- Page 1 SERVICE MANUAL Time Steered Condenser Dryer White Knight C77AS 0312 76A 15332 Wiring Diagram Exploded Views Parts List July 2013...
- Page 2 White Knight Condenser Dryer - Exploded View 1 235a 248a 203a 367...
- Page 3 White Knight Condenser Dryer - Exploded View 2 445b 445a...
- Page 4 White Knight Exploded View 3...
- Page 5 White Knight Condenser Dryer - Exploded View 4...
- Page 6 Wiring Diagram...
- Page 7 White Knight Condenser - Parts List Item Description Part Number Expl.View Motor + 8µf Capacitor Assembly 4213 092 21001 Capacitor Assembly 8µf 4213 092 08091 Drive Belt 4213 092 19501 Mains Cable 4213 076 35123 Terminal Block 4213 078 44621...
- Page 8 White Knight Condenser - Parts List Banjo/Seals/Clips/Bearing Pads Assembly 4213 092 21161 Front Seal 4213 077 40942 Lifter 4213 077 41009 Front Bearings/Drum Seal Assembly 4213 092 21171 445a Bearing Pads (long) 4213 077 40962 445b Bearing Pads (short) 4213 077 40952...
