INTEGRATED TUMBLE DRYER
IMPORTANT: PLEASE READ THESE
INSTRUCTIONS THOROUGHLY BEFORE USING
THIS APPLIANCE. KEEP THEM IN A SAFE PLACE FOR
FUTURE REFERENCE.
IMPORTANT USER INFORMATION
These notes are provided in the interest of safety.
You must read them before installing or using the
appliance.
–This tumble dryer is intended for NORMAL DOMESTIC
USE ONLY.
- This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use
of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without
supervision. Children of less than 3 years should be kept away
unless continuously supervised.
- Adequate ventilation must be provided to avoid back flow of
gases into the room from appliances burning other fuels,
including open fires.
INSTRUCTIONS FOR USE
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for White Knight 437
Summary of Contents for White Knight 437
- Page 1 INSTRUCTIONS FOR USE INTEGRATED TUMBLE DRYER IMPORTANT: PLEASE READ THESE INSTRUCTIONS THOROUGHLY BEFORE USING THIS APPLIANCE. KEEP THEM IN A SAFE PLACE FOR FUTURE REFERENCE. IMPORTANT USER INFORMATION These notes are provided in the interest of safety. You must read them before installing or using the appliance.
- Page 2 - Exhaust air must not be discharged into a flue which is used for exhausting fumes from appliances burning gas or other fuel. –Please note it is not recommended that the dryer is placed directly next to ovens or cookers as the performance of the dryer may be affected.
- Page 3 - It is important to clean fluff from the window of the dryer and around the door seal after each drying cycle. Failure to do so could result in water leaking. - Fabric softeners, or similar products, should be used as specified by the fabric softener instructions.
- Page 4 DO NOT exceed the recommended maximum load. DO NOT dry unwashed items in the tumble dryer DO NOT place articles in the dryer if anything other than a water solution has been used in the cleaning process. DO NOT use the tumble dryer if you suspect that it is damaged in any way.
-
Page 5: Installation
INSTALLATION The tumble dryer is fully compatible with any 600mm deep kitchen units and complies with stringent EEC regulations. Your dryer is provided with a vent hose which will extend to approx 2.4m (8ft). We strongly recommend that this is vented through the wall with the attachment provided. The position of the hole (100mm diameter) for the vent directly behind the tumble dryer is shown in the diagram. -
Page 6: Control Panel Guide
THE FILTER The filter is found, as seen from the diagram, by opening the door and must always be in position when drying items in the appliance. To allow the dryer to operate efficiently it should be cleaned after each drying cycle. Do not be alarmed by the amount of fluff deposited on the mesh. -
Page 7: Operation
OPERATION Sort out the clothes into groups of similar fabrics and colours. Check the care label inside the garment. We suggest that a fabric conditioner be used to reduce static electricity. Delicate articles e.g. tights should be placed inside a pillowcase. -
Page 8: Door Reversal
DOOR REVERSAL APPLIANCE DOOR The door on the dryer can be positioned either with the left or right hand hinging. Please follow illustrations below to change the door position. THE DECOR DOOR The hinges can be fastened through the pre-drilled holes on either the left or right hand with the door stops being fitted on the other side. - Page 9 APPROVED SERVICE AGENTS: White Knight (Whirlpool) 0800 988 1323 (calls are free from landlines however calls from mobiles may be charged at your network provider’s rates) White Knight (0800 Repair): 0344 8797422 (Calls charged at basic rate).
- Page 10 This label positioned on the rear of your dryer, indicates the surface is hot when in operation – avoid touching. This appliance is marked according to the European Directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE). This guideline is the frame of a Europen wide validity of return and Recycling on Waste Electrical and Electronic Equipment.
- Page 11 LAV SDO Rev Suppliers name or trade mark WHITE KNIGHT Model identifier 437, 434, 447, 512, 514, 517, 432, 513, 44B, 44A, AWG 288S, 449, 44C- TYPE Rated capacity at full load Appliance type Air Vented Energy efficiency class Energy consumption of the appliance*...
- Page 12 Manufactured by: Crosslee plc. Hipperholme, Halifax, West Yorkshire HX3 8DE 4213 194 10483...
Need help?
Do you have a question about the 437 and is the answer not in the manual?
Questions and answers
How to replace motor capacitor
To replace the motor capacitor in a White Knight 437 tumble dryer:
1. Unplug the dryer from the power supply for safety.
2. Access the back panel by removing the screws holding it in place.
3. Locate the capacitor, usually near the motor. It is a cylindrical component with two terminals.
4. Discharge the capacitor by shorting the terminals with an insulated screwdriver to avoid electric shock.
5. Disconnect the wires from the capacitor, noting their positions.
6. Remove the old capacitor, usually held by a clamp or bracket.
7. Install the new 8μF capacitor, securing it in place and reconnecting the wires as before.
8. Reattach the back panel and screws.
9. Plug in and test the dryer to ensure it starts properly.
Make sure the replacement capacitor is compatible with the White Knight 437 model.
