Buffer
1
2
緩沖
3
T02043 4.0 E-ring
E 扣
..............................1
T02080 3x6x2.5 Ball Bearing
軸承
...........................4
T02061 Ball stud - silvery
球頭-銀色
...........................1
4
Buffer
緩沖
T02044 4.5x5.4 Block Carrier
軸套
.................................2
T02044 M3x10 Screw
螺絲
..................2
T02093 Ball stud - short
球頭-短
...........................2
T02044 3x7x0.8 Washer
墊片
........................2
Assemble in the specified order
1
2
按順序組裝
3
2
1
4
4.0mm
T02044
T02093
T02044
T02080
T02023
T02043
3
T02043
T02080
T02044
T02080
10
T02043
9
T02043
T02061
5
8
T02023
7
T02023
6
T02043
11
T02080
T02093
T02044
T02024
4
