3.Door Station Mounting

DT601FE/KP Mounting
1
Drill a hole in the wall to match the size of the
mounting box and attach to the wall.
3
Attach the panel to the mounting box and
use screws supplied to fix the panel
Placing Name Label
Use a screwdriver to unscrew the screw,
and cock the host , then Placing Name
Label.
2
Connect the cable correctly
4
