Cobalt Digital Inc 5590 Owner's Manual

Specifications
Standards
Analog Inputs:
Differential Input
Input Return Loss
Input A to D Quantization
A/D sampling rate
Frequency Response
K-Factor
SCH Phase
Differential Gain
Differential Phase
S/N
Chroma Luma Delay
Y/C Separation
Conversion Time
Digital Outputs:
Output Quantization
Output Return loss
Output Error Coding
Jitter Filter LBW
Operating Temperature Range
Humidity
Power
This product is not authorized for use in life support systems. Product
liability limited only to the replacement of this unit. Cobalt Digital Inc. does
not assume any liability for loss of use due to failure of this component.
Specifications subject to change without notice.
Cobalt Digital Inc.
2406 E. University Ave.
www.cobaltdigital.com Office: 217-344-1243
Rev. 1.2 dml Copyright 2003
NTSC, PAL, PAL(M), PAL(N), Secam
Analog Composite, Y/C or Component
YPbPr
Common Mode rejection < 4.8Vp-p
> 35 dB at 5 MHz
10-bit
8:4:4 (2x)
Y 0-5.0 MHz +/- 0.25 dB
< 1%
< 1 degrees
< 1.8%
< 0.8%
> 50 dB
< 2 ns
4-line adaptive, 4-line non-adaptive, 3-
line adaptive and notch filter
1.25H
6 with EDH
10 bits
>17 dB @ 270Mbit
SMPTE EDH
2Hz
40-100 degrees F.
40-120F Optional Heat Sink
(non-condensing)
4W Positive Rail
0.3W Negative Rail
Urbana, IL 61802 USA
Fax: 217-344-1245
Cobalt Digital Inc.
Model 5590
10-bit A/D
Analog Composite (4-line Adaptive Comb)
Y/C or Component YPbPr to
270Mb 4:2:2 SDI Decoder with EDH
Owner's Manual
Cobalt Digital Inc. 2003
