HITEC X2 AC Plus Operation Manual page 16

Pb Lead-Acid Battery Program [
Pb Charge Mode:
BEFORE YOU BEGIN CHARGING YOUR BATTERY, MAKE SURE YOU
HAVE READ AND UNDERSTAND ALL OF THE WARNINGS AND SAFETY
Warning
INFORMATION CONTAINED ON PAGES 02-07.
After selecting the correct battery type, use the + or ▬ buttons to change it to the
"CHARGE" mode.
Press the ► button and the amp rate value will begin flashing. Use the + or ▬
buttons to adjust the value to the desired charge rate. The amp rate should be set
to 1/10 of capacity. For example if you are charging a 7Ah battery the charge rate
should be set to 0.7A. Follow the instructions provided with your battery when
setting the amp rate.
Press the ► button again and the voltage rate value will
Pb Charge
begin flashing. Use the + or ▬ buttons to set the voltage
1.5A 12.0V(6P)
and number of cells.
Press and hold the ► button and charging will begin.
Once charging has commenced, the charger will display
P-6 1.5A 13.56V
the following real-time information: battery type, charging
CHG 002:22 00106
current, battery voltage, charging time and charged capacity.
When charging is complete, the screen will read "FINISHED" and the charger will emit
a chiming sound.
Pb Discharge Mode:
BEFORE YOU BEGIN CHARGING YOUR BATTERY, MAKE SURE YOU
HAVE READ AND UNDERSTAND ALL OF THE WARNINGS AND SAFETY
Warning
INFORMATION CONTAINED ON PAGES 02-07.
After selecting the correct battery type, use the + or ▬ buttons to change it to the
"DISCHARGE" mode.
Press the ► button and the amp rate value will begin flashing. Use the + or ▬
buttons to adjust the value to the desired charge rate. The amp rate should be set
to 1/10 of capacity. For example if you are discharging a 7Ah battery the discharge
rate should be set to 0.7A. Follow the instructions provided with your battery when
setting the amp rate.
30
cont.]
Pb Lead-Acid Battery Program [
Press the ► button again and the voltage rate value will
Pb Discharge
begin flashing. Use the + or ▬ buttons to set the voltage
1.5A 12.0V(6P)
and number of cells.
Press and hold the ► button and discharging will begin.
Once charging has commenced, the charger will display
P-6 1.0A 13.56V
the following real-time information: battery type, charging
DCH 005:10 00964
current, battery voltage, charging time and charged capacity.
When charging is complete, the screen will read "FINISHED" and the charger will emit
a chiming sound.
Additional Pb Process Information:
During the Pb battery charging/discharging process the X2AC+ can display a variety
of information. Using the + or - buttons you can also view the following information:
Capacity cut-
Capacity Cut-Off
off setting
ON 5000mAh
Temperature
Temp Cut-off
.
cut-off
50 C
Input voltage
In Power Voltage
12.56V
*Requires optional temperature sensor. (Part#: 44159)
cont.]
Safety timer
Safety Time
setting
ON 200min
External*/ internal
Ext. Temp ----
.
temperatures
Int. Temp 37 C
