970 User Guide and Technical Information

Menu and Navigation

Main View

The Main View displays all audio input levels and provides configuration of Track Arming, Track
Naming, Input Source selection, Input Gain, and Input Delay. The Main View by default displays 16
tracks at a time. This can be changed to 8, 16, or 32 track displays in [Audio - Audio Screen Meters].
Press the LCD Button to quickly switch between banks of meters (8, 16, or 32 depending on the value
of [Audio - Audio Screen Meters]). Press F10 on the attached USB keyboard to toggle through audio
track count displays.
Text fields in the Main View will change color to indicate transport status (White = Stopped, Red =
Record, Green = Play/Pause, Blue = Rew/Fast Forward/Shuttle).
Headphone Source
Track Arm Status
Track Name
Input Meter
Drive Statuses
Timecode Value
Input View
When viewing the Main View, press the AUDIO Button to display the Input View. This view short-
ens the audio input meters and displays Input Source, Gain, and Delay information for each audio
track. These input settings are adjusted from the Input View.
Adjusting Audio Input and Track Parameters
All parameters for individual audio tracks and inputs are made from the Main View or the Input
View. To make adjustments in these views:
1. Rotate the Control Knob to move the blue highlighter to the desired track.
2. Press the Control Knob to focus the highlighter on parameters for the track. The highlighter
will become orange.
3. Rotate the Control Knob to move the orange highlighter to the desired parameter.
6
v. 2.02 Features and specifications are subject to change. Visit www.sounddevices.com for the latest documentation.
Sync Source/Sample Rate
Timecode Frame Rate
Absolute Time Transport Status
File Name
