Video Equipment Connections

Enjoy the stunning visuals of a DVD or VCR by connecting them to this TV set through its audio/video in terminals.
FRONT
ON TIMER POWER SAVE
REAR
AV-1 IN AV-2 IN OUT
S-VIDEO VIDEO OUT
(AV-1 IN)
L
AUDIO (MONO) AV-1
R IN
Video in Video out
AV-1 IN AV-2 IN OUT
S-VIDEO
VIDEO
(AV-1 IN)
L
(MONO)
AUDIO
R
Audio out
S-Video in Audio in
NOTE :
• When a VCR is connected via the Antenna in, tune the TV to the VCR using preset channel 0.
• With this TV set, you can play back stereo-recorded video cassettes in stereo via the audio/video terminals.
• For monaural input, connect the external source to the audio in left terminal (AUDIO IN L (MONO)) to hear the same sound from both speakers. If monaural
equipment is connected to the audio in right terminal (AUDIO IN R), you will hear sound from only one of the speakers.
AV-1 IN AV-2 IN
VIDEO
L
Stereo
(MONO)
AUDIO
(AUDIO IN)
R
<Example of connection>
Front terminals (Behind the door)
<Example of connection>
AV-1 IN AV-2 IN
S-VIDEO
VIDEO
(AV-1 IN)
L
(MONO)
AUDIO
R
TV set
Antenna In
OUT
Stereo
(AUDIO OUT)
23
AV-3 IN
VIDEO L-AUDIO-R
(MONO)
To S-Video
out terminals
To Audio/Video
out terminals
OUT
To Audio/Video
in terminals
To Audio/Video
out terminals
AV-1 IN AV-2 IN
VIDEO
Mono
(AUDIO IN)
L
(MONO)
AUDIO
R
Camcorder
To Audio/Video
out terminals
To RF out
To
antenna in
VCR
Editing
VCR
Laser Disc Player or
Video CD Player
OUT
Stereo
(AUDIO OUT)
