Team C TC02T Pro Instruction Manual page 17

28
Shock Absorber
避震器
TG2025 & TG2026
x4
T02031
TG2025&TG2026 12x1 O - ring
O環
............4
29
Front Suspension
前橋
3
1
T02084
1
2
3
x2
Assemble as many times as specified
需組裝次數
for adjusting the spring tension
調整彈簧松緊
Compress the spring and install
壓縮彈簧後安裝
Short
短
TG2017(Short)
短
T02031
Short
短
1
Assemble in the specified order
1
2
3 按順序組裝
Front x2
前
TG2018(Long)
長
T02084 M3 Nylon Nut
L
R
Assemble left and rear sides the same way
L
R
左右裝法相同
Short
短
Long
長
2
T02082 M3x15 Screw
尼龍螺母
............2
Rear
x2
後
T02082
螺絲
......2
