Stop Button - Lexicon Alpha Owner's Manual

To check the input level from the microphone or Line Input:
1. If you are using a mic and have connected the Alpha Studio™ to studio monitors,
turn them down or off to avoid feedback.
2. If you want to hear the audio source in headphones, turn up the Alpha Studio
Output Level knob and turn the Monitor Mix knob counter-clockwise
(towards the Direct side). Press the Monitor Assign button so it is in the
Mono position. This will let you hear output on both sides of your headphones
when recording only one microphone or line level source.
Input Louder Playback Louder
Playback Softer Input Softer
Monitor Mix
3. Speak or sing into the microphone or play the line level source while gradually
increasing the gain by turning up the Line 1/Inst or Line 2/Mic knob; it's OK
to see the Peak LED light next to the Line 1/Inst or Line 2/MIc knob flash
occasionally.
To start recording:
1. Click the Record button on Cubase
Record Button
2. Speak or play an instrument into the microphone or line input.
3. When you are finished recording press the Stop button.

Stop Button

4. Press Rewind and press the Play button to listen to the track you have just
recorded.
Recording Using the Microphone/Line Input
Monitor Button
® LE 4's Transport control.
23
