06/2015...
Page 286 15. Maintenance R5905032 HDX SERIES 16/06/2015...
Page 287: Servicing
Remove and clear metal front ﬁlter Extra service information Extra service information for qualiﬁed service technicians can be found on Barco’s Partnerzone (URL:http:\\my.barco.com). Regis- tration is necessary. If you are not yet registered, click on Partnerzone registration and follow the instructions. With the created login and password, it is possible to enter the partnerzone where you can ﬁnd extra service information about the projector.
Page 288: Removal Of The Lamp House
Switch off the projector and unplug the power cord before starting the procedure. Necessary tools Flat screwdriver How to remove 1. Remove the lamp cover on the input side, see "Removal of the lamp cover", page 289. 2. Release the 3 spring lock screws. R5905032 HDX SERIES 16/06/2015...
Page 289: Installation Of The Lamp House
3. Take the lamp house by both handles and pull it out. Image 16-4 Lamp house, removal 16.3 Installation of the lamp house ARNING Switch off the projector and unplug the power cord before starting the procedure. Necessary tools Flat screwdriver R5905032 HDX SERIES 16/06/2015...
Page 290: Removal Of The
While starting up the projector, the electronics detect if a lamp is installed. If no lamp is installed, it is not possible to start up the projector. 16.4 Removal of the front cover Switch off the projector and unplug the power cord before starting the procedure. ARNING Necessary tools 7 mm ﬂat screw driver R5905032 HDX SERIES 16/06/2015...
Page 291 1. Remove the lens. See "Lens removal", page 30. 2. Remove the rubber dust ring from the lens holder. Image 16-6 Dust ring removal 3. Release the 4 captive screws (1). Image 16-7 Front cover removal 4. Take off the front cover. R5905032 HDX SERIES 16/06/2015...
Page 292: Mounting The
1. Place the front cover with the rubber dust facing the projector on its place. Image 16-8 Mount front cover 2. Secure the 4 captive screws (1). 3. Reinstall the rubber dust ring around the lens holder. R5905032 HDX SERIES 16/06/2015...
Page 293: Removal Of The Lamp Cover
16.6 Removal of the lamp cover ARNING Switch off the projector and unplug the power cord before starting the procedure. Necessary tools 7 mm ﬂat screw driver How to remove 1. Release the 6 captive screws. R5905032 HDX SERIES 16/06/2015...
Page 294: Mounting The Lamp Cover
Switch off the projector and unplug the power cord before starting the procedure. Necessary tools 7 mm ﬂat screw driver How to mount 1. Place the front cover on the is place and secure the 6 captive screws. R5905032 HDX SERIES 16/06/2015...
Page 295: Replacement Of The High Density Dust Filter
New ﬁlter (available kit : R98010085, contains 5 high density ﬁlters and one cleanable ﬁlter) How to replace 1. Remove the front cover, see "Removal of the front cover", page 286. 2. Push both ﬁlter holders to the outside. R5905032 HDX SERIES 16/06/2015...
Page 296: Remove And Clear Metal Front Filter
New ﬁlter when needed (available kit : R98010085, contains 5 HEPA ﬁlters and one cleanable ﬁlter) How to remove 1. Remove the front cover, see "Removal of the front cover", page 286. 2. Release the thumb screw (1) 3. Pull the bottom holder to the front. R5905032 HDX SERIES 16/06/2015...
Page 297: How To Install
If you cannot clean the ﬁlter anymore, insert a new one. How to install 1. Pull the bottom holder to the front and insert the ﬁlter. 2. Fasten the thumb screw (1). AUTION Never use the projector with removed ﬁlters ! R5905032 HDX SERIES 16/06/2015...
Page 298 16. Servicing R5905032 HDX SERIES 16/06/2015...
Page 299: Dimensions
A. Dimensions A. DIMENSIONS Overview • Dimensions of a HDX projector A.1 Dimensions of a HDX projector Overview Center of gravity Center of gravity Image A-1 Dimensions, mm Geometrical centre Centre without lens Centre with lens 186.5 170.0 185.0 237.5 241.0...
Page 300 A. Dimensions R5905032 HDX SERIES 16/06/2015...
Page 301: Speciﬁcations
(optional), passive Inﬁtec (optional), passive circular (optional), triple ﬂash up to 200 Hz Inputs DVI - I (HDCP including analog RGB YUV), SDI/HDSDI/dual HDSDI/3G/Barco Link Optional Inputs 5-BNC RGBHV ( RGBS/RGsB, YUV CS/SOY, Composite video, S-Video); DVI - I (HDCP including analog RGB YUV) + BarcoLink/SDI/HDSDI/dual HDSDI/3G;...
Page 302: Speciﬁcations Of The Hdx W14
Compliant with UL60950-1 and EN60950-1, complies with FCC rules & regulations, part 15 Class A and CE EN55022 Class A, RoHS Warranty 2 years standard, extendable up to 5 years +/- 10% B.2 Speciﬁcations of the HDX W14 Overview Projector type WUXGA 3-chip DLP digital projector Technology 0.96"...
Page 303: Speciﬁcations Of The Hdx W18
Compliant with UL60950-1 and EN60950-1, complies with FCC rules & regulations, part 15 Class A and CE EN55022 Class A, RoHS Warranty 2 years standard, extendable up to 5 years +/- 10% B.3 Speciﬁcations of the HDX W18 Overview Projector type WUXGA 3-Chip DLP digital projector Technology 0.96"...
Page 304: Speciﬁcations Of The Hdx W20 Flex
Compliant with UL60950-1 and EN60950-1, complies with FCC rules & regulations, part 15 Class A and CE EN55022 Class A, RoHS Warranty 2 years standard, extendable up to 5 years +/- 10% B.4 Speciﬁcations of the HDX W20 FLEX Overview Projector type WUXGA 3-Chip DLP digital projector Technology 0.96"...
Page 305 Power cord; wireless/XLR wired rugged remote control Certiﬁcations Compliant with UL60950-1 and EN60950-1, complies with FCC rules & regulations, part 15 Class A and CE EN55022 Class A, RoHS Warranty 2 years standard, extendable up to 5 years +/- 10% R5905032 HDX SERIES 16/06/2015...
Page 306: Technical Regulations
B. Specifications B.5 Technical Regulations Certiﬁcates RoHS Image B-2 Image B-3 Image B-4 Image B-1 Rohs Rohs OK CE mark EAC mark R5905032 HDX SERIES 16/06/2015...
Page 307: Standard Source Files
9. Fpix MHz: pixel frequency 10. Ptot : total pixels on one horizontal line. 11. Pact: active pixels on one horizontal line. 12. Ltot: total lines in one field 13. Lact: active lines in one field. R5905032 HDX SERIES 16/06/2015...
Page 308 2200 1920 hd-1920x1035@30i 60,000 33,750 74,250 2200 1920 hd-1920x1080@24p 24,000 27,000 74,250 2750 1920 1125 1080 hd-1920x1080@24sf 48,00038, 27,000 74,250 2750 1920 hd-1920x1080@25i 50,000 28,125 74,250 2640 1920 hd-1920x1080@25p 25,000 28,125 74,250 2640 1920 1125 1080 R5905032 HDX SERIES 16/06/2015...
Page 309 2376 1920 hd-1920x1080@50p 50,000 56,250 148,500 2640 1920 1125 1080 hd-1920x1080@60p 60,000 67,500 148,500 2200 1920 1125 1080 VIDEO525 59,940 15,734 13,500 VIDEO525p 59,940 31,469 27,000 VIDEO625 50,000 15,625 13,500 VIDEO625p 50,000 31,250 27,000 Table C-1 R5905032 HDX SERIES 16/06/2015...
Page 310 C. Standard source files R5905032 HDX SERIES 16/06/2015...
Page 311: Dmx Chart
Mechanical shutter closed 6 - 255 Electronic contrast on output Brightness 0 - 255 Adjusts the brightness between 0 and 100% on input 0 - 255 Contrast Adjust the contrast between 0 and 100% on input R5905032 HDX SERIES 16/06/2015...
Page 312: Dmx Chart, Extended
0 - 5 6 - 255 Electronic contrast on output Brightness 0 - 255 Adjusts the brightness between 0 and 100% on input Contrast 0 - 255 Adjusts the contrast between 0 and 100% on input R5905032 HDX SERIES 16/06/2015...
Page 313 Stand by / Lamp Off (if held for 5 seconds) 224 - 231 XLR output voltage On (if held for 5 seconds) 232 - 239 XLR output voltage Off (if held for 5 seconds) 240 - 255 No function 14. Only when lens is calibrated R5905032 HDX SERIES 16/06/2015...
Page 314 D. DMX chart R5905032 HDX SERIES 16/06/2015...
Page 315: Stacking Hdx Projectors
E. Stacking HDX projectors E. STACKING HDX PROJECTORS Overview • Mount stacking points • Stacking HDX projectors • Aligning stacked HDX projectors Mount stacking points Necessary tools Allen key 8 mm How to mount 1. Place the ﬁrst stacking point on a corner.
Page 316 E. Stacking HDX projectors How to stack 1. Mount stacking points on lower projector. See "Mount stacking points", page 311. 2. Mount a bottom carry handle on the upper projector. See "Mounting the bottom carry handler", page 39. 3. Place the projector with carry handle on top of the projector with stacking points.
Page 317 E. Stacking HDX projectors Image E-4 Security cables, mount 2. Mount the other end of the security cable around the carry handle of the top projector and clasp the safety hook round the cable as illustrated. Make sure that the falling distance is maximum 20 cm. If necessary, before clasping the safety hook around the cable, turn the cable a few time around the carry handle.
Page 318: Aligning Stacked Hdx Projectors
E. Stacking HDX projectors ARNING Never open an interlocking adapter of a stacked projector which is still suspended. First place the stacked projectors on the ﬂoor. Aligning stacked HDX projectors Necessary tools No tools. How to align stacked projectors 1. Make sure that the internal hatch pattern projected by the reference projector is sharp and has a perfect rectangle outline. If this is not the case, readjust the reference projector before aligning the other stacked projector(s) with the reference hatch pattern.
Page 319 E. Stacking HDX projectors Inclination Image E-7 Stacked projectors, inclination 5. If necessary, adjust the skew of the stacked projector with respect to the reference projector by turning the Hand screw in or out. The hand screw is located at smallest side of the carrying handle (front or back). Adjust until the outline of the hatch pattern is most symmetric with the reference hatch pattern.
Page 320 E. Stacking HDX projectors Zoom Image E-10 Stacked projector, zoom 8. If necessary, repeat from step 2 until the hatch pattern of the stacked projector is perfectly aligned with the hatch pattern of the reference projector. In case of a triple stacked table mount projector conﬁguration adjust and align ﬁrst the bottommost projector (reference), than the projector in the middle and ﬁnally the uppermost projector.
Page 321: Environmental Information
For more information about recycling of this product, please contact your local city ofﬁce or your municipal waste disposal service. For details, please visit the Barco website at: http://www.barco.com/en/AboutBarco/weee...
Page 322 SJ/T11363. X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T 11363 标准规定的限量要求. X: Indicates that this toxic or hazardous substance contained in at least one of the homogeneous materials used for this part is above the limit requirement in SJ/T11363 R5905032 HDX SERIES 16/06/2015...
Page 323: Production Address
The month and year of production is indicated on the product ID label on the product itself. Importers contact information Contact To ﬁnd your local importer, contact Barco directly or one of Barco’s regional ofﬁces via the contact information given on Barco’s web site, www.barco.com. R5905032 HDX SERIES 16/06/2015...
Page 324 F. Environmental information R5905032 HDX SERIES 16/06/2015...
Page 325: Index
157–160 SMS services 257–258 Calbrate lens at startup Information request Calibrate Lamp ignition admission Mid position Notiﬁcation request Zoom - focus 157–158 Status lights Orientation USB port Overview Communication connections Scenergix 190–195, 198, 201 Conﬁgurations 16–17 R5905032 HDX SERIES 16/06/2015...
Page 326 Custom ﬁle 89, 91–92 Help information Create Adjustment mode Delete High End Systems Mirror Delete all Horizontal tilt range Delete How to use Custom ﬁle Delete ll Remote control Custom ﬁle Enter PIN code 251, 253 R5905032 HDX SERIES 16/06/2015...
Page 327 White balance Selection Input conﬁguration Language selection Input locking Layout 133–141, 143–147 Input menu 75–78, 80, 82–86, 88, 92, 95–98 File services 143–147 92, 95–98 Delete 144, 146 Auto detection Delete all Input type Lens behavior R5905032 HDX SERIES 16/06/2015...
Page 328 Power cable LPS power Connection Power mode Lamp power net Connection Main window 134–136 Power off Position Power on Size Power requirements Source selection Prevent Maintenance Electrical shock Measurements Production address Fan speeds Projector 18–19 Temperatures R5905032 HDX SERIES 16/06/2015...
Page 329 Delete task Quick language Edit task Selection Enabled or disabled Quick set up 65, 67 On or off Adjustment Task 244, 247, 249 Lens 65, 67 Create Lens functions Delete LENS key Edit Text on/off Scheimpﬂug R5905032 HDX SERIES 16/06/2015...
Page 330 Standby Values reset Switch to Warp board reset 181–182 Standby button Warp ﬁle service 175–180 Function Delete 179–180 Start up Load ﬁle Adjustment mode Rename Status LEDs Save Status lights Save as Suspend Wired remote control R5905032 HDX SERIES 16/06/2015...
Page 331 Index Z-axis, current light output R5905032 HDX SERIES 16/06/2015...

This manual is also suitable for:

Hdx w12 Hdx w14 Hdx w18 Hdx w20

Barco HDX User And Installation Manual

1 Safety

2 General

3 Physical Installation

4 Input & Communication

5 Getting Started

6 Quick Set up Adjustment

7 Start up of the Adjustment Mode

8 Input

9 Image

10 Layout

11 Lamp

12 Alignment

13 Projector Control

14 Service

15 Maintenance

Quick Links

Related Manuals for Barco HDX

Summary of Contents for Barco HDX
