DEFROST HEATER:-

1. Separate FC Plenum from refrigerator
2. Disconnect Heater terminals
3. Pull out cooling coil slightly upwards and towards your side
4. Remove LHS and RHS EPS blocks
5. Remove Thermal Fuse
6. Take the black wire (thin) out
7. Take the white wire (thick) out
8. Cut white wire of defective heater at by wire cutter
9. Separate defrost heater from the machine
Note – All the models above 400L carries 200W integrated heater with evaporator. Need to remove as an assembly.
Part Code A2242730000
