INTERIOR PARTS OF DIFFUSER ASSEMBLY:-
-
Thermostat
- Defrost Timer
1. Disconnect thermostat connectors
2. Separate thermostat from machine
3. Remove deodorizer cover
4. Use star screw driver and remove 1 screw
5. Disconnect D Timer connectors
6. Separate D Timer from refrigerator
BOTTOM HINGE:-
1. Use 8mm round spanner and open 2 screws from front side
2. Tilt the machine slightly at back side
3. Open 2 screws from bottom side
4. Separate bottom hinge from machine
