Item: (Figure 5)
K. Push Handle Assembly w/Lock .................. 1
L. Miter Gauge Assembly w/Flip Stop ............ 1
M. Push Stick .................................................. 1
N. Blade Guard Assembly .............................. 1
O. Riving Knife ................................................ 1
P.
Arbor Lock Tool .......................................... 1
Q. Wrench 17mm ............................................ 1
R. Wrench 19/22mm ....................................... 1
S. Scoring Blade ............................................. 1
T.
Main Blade ................................................. 1
K
N
S
Figure 5. Miscellaneous components.
Model G0700 (Mfd. Since 5/14)
Qty
M
L
O
P
R
Q
T
Fasteners (Grouped by Usage)
Cap Screws M10-1.5 x 25 (Ext. Table) ............. 5
Flat Washers 10mm (Ext. Table) ...................... 5
Lock Washers 10mm (Ext. Table) ..................... 6
Set Screws M8-1.25 x 25 (Ext. Table) .............. 6
Hex Nuts M8-1.25 (Ext. Table) .......................... 6
Hex Bolts M6-1 x 16 (Fence Scale) .................. 2
Hex Bolt M6-1 x 25 (Fence Scale) .................... 1
Flat Washers 6mm (Fence Scale) ..................... 3
Lock Washers 6mm (Fence Scale) ................... 3
Hex Nuts M6-1 (Fence Scale) ........................... 3
Cap Screws M5-.8 x 12 (Switch) ....................... 2
Lock Washers 5mm (Switch) ............................ 2
Cap Screw M10-1.5 x 25 (Hose Support) ......... 1
Flat Washers 10mm (Hose Support) ................. 2
Lock Washer 10mm (Hose Support) ................. 1
Hex Nut M10-1.5 (Hose Support) ...................... 1
NOTICE
If you cannot find an item on this list, care-
fully check around/inside the machine and
packaging materials. Often, these items get
lost in packaging materials while unpack-
ing or they are pre-installed at the factory.
