Utility

The Utility function is available for erasing inserted cards and updating the Duplicator firmware.

Measure Speed

The Measure Speed function can be turned on to measure the exact speed of the flash read
and write.

Media Check

This function checks the media quality, and can be set to 3 different levels: Normal 100%,
Strict 100%, and Setup Range. Regardless of the setting, if the check detects a read or write
error, the LED for that flash card will show red.
Normal 100% will use bit 0 to perform a write and read to examine the flash quality.
Strict 100% will use bits 0 and 1 to perform a write and read to examine the flash quality.
Setup Range allows you to specify the percentage of the flash media that gets checked. The
range can be set from 1% to 100%.

Quick Erase

This will perform a quick erase on any card inserted into any port, including the reader port.
Do not run the erase function with your master card in the duplicator.

Full Erase

This will perform a full erase on any card inserted into any port, including the reader port.
Do not run the erase function with your master card in the duplicator.

System Update

This will update the system firmware from the card in the Reader port. Do not attempt to
perform an update unless directed to by Technical Support.

Setup Menu Flowchart

OK
6. Setup
OK
This setting specifies which of the 6 Main
1. Start-up Menu
Menu items is the default that shows on
start-up.
▼
OK This setting can be set to
2. Copy Area
Only Data Area and Whole
Area.
▼
OK
Turn the Button Beep ON or OFF.
3. Button Beep
▼
This setting determines how long the
OK
4. Asyn Hold Time system will wait before continuing or
exiting an Asynchronous duplication job.
▼
Sets the tolerance percentage of source
OK
5. Ignore Size
and target flash capacity difference.
▼
OK
This must be set to ON for
6. Asynchronous
Asynchronous duplication.
▼
This setting specifies the
OK
7. Language language displayed on the
interface.
