COLOUR TELEVISION
MODEL
CX68K5
OPERATION MANUAL
AV STEREO
Please read this operation manual
ON TIMER POWER
carefully before using the colour
SAVE
television.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CX68K5 and is the answer not in the manual?

Questions and answers

Related Manuals for Sharp CX68K5

Summary of Contents for Sharp CX68K5

  • Page 1 COLOUR TELEVISION MODEL CX68K5 OPERATION MANUAL AV STEREO Please read this operation manual ON TIMER POWER carefully before using the colour SAVE television.

  • Page 2: Table Of Contents

    After reading, keep this manual in a safe place for future reference. For access to information on all the latest technology brought to you by Sharp, visit our web site at www.sharp.net.au where you will nd our Connected Club, Product News, New Releases, Service , Educational resources, Sharp World Wide web links, plus much more.

  • Page 3: Accessories

    Safety Precautions (continued) Do not place this television equipment on an unstable cart, stand or table. The televi- sion equipment may fall, causing serious injury to a child or an adult and serious damage to the equipment. Use only with a cart or stand recommended by the manu- facturer, or sold with the television equipment.

  • Page 4: Location Of Controls

    Location of Controls Remote Control Infrared transmitter window STAND/ON ( ) button. • Aim this window at the infrared sensor window CHANNEL SELECT buttons ( , and on your TV set button). FLASHBACK ( ) button. • Returns to previously viewed channel. TV/VIDEO VOLUME UP ( ) / VOLUME DOWN (...
  • Page 5 Location of Controls (continued) TV front AV STEREO ON TIMERPOWER SAVE ON TIMER POWER SAVE Infrared sensor window POWER ( ) switch POWER SAVE indicator POWER ( ) indicator ON TIMER indicator Behind the Door VIDEO INPUT terminal (AV-3) HEAD PHONE jack PRESET / MENU button PRESET AV-3 IN...

  • Page 6: Basic Operation

    Basic Operation TV set Remote Control AV STEREO STANDBY/ON ) button TV/VIDEO (Behind the Door) CHANNEL UP/DOWN ON TIMER POWER SAVE CH ¶ buttons MENU AV MODE NORMAL POWER SAVE ON TIMER POWER SAVE CHANNEL UP/DOWN buttons POWER ( indicator POWER ( ) switch Turning on the power...
  • Page 7 TV/VIDEO Basic Operation (continued) Adjusting the Volume Press the VOLUME UP ( ) or DOWN ( ) buttons to adjust the volume. The number of oval blocks “ ” indicates the MENU volume level. AV MODE NORMAL The display disappears approximately three seconds after the volume adjustment has POWER SAVE...

  • Page 8: Language Selection

    Language Selection On-screen Display language selection 6-LANGUAGE ON-SCREEN DISPLAY (Behind the door) n The language for this unit’s On-screen Display can be set to ENGLISH, CHI- PRESET / MENU NESE, FRENCH, RUSSIAN, MALAY or ARABIC. n Setting the On-screen Display lan- guage 1 , 3 Press the PRESET/MENU button on...

  • Page 9: Presetting The Channels (Manual)

    Presetting the channels (MANUAL) Manual Channel Preset (Manual) Tuning in one or more channels (e.g. tuning the TV to a VCR, tuning in an additional TV station.) NOTE : This TV is already tuned into 2, 7, 9, 10 and 28. Press the PRESET/MENU button on the (Behind the door) TV set for more than two seconds.

  • Page 10: Presetting The Channels (Auto)

    Presetting the channels (AUTO) Full Auto Channel Preset (AUTO) Automatically tunes in and presets all receivable TV stations, using consecutive channels numbers (e.g. 2, 7, 9, 10 will be stored as 1, 2, 3, 4). Press the PRESET/MENU button on PRESET the TV set for more than two seconds.

  • Page 11: Channel Settings

    Channel Settings Channel Settings Picture system settings for each channel Press the MENU button to call the MENU (MENU screen) screen. Remote control Press the CHANNEL UP ( ) or MENU DOWN ( ) buttons to select “CH- PICTURE SOUND SETTING”.

  • Page 12: Selecting The Menu Items

    Selecting the Menu Items TV/VIDEO This TV set allows you to adjust the picture and sound, and set the channels and other features using the On Screen Display with the remote control or from the TV set. Select the desired menu item by following the steps below and then refer to the indicated page for details.
  • Page 13 Selecting the Menu Items (continued) Menu Items AV STEREO MENU PICTURE SOUND FEATURE TIMER CH-SETTING :SELECT :ENTER MENU:RETURN ON TIMER POWER SAVE Operating guide PICTURE menu ------- Page 13 SOUND menu --------- Page 14 PICTURE (STANDARD) SOUND (STANDARD) CONTRAST BASS+ COLOUR SURROUND BRIGHTNESS...

  • Page 14: Picture Adjustment

    Picture Adjustment (MENU screen) Press the MENU button to call the MENU screen. TV/VIDEO MENU Press the CHANNEL UP ( ) or PICTURE SOUND DOWN ( ) buttons to select “PIC- FEATURE TIMER CH-SETTING TURE”. Press VOLUME UP ( ) or DOWN ( buttons to display the PICTURE menu.

  • Page 15: Sound Adjustment

    Sound Adjustment (MENU screen) Press the MENU button to call the MENU screen. MENU Press the CHANNEL UP ( ) or PICTURE SOUND FEATURE DOWN ( ) buttons to select “SOUND”. TIMER CH-SETTING Press VOLUME UP ( ) or DOWN ( TV/VIDEO buttons to display the SOUND menu.

  • Page 16: Feature Adjustment

    Feature Adjustment Blue Back : Automatically turns the screen blue after ve seconds if the broadcast signal is not received (e.g. when a TV station goes off the air. After 15 minutes of non-reception, the TV set enters standby mode.) Press the MENU button to call the MENU (MENU screen) screen.

  • Page 17: Auto Select

    Feature Adjustment (continued) Auto Select : When video equipment, such as a video game system or camcorder, is connected to the front terminals, this TV set automatically selects the input mode (AV-3) when the video equipment is turned on. (MENU screen) Press the MENU button to call the MENU screen.

  • Page 18: Vm (Velocity Modulation)

    1 video lead RCA to RCA and 2 audio leads RCA to RCA. For a Mono VCR, 2 leads are required, 1 video lead RCA to RCA and 1 audio lead RCA to RCA (RCA refers to the type of plug required to connect a Sharp VCR to this set.

  • Page 19: Timer Adjustment

    Timer Adjustment OFF Timer : Automatically turns power off after a set length of time has passed. Press the MENU button to call the MENU (MENU screen) screen. MENU PICTURE SOUND TV/VIDEO Press the CHANNEL UP ( ) or DOWN FEATURE TIMER CH-SETTING...

  • Page 20: On Timer

    Timer Adjustment (continued) ON Timer : Automatically turns power on after a set length of time has passed. Press the MENU button to call the MENU (MENU screen) screen. MENU Press the CHANNEL UP ( ) or PICTURE SOUND TV/VIDEO FEATURE DOWN ( ) buttons to select “TIMER”.
  • Page 21 Timer Adjustment (continued) Reminder : This function lets you know when a preset length of time has passed by displaying a countdown timer on the screen. This is useful for timer cooking while you watch TV. (MENU screen) Press the MENU button to call the MENU screen.

  • Page 22: Other Functions

    TV/VIDEO Other Functions AV mode Each time you press the AV MODE button, the mode switches between STANDARD, DYNAMIC and SOFT in that order. (STANDARD) MENU (DYNAMIC) STANDARD : Normal mode AV MODE NORMAL DYNAMIC : Dynamic mode (SOFT) SOFT : Soft mode POWER SAVE Flashback :...

  • Page 23: Power Save

    TV/VIDEO Other Functions (continued) Call : Displays the current channel number, the timer, and other settings on screen. Press the CALL ( ) button. The time remaining on the OFF TIMER, ON TIMER and REMINDER appear on the screen. MENU 0 : 07 Press CALL ( ) button again.

  • Page 24: Video Equipment Connections

    Video Equipment Connections Enjoy the stunning visuals of a DVD or VCR by connecting them to this TV set through its audio/video in terminals. FRONT <Example of connection> Front terminals (Behind the door) Camcorder AV-3 IN VIDEO L-AUDIO-R (MONO) ON TIMER POWER SAVE To Audio/Video out terminals...

  • Page 25: Troubleshooting

    Troubleshooting The following problems do not always indicate a hardware failure. Therefore, please use the troubleshooting guide below before calling for repair service. If, after following the guide none of the remedies work, unplug the TV set and call for service. Quick Service Check...

  • Page 26: SpeciCations

    Specications MODEL CX68K5X Receiving System TV Broadcasts / VCR PAL - B/G Playback VCR Playback PAL 60 Hz, PAL B/G, NTSC 3.58, NTSC 4.43 (Using Video-in terminals) VCR Playback PAL 60 Hz, PAL B/G, NTSC 3.58, NTSC 4.43 (Using S-Video-in terminals) Reception Channels AU0 - AU12 ch PAL - B/G...

  • Page 27: Warranty

    Consumer Electronic Products Congratulations on Your Purchase! This Sharp product is warranted against faults in materials and manufacture for a period of twelve (12)* months from the date of original purchase. If service is required during the warranty period, please contact your nearest SHARP Approved Service Centre.

  • Page 28: Sharp Corporation

    SHARP CORPORATION OSAKA, JAPAN SHARP CORPORATION OF AUSTRALIA A.C.N. 003 039 405 1 HUNTINGWOOD DRIVE, HUNTINGWOOD, N.S.W 2148 Printed in Australia TINS-7028CEZZ...
