- Page 1 CAR CD /DVD /MP3 PLAYER /RADIO/SWC/GPS&RDS RECEIVER /WITH Bluetooth MODEL: TE-269...
- Page 2 INSTRUCTION MANUAL Copyright Information ©2009 All rights reserved. This document may not in whole or in part be reproduced, stored in a retrieval system, transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, or reduced to any electronic medium or machine-readable form without prior consent, in writing, from [COMPANY].
- Page 3 INSTRUCTION MANUAL WARNING! To promote safety, certain functions are disabled unless the parking brake is on. The Unit is designed to detect parked status and must be connected to the power supply side of the parking brake switch. Improper connection or use of his connection may violate applicable law and may result in serious injury or damage.
-
Page 4: Table Of Contents
INSTRUCTION MANUAL CONTENTS WARNING!......................... 2 OPERATION PRECAUTIONS ................... 2 CONTENTS ........................3 ACCESSORIES......................... 4 INSTALLATION........................5 WIRING CONNECTIONS ....................6 PANEL ..........................8 REMOTE CONTROL ....................... 10 REMOVE BATTERY ......................12 MAIN MENU ........................13 ◆RADIO PLAYER..................... 13 CD PLAYER ...................... -
Page 5: Contents
INSTRUCTION MANUAL ACCESSORIES Package contains the following accessories for installation and operation of the unit. (1) Washer, Spring (4) Rubber Washer, each cushion M5 Nut (2) Mounting (5) Screw Strap (6) Screw (3) Bolt 1x AV-IN Cable ISO Cable Remote Control GPS Cable Trim ring RCA Cable... -
Page 6: Installation
INSTRUCTION MANUAL INSTALLATION Note Before starting installation of the unit, make sure the wiring is connected properly. Use only the parts provided with the unit to ensure proper installation. The use of unauthorized parts may cause malfunction. Install the unit where it does not get in the driver’s way and will not injure the passenger in case there is a sudden stop, like an emergency stop. -
Page 7: Wiring Connections
INSTRUCTION MANUAL WIRING CONNECTIONS NOTE: Never connect cable to the system while it is connected to the battery power. Whenever the unit is disconnected from the battery, the preset memory will be erased and the unit will go back to its factory defaults. Note: 1.To watch video the parking wire should be connected to break signal. - Page 9 INSTRUCTION MANUAL Connecting the reversing line to taillight on the car After connecting, when you start up the reverse gear, the unit will receive the picture from car rear view camera. Note: Only use groundless loudspeakers. Use only loudspeakers of minimal 40Watt, using fewer watts may result in damaging your loudspeakers at higher volumes.
-
Page 10: Panel
INSTRUCTION MANUAL PANEL... - Page 11 INSTRUCTION MANUAL 1. POWER/MUTE Button Press it to turn on the unit. Press and hold for 2 seconds to turn the unit off .Press the button briefly to Mute .Please note that the volume will be muted on all audio output connector.
-
Page 12: Remote Control
INSTRUCTION MANUAL REMOTE CONTROL MODE POWER BAND/RANDOM/CLEAR ENTER UP/DOWN/LEFT/RIGHT EJECT PTY/* P.SCN/RPT/# BACKWARD/SEEK- 10: AF/TA 11: OSD 12: PBC/STOP 13: DIGIT NUMBERS 14: PLAY/PAUSE 15: MUTE/BLUETOOTH 16: MENU 17: SUBTITLE 18: SETUP 19: ANGLE/ACCEPT 20: INT/REJECT 21: VOLUME PLUS 22: A-B/ZOOM 23: SEL 24: FORWARD/SEEK+ 25: VOLUME MINUS... - Page 13 INSTRUCTION MANUAL 8. P.SCN/ RPT /# In SD CARD/ USB mode, press to repeat REP OFF=>REP track=>REP in folder=>REP When playing the video, press to start repeat REP OFF=>REP track=>REP in folder=>REP In Radio mode: PS (Preset Scan): Press to scan all preset stations in the memory of the current band and stay on each memory stations for about 5 seconds.
-
Page 14: Remove Battery
INSTRUCTION MANUAL Press to increase volume level. 22. A-B/ZOOM button During playback, press it at the starting point of section you want to repeat (A), press this button again at the ending point of the section you want to repeat (B), section A-B repeating starts. -
Page 15: Main Menu
INSTRUCTION MANUAL MAIN MENU The best way to discover the program is to explore each screen in detail, and to find out how to move from one to another. Read this chapter for a guided tour. Unit starts by displaying the Main menu. This is the root of the screen hierarchy, and you can simply access all features by tapping on the touch screen icons. -
Page 16: Cd Player
INSTRUCTION MANUAL Touch this icon scan the stations and scan each station for 5 seconds. Touch and hold it to save the stations with good reception automatically. Touch this icon again to stop. Touch this button to switch an alternative frequency on or off. When it turned on, radio can follow the same station when the frequency is different. -
Page 17: Dvd Player
INSTRUCTION MANUAL ◆ DVD PLAYER To start DVD Player, tap on DISC icon from main menu screen. TOUCH SCREEN MENU You will not see any buttons while DVD is played. Buttons will appear when you tap on TFT screen. Tap the screen again to hide the buttons. Touch it to skip to the previous track. -
Page 18: Usb/Sd/Mmc Interface
INSTRUCTION MANUAL USB/SD/MMC INTERFACE When a file disc, USB or a memory card is played, the screen will show following interface: Touch it to select music files. Touch it to select video files. Touch it to select photo files. Touch it to select: repeat all=>repeat 1=>... -
Page 19: Dual Zone Mode
INSTRUCTION MANUAL optional audio/video source into the 3.5mm input jack on the front panel. Connect an optional audio/video source to the RCA connectors on the back of the unit. ◆ DUAL ZONE front deck and background work at the same time To start dual zone Mode, ◆... -
Page 20: Radio Frequence Control
INSTRUCTION MANUAL Radio Frequency CONTROL Tap radio freq icon to show radio freq menu, then through touching the area name to select different frequency region Navi Path CONTROL Tap NaviPath icon to show NaviPath menu, then set the navigation path. Press the icon to enter into GPS mode, and we must exit the map to end the GPS mode. -
Page 21: System Information Display
INSTRUCTION MANUAL Sys info CONTROL Tap sys info icon to show the syeterm information Tools CONTROL Tap tools icon to select the GPS monitor and touch calibration function WHEELCTRL CONTROL Tap WHEELCTRL icon to set SWC function... -
Page 22: Other Control
INSTRUCTION MANUAL Other CONTROL Tap other icon to show the menu to set the other function Video/Camera CONTROL Tap video/camera icon to show the video/camera menu to set the effect Sound CONTROL Tap Audio icon to show audio menu, then touch the different effect to Select the digital sound effect (close,rock,pop,live,dance,classic,soft) -
Page 23: Desktop Control
INSTRUCTION MANUAL icon to show BALANCE menu BALANC UP/DOWN/LEFT/RIGHT Balance control REVERB Set reverberation: original ERATION sound, the scene, living room, hall, caves, bathroom, arena. Desktop CONTROL Tap desktop icon to show desktop menu, then select the picture you desire as the wallpaper OTHER FUNCTIONS Subwoofer Connect the subwoofer to the unit using sub output (see electrical diagram). -
Page 24: Parking
BT function on the mobile phone. 2) Tap the MATCH icon on the unit, select the new device(TEAC) on the phone after searching for it, input PIN password”1234” on the phone and confirm, the phone and the unit is connected. - Page 25 INSTRUCTION MANUAL Tap CALLING icon to use phone functions. Tap MUSIC icon to start BLUETOOTH music player. Tap HISTORY icon to check dialed, received, missed calls. Tap PHONEBOOK icon to use phone book functions. Tap EDIT icon to use edit functions 1.
-
Page 26: Navigation Mode
INSTRUCTION MANUAL this icon indicate the Bluetooth has opened touch it can close the luetooth. 5. BT MUSIC Tap MUSIC icon to listen music in A2DP mode. You can select the function with the icon for previous, play / pause, and next. Note: in this mode the ID3 and present information can just display iPone, other phone may not display this information. -
Page 27: Notes On Disc
INSTRUCTION MANUAL 3) While holding down the button on the steering wheel and the corresponding button on the SWC interface it will display complete setting. When all the buttons on the steering wheel and the corresponding button on the WHEEL CTRL interface complete setting, you can use the steering wheel button to operation the unit. -
Page 28: Troubleshooting
INSTRUCTION MANUAL TROUBLESHOOTING Symptom Cause Remedy Power does not turn Replace with fuse of the same amperage. Fuse is blown If the fuse blows again, consult your store (No sound is of purchase produced.) In correct wiring Consult your local retailer. 1. -
Page 29: Troubleshooting
INSTRUCTION MANUAL TROUBLESHOOTING SYMPTOM CAUSE SOLUTION IF THE POWER SUPPLY IS PROPERLY THE CAR IGNITION IS NOT CONNECTED TO THE CAR ACCESSORY SWITCH THE IGNITION KEY NO POWER TO “ACC”. THE FUSE IS BLOWN. REPLACE THE FUSE. PRESENCE OF DISC REMOVE THE DISC IN THE PLAYER THEN DISC CANNOT BE INSIDE THE PLAYER... -
Page 30: Technicial Specifications
INSTRUCTION MANUAL TECHNICIAL SPECIFICATIONS General Power supply: 11~16V DC Current consumption: max. 15 A Maximum power output: 50W x 4 channels (max) DVD/SVCD/VCD/HDCD/MP3/MP4/VIDEO/CDDA/PICTUR Compatible formats: E CDCD-R/-RW/DVD±R/±RW PLAYBACK Dimensions (W x D x H) / 165*178*100 mm/2 kg weight: Working temperature -20 ℃... - Page 31 www.phonic-teacaudio.com...
