- Page 1 D-LED TV DVB-T2 OpEraTing insTrucTiOn please read these instructions before operating your set and retain them for future reference. Model: K32D301B2...
-
Page 3: Table Of Contents
Contents Features � � � � � � � � � � � � � � � � � � � � � � � � � � � � �3 PICTURE� � � � � � � � � � � � � � � � � � � � � � � � � �12 Safety Warning and Notice �... -
Page 4: Safety Warning And Notice
saFety Warning and notiCe Thank you for choosing the LED TV with LED backlight made by our company, a valuable product with excellent quality and multiple functions� This device will bring you more audiovisual enjoyment� Its design ensures user’s safety� All devices are strictly tested before leaving factory�... -
Page 5: Mounting And Connecting
Do not touch the plug with wet hands, or else it may cause electric shock� Do not turn on the TV set in thunderstorm weather; instead, unplug the power plug and antenna connector to avoid lightning strike� Do not disassemble the TV set by yourself as this can cause electric shock or fire� Contact qualified personnel for maintenance�... -
Page 6: Connecting Peripheral Equipment
Mount on the wall Mount on the base 30cm 30cm 10cm 10cm 10cm 10cm 10cm Obstructs the air circulation Obstructs the air circulation Ventilation • Please keep the minimum space around the TV as shown in the figure� • Do not cover air vents or insert any objects into the enclosure�... - Page 7 Yellow (Video signal cable) Connecting power supply White(AUDIO-L signal cable) Antenna connection Red (AUDIO-R signal cables) To power socket (100-240VAC 60/50Hz) USB interface Warning When connecting outdoor antenna to signal port of the TV set, please turn off the main power switch of the TV set first.
-
Page 8: Control Panel Keys
control panel Keys 1� Power LED indicator and remote receiving window� 2� Standby: To switch the TV on or back to standby� 3� MENU ( ): Press this key to enter main menu� 4� VOL-, VOL+ ( ): Press these two keys to add or reduce volume� In OSD menu, press the two keys to adjust the analogue value of the selected item�... - Page 9 5� Do not use different batteries� Combining new and old batteries is not allowed� You should use batteries in pair� 6� Do not throw batteries into fire, do not charge or disassemble, especially do not charge, assemble or disassemble, heat or burn used batteries� Please observe the related environmental protection regulations on used batteries� remote control Key instruction Note: Appearance of the remote control can differ from the one shown in the figure.
-
Page 10: General Operating Instructions
remote control user manual about teletext TeleText: Press ‘’Teletext’’ key, it loops in 3 modes: Mix Display > Text Mode > TeleText Off� Thereinto: TText Mode is Automatic Mode� In Automatic mode, the system automatically selects TOP, Fastext, or Default mode as appropriate, depending on the data being received� In Text Mode or Mix Display, press number 0~9, “/’’... -
Page 11: Signal Source Selection
signal source selection Press “SOURCE” key either on the remote control or on the panel� ‘’Input Source’’ will be displayed on the screen (Fig�3)� Then press “/’’ key on remote control or “CH+/CH-” key on the panel to select the signal source�... -
Page 12: Picture
DTV Manual Tuning DTV Manual Tuning Press “MENU” key and CHANNEL menu will be displayed on the screen� Press “/” key to select DTV Manual Tuning� Press “OK” key to enter into DTV UHF CH 21 Manual Tuning menu (Fig�6)� Press “t/u” key to select channel, then press “OK”... -
Page 13: Sound
Item Function Description Picture Mode Selecting picture mode “Standard”, “Soft”, “User Dynamic” four modes� Contrast Adjusting contrast of whole picture Increasing analogue value increases Contrast; Decreasing analogue value decreases Contrast (0~ 100)� Brightness Adjusting brightness and black level Increasing analogue value increases brightness; of whole picture Decreasing analogue value decreases brightness (0~ 100)�... -
Page 14: Options
OpTiOns Press “MENU” key and CHANNEL menu will be displayed on the screen� Press “t/u“ key to select OPTIONS (Fig�11), then press “/” key to select the OSD Language English item you want to adjust or set� Audio Language English Hearing Impaired Off PVR File System OSD Language: Press “OK”... -
Page 15: Lock
LOcK Press “MENU” key and CHANNEL menu will be displayed on the screen� Press “t/u“ key to select LOCK� After pressing “OK” key, press Numerical key Lock System to input default password 0000 and enter LOCK menu Set Password (Fig�14)� Then press “/” key to select the item you Block Program want to adjust or set�... -
Page 16: Time-Shift Option
Time-shift option In DTV mode, press “ZOOM” key� Time-shift option Time Shift menu will be displayed on the screen (Fig� 16) and the programme will be in suspended state� Press “INDEX” key to resume the programme� Press “REVEAL” key to stop and quit time-shift� When user leaves programme for a short time, time-shift function can suspend and cache the playing programme to a U disc�... -
Page 17: Usb Media Function
usB Media Function USB 2.0 Please insert USB storage device into USB interface of TV and press “SOURCE” key� “Input Source” menu will be displayed on the screen� Then press “/” key to select USB� Press “OK” key to enter USB (Fig�19)�... - Page 18 Icon Description Playlist: Press “t/u“ key to select this function� Press “OK” key to view playlist� Info. : Press “t/u“ key to select this function� Press “OK” key to view photo information, including resolution, size and so on� Rotate: Press “t/u“ key to select this function� Press “OK” key to rotate photos clockwise� Rotate: Press “t/u“...
-
Page 19: Simple Troubleshooting
simple troubleshooting Symptom Cause Solution 1� Antenna cable connector is loose, 1� Check if the antenna cable connector plug is cable is damaged� loose and if the cable is perfect� Snowflake speckle and 2� Antenna cable type does not match� 2�... -
Page 20: Technical Specifications
Technical specifications Master unit Panel size 32" Max� Resolution 1366×768 Best Resolution 1360×768@60Hz Pixel Pitch 0�51075mm×0�51075mm Active Area 697�685mm×392�256mm Power Supply 100-240VAC 60/50Hz Power Consumption of Speaker 6W+6W Dimension (L x H x W) and Weight Panel size The base Unpacking Packing Net Weight... -
Page 21: Base Installation Instructions
