Flow Knob
Flowmeter
0.5 L/min
Ball
Front Panel
Front Panel Indicators - Units with
SensO
2
The SensO
feature monitors the purity of oxygen generated
2
by the oxygen concentrator. If purity falls below factory preset
standards, indicator lights on the control panel will
illuminate.
Auto Shut Down
FIGURE 5.6
Part No 1143482
SECTION 5—OPERATING INSTRUCTIONS
FIGURE 5.5
OXYGEN PURITY
Use Backup
Below
Normal
O
Normal
Front Panel Indicators - Units with SensO2
Flowrate
Call Supplier
2
19
RED
YELLOW
GREEN
Perfecto
™
2
Series
