Safety Instructions & Operators Manual
Zero Turn Radius Mower
Congratulations for buying a Country Clipper product. Your Country Clipper Zero Turning Radius
Riding Mower was designed and built to provide long and trouble free service. Keep in mind that it, like
any other mechanical device, can be potentially dangerous if used improperly, and hazard control and
accident prevention are dependent upon the awareness, concern, prudence, and proper training of
personnel involved in the operation, transport, maintenance, and storage of the equipment. Study this
manual and pay special attention to the important Safety Precautions on pages 4-6. Following these
instructions will help you continue to enjoy the trouble-free performance expected of your Country
Clipper product.
P-11776 (03/03)
Copyright, Shivvers Mfg., 2004

Advertisement

loading
Need help?

Need help?

Do you have a question about the JAZEE One and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Country Clipper JAZEE One

  • Page 1 Safety Instructions & Operators Manual Zero Turn Radius Mower Congratulations for buying a Country Clipper product. Your Country Clipper Zero Turning Radius Riding Mower was designed and built to provide long and trouble free service. Keep in mind that it, like...
  • Page 2: Table Of Contents

    Main Menu TABLE OF CONTENTS SAFETY ............................3 ACCIDENT PATTERNS TO AVOID......................3 SAFETY INSTRUCTIONS AND RECOMMENDATIONS................. 3 SAFETY INTERLOCK SYSTEM........................5 START UP AND OPERATION ....................6 CHECKLIST BEFORE OPERATION ......................6 CONTROL LOCATIONS ..........................6 OPERATION ..............................7 MOWING RECOMMENDATIONS ....................... 9 SPECIFICATIONS ........................9 MAINTENANCE ........................10 MAINTENANCE SCHEDULE........................
  • Page 3: In Place

    PEOPLE WHO OPERATE, SERVICE, CONTACT WITH THE ROTATING OR ARE OTHERWISE ASSOCIATED BLADE -- This accident usually happens with the Country Clipper Zero Turning when the operator is clearing the Radius Mower should be trained in its discharge chute of grass, (especially proper use and warned of its dangers.
  • Page 4: Mowed

    Table of Contents DO NOT MOVE JOYSTICK CONTROL container. Gasoline fumes can easily ignite. LEVER from forward position to reverse position rapidly. The speed and/or direction of travel is affected instantly by KEEP GASOLINE IN A WELL- movement of the Joystick Control Lever. VENTILATED AREA away from your living quarters and in tightly-capped DO NOT ALLOW CHILDREN TO...
  • Page 5 SAFETY INTERLOCK SYSTEM safety labels. Replace any safety label that is missing or damaged. Your Country Clipper Zero Turning Radius Mower is equipped with switches interlocked for WEAR PERSONAL PROTECTIVE your safety. EQUIPMENT. Eye, ear, feet and head protection is recommended.
  • Page 6 Table of Contents Check battery fluid level. START UP AND OPERATION Inspect V-belts. CHECKLIST BEFORE OPERATION Check tire pressure: Make sure fuel tank is full. Use regular Model Front tires Rear tires unleaded gasoline (see engine owner’s 12 psi 12 psi manual for more details).
  • Page 7 RELEASE PARKING BRAKE. Push brake lever down to release. IMPORTANT: Until the operator is familiar with the Country Clipper Zero Turning Radius Mower, he/she should follow these recommendations: Disengage the mower blades. Go very slowly until 11.
  • Page 8 Table of Contents AVOID HILL AND SLOPES. USE EXTREME 13. TO FREE WHEEL MACHINE: UNLOCK CAUTION WHEN MOWING UP OR DOWN TRANSMISSION: The Transmission Release Chains are located on each SLOPES. NEVER MOW ACROSS THE FACE side of the mower on the rear of the OF A SLOPE.
  • Page 9: Mowing Recommendations

    Table of Contents When mowing tall grass, make two passes, mowing off 1/2 of the desired MOWING RECOMMENDATIONS cut on the first pass, and then the desired height the second pass. Check Keep mower blades sharp. for hidden dangers first. Make sure deck and discharge are Go slowly for trimming.
  • Page 10: Maintenance

    Table of Contents MAINTENANCE CAUTION BEFORE PERFORMING ANY MAINTENANCE, TURN OFF ENGINE REMOVE KEY AND DISCONNECT SPARK PLUGS. USE EXTREME CARE WHEN WORKING ON MACHINERY. DO NOT WEAR WATCHES OR JEWELRY. DO NOT WEAR LOOSE FITTING CLOTHES, AND OBSERVE ALL COMMON SAFETY PRACTICES WITH TOOLS. MAINTENANCE SCHEDULE SERVICE WHEN...
  • Page 11: Maintenance Instructions

    Model Front tires Rear tires by the engine manufacturer and 12 psi 12 psi included in your Country Clipper Zero Models Turning Radius Mower information packet. Lug nuts should be torqued to 75 ft/lbs and checked regularly for tightness. NOTE: Air intake screen must be kept clean.
  • Page 12 Table of Contents V-BELTS: JOYSTICK CONTROL LEVER NEUTRAL ADJUSTMENT: All belts should be checked every 50 hours. Replace any belts found to be in With the engine running, if the machine poor condition. All belts are equipped travels in either direction when the with spring loaded belt tighteners and do Joystick Control Lever is in the neutral not require tightening adjustments.
  • Page 13 Table of Contents 9. JOYSTICK CONTROL LEVER 10. ADJUSTING FOR STRAIGHT FORWARD SENSITIVITY ADJUSTMENT TRACKING: To change the sideways turning response adjust as follows: In a large open area, actuate the Joystick Control lever into the full A. Remove the right hand fender skirt forward position.
  • Page 14 Table of Contents 11. JOYSTICK CONTROL LEVER DETENT HYDROSTATIC TRANSMISSIONS: ADJUSTMENT: Before each use, check to be sure that If the Joystick Control Lever does not the cooling fins of the hydrostatic lock in the “UP” position, turn the detent transmissions are clean.
  • Page 15 Table of Contents PROCEDURE FOR RAISING AND RELEASE HANDLE LOWERING THE DECK FOR SERVICING ROTATE 13. FLIPPING UP THE DECK: Park mower on hard flat surface. B. To remove the tension of the deck belt carefully rotate the RELEASE HANDLE on the left side of the deck From straight forward to straight back.
  • Page 16 Table of Contents E. While standing in front of the tractor, with your feet apart, lift the front of the tractor And the deck will swing out as shown. At this point set the tractor back down on top of the deck.
  • Page 17: Trouble Shooting Check List

    Table of Contents TROUBLE SHOOTING CHECK LIST ENGINE WON’T TURN OVER: Mower blades engaged ------------------------------------------------- disengage blades Drive not in neutral --- move Joystick Control Lever to neutral “DOWN” position Blown fuse ------------------------------------------------------------------------ replace fuse Dead battery --------------------------------------------------------------- charge or replace Solenoid ------------------------------------------------------------------------- consult dealer Ignition switch ------------------------------------------------------------------ consult dealer Starter ---------------------------------------------------------------------------- consult dealer...
  • Page 18 Table of Contents ENGINE SOMETIMES SKIPS AT HIGHER SPEEDS: Incorrect Ignition Timing ---------------------------------------------------- consult dealer Carburetor maladjusted ----------------------------------------------- readjust carburetor Faulty spark plugs -------------------------------------------------------- check spark plug condition and reset gap* Bouncing off seat safety switch -------------------------- slow down on rough terrain ENGINE OVER HEATED: Air intake screen or fins clogged ------------------------ clean intake screen and fins Fuel mixture too lean ------------------------------------------------- readjust carburetor*...
  • Page 19: Wiring Schematic

    Table of Contents WIRING SCHEMATIC Black wires = Ground Red wires = Power Blue wires = Kill Circuit BRAKE SWITCH Yellow wires = Start Circuit Green wires = Signal Circuit N.C. KOHLER ENGINE PLUG #2 TWIN LEVER STEER ONLY MAGNETO CHARGE OIL PRESSURE FUEL...
