step 2 - asseMblIng tHe Fan
1. Feed the wires and the steel ca-
ble support from the fan through
the canopy and the pipe.
2. Screw pipe into fan assembly until
tight. IMPORTANT! Tighten pipe
setscrew as shown in Figure 2.
Pipe Setscrew
Figure 2 - Assembling The Fan
44204-01
5/30/2007
WarNiNg
• Failure to complete the
steps above properly could
result in the fan falling.
CautioN
• The pipe adapter has a spe-
cial coating on the threads.
Do not remove this coat-
ing; the coating prevents
the pipe from unscrewing.
Once assembled, do not
remove the pipe.
