- Page 1 MS700i Series Laser Bar Code Projection Scanner Installation and User’s Guide MLPN 2178 Printed in USA October 1998...
-
Page 2: Table Of Contents
MS700i and MS720i Features ........14... - Page 3 Depth of Field and Symbol Specification for the MS700i and MS715i . 28, 29 Depth of Field for the MS720i Scanner ......30 Depth of Field and Symbol Specification for the MS720i .
-
Page 4: Introduction
For close scanning, the MS700i and MS715i’s depth of field of 0.0mm - 178mm (0" - 7") is ideal. To accommodate applications where scanning items farther away from the scan window is preferred, the MS720i’s depth of field of 178mm - 381mm (7"... -
Page 5: Unpacking List
Installation and User’s Guide (MLPN: 2178) ScanSelect™ Scanner Programming Guide (MLPN: 2186) Volume Control Card (MLPN: 2346) MS700i /MS715i or MS720i Laser Bar Code Projection Scanner Power Supply (optional) Communication cable with connection for power supply (optional) or Communication Cable (optional) -
Page 6: Scanner Connections To The Host
2. Connect the 25-pin D-type connector on the scanner’s head cable to the communication cable. Connect the other end of the communication cable to the host device. (If the scanner will not receive power from a transformer, skip to Step 5.) 3. -
Page 7: Configuration Of The Scanner To The Host System
ScanSelect guide have an asterisk that appears before the brief definition next to the bar code. For the scanner to properly communicate with the host system, it needs to be programmed to meet the specific scanning needs. Since each host system is unique, configure the scanner to match the host system requirements. -
Page 8: Cloning Feature
2. Connect the cloning cable between the two scanners. 3. Turn both scanners on by plugging in the transformers. 4. Once each scanner is ready, scan the cloning bar code with the scanner that has the settings that need to be transferred to the other scanner. -
Page 9: Version 11 Ibm 46Xx Scanner
The IBM 1520 mode/address was selected as a default because it was the first IBM 46XX family scanner to support UPC/EAN, Code 39 and Interleaved 2 of 5. The Version 11 scanner formats Codabar, Code 128, and Code 93 using the Code 39 function code designation supported by the IBM device driver for this scanner type. -
Page 10: Configuring The Scanner
Configuring the Scanner Located in the Version 11 scanner are two computer boards. One board is for decoding and the other for 46XX IO processing. The decode board is configured using ScanSet™ or ScanSelect™ while the IO board is configured with an internal DIP Switch bank. -
Page 11: Configuring The Ibm 46Xx
It should be listed under the Port 9A, 9B, 9C, or 9E sections. The 4693 terminal has a Port 5B that was originally used for the IBM 1520 scanner. While IBM has withdrawn this product, it was not clear how terminal configuration and device driver support would be provided for the installed base of users. -
Page 12: Scanner Installation To A Pc Keyboard Port
The kit also includes an adaptor cable. This cable allows the ® scanner to plug into an IBM PC XT or AT compatible computer or a PS/2 computer and keyboard. With the appropriate communication cable, the scanner will also provide RS- 232 or light pen emulation interface. - Page 13 4. Plug the communication cable to the PC and the keyboard. (Refer to Figure 1). 5. Connect the 25-pin D-type connector on the scanner’s head cable to the communication cable. 6. Check the AC input requirements of the transformer to make sure the voltage matches the AC outlet.
-
Page 14: Pc Application Note
Note: Once the scanner connects to the PC, the PC can be turned on and will operate normally even if the scanner's transformer plug is not in. How- ever, bar codes will not be read until the scanner receives power. When the scanner first receives power, the LEDs will flash and then the scanner will beep once. -
Page 15: Installation Of The Ms700 Series Stand
Installation of the MS700 Series Stand The following are components used to build the MS700 Series stand (MLPN: 45483): Figure 2 Shoe Mount Four Wood Screws Stand Cover One Machine (¼-20) Screw Stand Base Internal Lock Washer Flexible Shaft 1. Use the 2½ inch x 2½ inch stand base to mark the position for pilot holes. -
Page 16: Attaching The Scanner To The Stand
Once the stand is securely mounted to the work surface, attach the scanner. The scanner has a “foot” that is at the bottom of the scanner. This foot fits into the “shoe” attached to the top of the stand. This construction helps prevent the scanner from being knocked from the stand. -
Page 17: Ms700I And Ms720I Features
MS700i and MS720i Series Features Figure 4 Speaker The sound of a beep emits from here when the scanner performs a good read of a bar code. Green and Red LEDs When the green LED is on, this indicates that the unit is receiving power and the laser is on. -
Page 18: Visual Indicators
When the scanner successfully reads a bar code, the red LED will flash followed by one beep. If you do not see the red LED flash or the scanner beep once, then the bar code has not been successfully read. - Page 19 La diode verte reste allumée; la diode rouge clignote Après lecture avec succès d'un code à barres par le scanner, la diode rouge se met à clignoter, suivie d'un bip sonore unique. Si la diode rouge ne clignote pas ou quand aucun bip sonore n'est émis, cela signifie que le code à...
- Page 20 Zeigt an, daß sich der Scanner im Programmiermodus befindet. Feststehende rote Leuchtanzeige Zeigt an, daß sich der Scanner im ScanSet-Modus befindet. Aufblinkende rote Leuchtanzeige Zeigt an, daß beim Scanner ein Laserausfall vorliegt. Bringen Sie das Gerät zur Reparatur in ein Vertragsservicecenter.
- Page 21 Sono accesi sia il diodo luminoso rosso che quello verde Dopo la scansione riuscita lo scanner trasmette i dati all’host. Se l’host non è pronto per accettare i dati, il diodo luminoso rosso dello scanner è acceso fino a che i dati possono essere trasmessi.
-
Page 22: Volume Settings
Volume Settings There are four volume settings available: low, medium, high and no volume. The operator can temporarily change the volume of the scanner by scanning the bar codes on the volume control card. To permanently change the volume of the scanner, enter program mode and scan the appropriate volume setting bar code in Section C of the ScanSelect Programming Guide or use ScanSet. -
Page 23: Labels
CDRH Class IIa laser product and IEC 825 LASERKLASSE 1. Also on each scanner is a label located on the back of the unit. This label contains information such as the model number, date of manufacture, serial... -
Page 24: Infrared (Ir) Object Sensor
An infrared (IR) device located below the LEDs and above the scanner output window (refer to the section, MS700i and MS720i Features page 14) initiates the scanning process. As long as power is applied to the unit, the IR sensor projects a signal that extends approximately seven (7) inches beyond the output window. -
Page 25: Symbol Orientation
Symbol Orientation To scan a symbol, it may be oriented in any of the degree angles shown in Figure 5. The roll, pitch, and yaw are 360E, ±60E, and ±60E respectively. Figure 5... -
Page 26: Active Scan Region For The Ms700I And Ms715I Scanner
Active Scan Region for the MS700i and MS715i Scanner The active scan region is the region within the depth of field of the five scan segments in which the laser beam can intercept and read symbols oriented as shown in the section Symbol Orientation page 22. Planes formed by each of the five scan segments define the bottom of the region. -
Page 27: Horizontal Scan Width Vs. Distance For The Ms700I And Ms715I Scanner
The bottom of the region is 7" from the scanner window. Planes formed by each of the five scan segments define the sides. The 203mm (8.0") depth of field of each of the scan segments bound the top. - Page 28 Horizontal Scan Width vs. Distance for the MS700i and MS715i Scanner The following illustration notes the measurements of the horizontal scan width at given distances. Figure 8...
-
Page 29: Horizontal Scan Width Vs. Distance For The Ms720I Scanner
Horizontal Scan Width vs. Distance for the MS720i Scanner The following illustration notes the measurements of the horizontal scan width at given distances. Figure 9... -
Page 30: Depth Of Field For The Ms700I And Ms715I Scanner
This 0.0mm - 178mm (0" - 7") range is the depth of field for the MS700i and MS715i scanner (refer to Figure 10). This area of active scanning projects out from the glass on the face of the scanner to about 7 inches. -
Page 31: Depth Of Field And Symbol Specification For The Ms700I And Ms715I
Depth of Field and Symbol Specification for the MS700i and MS715i (Refer to Figure 11) Code Type Minimum Small Code Density Element Mil. (1/1000") UPC/EAN 10.4 UPC/EAN 13.0 100% Code 39 High Code 39 12.0 Medium Code 39 21.0 I 2 of 5... - Page 32 Figure 11...
-
Page 33: Depth Of Field For The Ms720I Scanner
Like an image expands from a film projector as it moves toward the screen at a movie theater, the scan pattern projects out to a well-defined region. Any label that is facing toward the scanner can be read at any point within the scanning field. -
Page 34: Depth Of Field And Symbol Specification For The Ms720I
Depth of Field and Symbol Specification for the MS720i (Refer to Figure 13) Code Type Minimum Small Code Density Element Mil. (1/1000") UPC/EAN 10.4 UPC/EAN 13.0 100% Code 39 12.0 Medium Code 39 21.0 I 2 of 5 12.0 Medium I 2 of 5 21.0 Codabar... - Page 35 Figure 13...
-
Page 36: Maintenance
Therefore, the output window will need occasional cleaning. 1. Spray glass cleaner onto lint free, non-abrasive cleaning cloth. 2. Gently wipe the scanner window. Applications and Protocols The model number on each scanner includes the scanner number and communications protocol. Scanner Version Identifier... -
Page 37: Appendix A Specifications
Appendix A Specifications Application: Laser Bar Code Projection Scanner Light Source: VLD 675 ± 5 nm, Maximum output 1mW CDRH: CLASS IIa laser product EMC: EN 60950: 1993, EN 60825:1:1994, laser class 1, EN 55022:1987 Class A, EN 55082-1:1992, IEC 801-2:1991 8kVAD, IEC 1004-3:1995 3V/m... - Page 38 Operational Depth of Field: - 0.0mm - 178mm (0" - 7") MS700i, MS715i - 178mm - 381mm (7" - 15") MS720i Scan Speed: 2000 scan lines per second MS700i, MS720i 1000 scan lines per second MS715i Scan Pattern: 5 scan fields: 1 horizontal, 4 at angles...
-
Page 39: Appendix B Default Settings
The scanner is shipped from the factory programmed to a set of default conditions. The default parameter of the scanner has an asterisk ( * ) in the charts on the following pages. If an asterisk is not in the default column then the default setting is Off or Disabled. - Page 40 Parameter Default OCIA 46XX 232* Minimum Symbol Length Symbol Length None Lock SWEDA Fujitsu OMRON IBM Parallel Bars High as Code 39 Spaces High as Code 39 Bars High as Scanned Spaces High as Scanned DTS/SIEMENS DTS/NIXDORF NCR F NCR S Poll Light Pen Source Beeper Tone...
- Page 41 Parameter Default OCIA 46XX 232* Three Beeps on Timeout No Beeps on Timeout IR Timeout 10 Min. Same Symbol Rescan Timeout: 200 msecs Same Symbol Rescan Timeout: 500 msecs Same Symbol Rescan Timeout: 1250 msecs Same Symbol Rescan Timeout: 2000 msecs Scanability Intercharacter...
- Page 42 Parameter Default OCIA 46XX 232* Transmit UPC- A Number System Transmit Codabar Start/Stop Characters CLSI Editing (Enable) Transmit Mod 43 Check Digit on Code 39 Transmit Code 39 Stop/Start Characters Transmit Mod 10/ITF Transmit Code 11 Check Digit Transmit MSI- Plessey Check Characters Parity...
- Page 43 Parameter Default OCIA 46XX STX Prefix ETX Suffix Carriage Return Line Feed Tab Prefix Tab Suffix "DE" Disable Command "FL" Laser Enable Command Handshaking Support RTS/CTS Handshaking Character RTS/CTS Message RTS/CTS XON/XOFF Handshaking ACK/NAK Parallel Light 232*...
- Page 44 Parameter Default OCIA 46XX 232* Special Software is required for the following: Two Digit Supplements Five Digit Supplements Bookland 977 (2 digit) Supplemental Requirement Supplements are not Required Two Digit Redundancy Five Digit Redundancy 200 msec to Find Supplement 100 msec to Find Supplement Parallel...
-
Page 45: Appendix C Pin Assignments
The communication cable may include a connection for a transformer or it may be designed to draw power directly from the host device. This item can be ordered at the same time scanner is purchased. The version “1” and “21” scanners are designed to be used for RS-232, OCIA or Light Pen Emulation communication. - Page 46 Version “2” Pin Assignments for Parallel Communication The version “2” scanner head cable is terminated with a male 25-pin D-type connector. To connect the scanner to the host device, may require a communication cable. The communication cable may include a connection for a transformer or it may be designed to draw power directly from the host device.
- Page 47 This item can be ordered at the same time scanner is purchased. The version “26” scanner is designed to be used for Point to Point RS-422 communication.
- Page 48 The communication cable may include a connection for a transformer or it may be designed to draw power directly from the host device. This item can be ordered at the same time scanner is purchased. The version “11” and “24” scanners are designed to be used primarily with IBM®...
-
Page 49: Pin Assignments
Version “17” Pin Assignments for Keyboard Wedge, RS-232 and Light Pen Emulation The version “17” scanner head cable is terminated with a male 25-pin D-type connector. To connect the scanner to the PC, may require a communication cable and a transformer. The communication cable is terminated to two 5-pin DIN connectors that will directly connect to an IBM PC XT or AT compatible computer and keyboard. -
Page 50: Warranty And Disclaimer
Appendix D Warranty and Disclaimer Limited Warranty Products manufactured by Metrologic have a 2-year limited warranty from date of manufacture. In the event that it is determined that the equipment failure is covered under the warranty, Metrologic shall, as its sole option, repair, replace with a functionally equivalent unit, or refund an amount equal to the purchase price to the original purchaser, whether distributor, dealer/reseller, or retail consumer, and return the equipment to the customer without charge for service or return freight. - Page 51 Disclaimer Metrologic Instruments, Inc. and the author or authors make no claims or warranties with respect to the contents or accuracy of this publication, or the product it describes, including any warranties of fitness or merchantability for a particular purpose. Any stated or expressed warranties are in lieu of all obligations or liability for any damages, whether special, indirect, or consequential, arising out of or in connection with the use of this publication or the product it describes.
-
Page 52: Appendix E Notices
Under no circumstances should the customer attempt to service the laser scanner. Never attempt to look at the laser beam, even if the scanner appears to be nonfunctional. Never open the scanner in an attempt to look into the device. Doing so could result in hazardous laser light exposure. - Page 53 Umständen versuchen, den Laser-Scanner selbst zu warten. Sehen Sie niemals in den Laserstrahl, selbst wenn Sie glauben, daß der Scanner nicht aktiv ist. Öffnen Sie niemals den Scanner, um in das Gerät hineinzusehen. Wenn Sie dies tun, können Sie sich einer lebensgefährlichen Laserstrahlung aussetzen.
-
Page 54: Appendix F Patents
Appendix F Patents “Patent Information This METROLOGIC product may be covered by one or more of the following U.S. Patents: U.S. Patent No. 4,360,798; 4,369,361; 4,387,297; 4,460,120; 4,496,831; 4,593,186; 4,607,156; 4,673,805; 4,736,095; 4,758,717; 4,816,660; 4,845,350; 4,896,026; 4,923,281; 4,933,538; 4,992,717; 5,015,833; 5,017,765;... -
Page 55: Volume Control Card
Configuration 4, 6, 8, 9, 46 Contrast 35 Copyright Visual 15-18 Current 34 Interfaces Customer Service ii, 47 Installation Scanner Stand DC transformer 36-41 1, 23, 24, 27- 36-46 ii, 47 14, 35 3, 11, 14, 15, 3, 4, 34, 42-45... - Page 56 33, 35 Scan field(s) Mechanical Scan lines Model number 20, 33 Scan pattern Scanner connections ScanSet 1, 4, 7, 15-19, 21, 46 Notices 49, 50 ScanSelect manual 4, 7, 9, 19, 21, 46 Scan speed OCIA 33, 35, 42, 45...
- Page 57 UL/CSA/TUV USA corporate headquarters Ventilation Version identifiers Voltage 3, 10, 34 Volume control card 52, 53 Warranty Watt(s) 1, 34 Weight 34 Window 1, 24, 27, 30, 33-35...
