Summary of Contents for LCG Thunder 400
- Page 1 FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE POWERING OR INSTALLING YOUR LED WASH, Save it for future reference.
-
Page 2: Table Of Contents
TABLE OF CONTENTS LED Strobe Fixture 1.GETTING STARTED ..............2 UNPACKING ..................... 2 INTRODUCTION ....................2 Powering Up! ....................2 Getting A Hold Of Us ................... 2 SAFETY INSTRUCTIONS .................. 3 2. MEETFIXTURE LED STROBE FIXTURE ......... 4 MAIN FEATURES....................4 DMX Quick Reference (1/3/4/6/7/16-Channel Modes) .......... -
Page 3: Getting Started
1.GETTING STARTED UNPACKING • 1 x LED Strobe • 1 x Base Plate /Mounting Brackets • A Sweet Safety Cable & eyebolt • A Power Cord • User Manual Carefully check the shipping carton for damage that may have occurred during shipping. -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS Please read these instructions carefully they include the important information about the installation usage and maintenance of this products Please note: Certain people with epilepsy and photosensitivity may suffer a seizure if exposed to flashing or strobe lighting. If strobe lighting is to be used in a production, warnings should be posted at the front of house or entrance doors to the theater as well as in a program, if distributed. -
Page 5: Meetfixture Led Strobe Fixture
2. MEETFIXTURE LED STROBE FIXTURE MAIN FEATURES • Super bright output via 1,452 white SMD LEDs • Intense built-in strobe programs + random strobe • 3/9-segment pixel modes can safely be used as wash (max 40% brightness) • Built-in over heat protection temperature sensor to extend the lamp life •... -
Page 6: Figure 1: The Fixture Pin-Up Picture
Figure 1: The fixture Pin-Up Picture 1452pcs Bright LEDs Locking Knobs Durable Cast Aluminum Mounting Housing Bracket Figure 2: The Rear Connections Natural Convection Easy-To-Use4-Button Heat Sink Cooling LCD Control Panel AC Power Out 3 pin XLR AC Power in... - Page 7 Figure 3: Setting on the floor...
-
Page 8: Setup
3. SETUP Before replacing a fuse, disconnect power cord, Always replace with the same type and rating of fuse Fuse Replacement CAUTION! The fixture utilizes a high-output switch-mode power supply with an internal fuse. Under normal operating conditions, the fuse should not require replacement. The fuse is field replaceable, however it is an advanced procedure suited to qualified individuals. -
Page 9: Data/Dmx Cables
Data/DMX Cables To link fixtures together you’ll need data cables. You should use data grade cables that can carry a high quality signal and are less prone to electromagnetic interference. For instance, Belden© 9841 meets the specifications for EIA RS-485 applications. -
Page 10: Take It To The Next Level: Setting Up Dmx Control
Take It To The Next Level: Setting Up DMX Control Step 1: Connect the male connector of the DMX cable to the female connector (output) on the controller Step 2: Connect the female connector of the DMX cable to the first fixture’s male connector (input). -
Page 11: Mounting & Rigging
Mounting & Rigging This fixture can be mounted in any orientation (vertical, horizontal). Always make sure there is adequate ventilation and no flammable surfaces within 2 feet (.6 meters) of the fixture. You can mount the fixture using fixture clamps or with threaded bolt type hardware. -
Page 12: Operating Adjustments
compound onthreaded bolts as an extra precaution to ensure that the fixture installation is secure and safe. 4. OPERATING ADJUSTMENTS The Control Panel All the goodies and different modes possible with the fixture are accessed by using the control panel on the front of the fixture. There are 4 control buttons below the LCD display which allow you to navigate through the various control panel menus. -
Page 13: Control Panel Menu Structure
Control Panel Menu Structure Menu Sub-menu Address Set DMX 001-512 Address Auto Mode 1 Auto Mode 1 Mode 2 Auto Mode 2 Mode 3 Auto Mode 3 Mode 4 Auto Mode 4 Mode 5 Auto Mode 5 Speed 000-031 Auto Run Speed Test LED All on All On + Individual LED Segment... -
Page 14: Dmx Mode
DMX Mode Allows the unit to be controlled by any universal DMX controller. Set the Starting DMX Address: The default mode for the fixture is DMX, so the first menu item that you can edit is the starting DMX address. 1.) Press the <UP/DOWN>... -
Page 15: Temperature
Additional Features: Never thought you would ever see so many nifty neato features in a strobe light did you? Temperature: IMPORTANT - Brightness will decrease when the LED temperature rises over 55ºC. If a temperature of +70ºC is reached, the overheat protection sensor will activate, initiating blackout until a safe temperature is reached. -
Page 16: Dmx Values In-Depth (16-Channel Mode)
DMX Values In-Depth (16-Channel Mode) Fuction Value 000 <--> 255 Dimmer (0% <--> 100%) 000 <--> 255 Segment 1-3 Intensity (0% <--> 100%) 000 <--> 255 Segment 4-6 Intensity (0% <--> 100%) 000 <--> 255 Segment 7-9 Intensity (0% <--> 100%) 000 <-->... - Page 17 DMX Values In-Depth (6-Channel Mode) Value What It Does 000 <--> 255 Dimmer (0% <--> 100%) 000 <--> 255 Segment 1-3 Intensity (0% <--> 100%) 000 <--> 255 Segment 4-6 Intensity (0% <--> 100%) 000 <--> 255 Segment 7-9 Intensity (0% <--> 100%) 000 <-->...
-
Page 18: Troubleshooting
DMX Values In-Depth (9-Channel Pixel Mode) Value Function 000 <--> 005 No Function 006 <--> 255 Segment 1 Intensity (0% <--> 100%) 000 <--> 005 No Function 006 <--> 255 Segment 2 Intensity (0% <--> 100%) 000 <--> 005 No Function 006 <-->... -
Page 19: Appendix
5. APPENDIX MAINTENANCE ALWAYS DISCONNECT POWER BEFORE CLEANING NEVER REMOVE THE GROUND PRONG FROM POWER CORD NEVER SPIN A FAN WITH COMPRESSED AIR, this can damage components in your fixture Your fixture will require regular cleaning to prevent a build up of dust and smoke debris on the optics and housing.
