Summary of Contents for Asko TD60.C
- Page 1 Service Manual Professional TD Type: TD60.C...
- Page 2 Service Manual TD60.C...
-
Page 3: Table Of Contents
Type: TD60.C Contents Updates ..................................................4 Introduction .................................................5 General product information ........................................6 Troubleshooting strategy ..........................................7 Product overview ..........................................8 Programme table ..............................................9 Programme descriptions ........................................... 10 Settings................................................. 11 Service menu ..............................................12 Service menu content ..........................................13 Fault indicators ..............................................15 Components and measurement values .................................... 16 Technical data .............................................. -
Page 4: Updates
Service Manual TD60.C Updates Revi- Date Description Initials sion 2009-08-12 Conference version 2010-04-29 Supplemented with information... -
Page 5: Introduction
Service Manual TD60.C Introduction You are holding the service manual for TD60 tumble dryers. It should be easy to service a tumble dryer. It is important that you, as a service technician, are provided the necessary conditions to work in an efficient and satisfactory manner. Our hope is that this service manual will prove a useful tool in your daily work. -
Page 6: General Product Information
Service Manual TD60.C... -
Page 7: Troubleshooting Strategy
Service Manual TD60.C Troubleshooting strategy At Asko, we believe in always remaining focused on the customer, and as an ASKO service techni- cian, you are one of the most important ambassadors of our brand. As such, it is important that the customer finds the service callout a pleasant experience. -
Page 8: Product Overview
Service Manual TD60.C Product overview TD60.C Programmes: A total of 7 programmes. Settings: 4 settings (Language, Child-safe, Buzzer, Heater 2) Knob and button descriptions Programme selector (J1) Turn clockwise or anti-clockwise to cycle through the different programmes and options in the various menus. -
Page 9: Programme Table
Service Manual TD60.C Programme table Condenser Programme Material Tempe- Max. Energy consump- Programme time rature load tion (approx. kWh) (kg) 1600 1600 Auto extra dry Cotton, linen Auto 2:30 2:04 normal dry Auto dry Cotton, linen Auto 2:02 1:47 normal dry... -
Page 10: Programme Descriptions
Service Manual TD60.C Programme descriptions Programme designation Description Auto extra dry This programme is for items that are particularly difficult to dry, e.g. jeans with very thick seams. Auto dry These programmes shut off the heat once the load is dry but before it is “overly dry”. The Auto dry programme shuts off the heat slightly later than Auto normal dry. -
Page 11: Settings
Service Manual TD60.C Settings Opening the settings menu Is the machine on? First turn off the power at the main På/Av power switch (S1). Start Stop Press the Stop button (S3) while simultaneously pressing the main power switch (S1). × 5 Press the Stop button 5 times within 10 seconds. -
Page 12: Service Menu
Service Manual TD60.C Service menu Opening the service menu If the machine is on: First turn off the power at the main På/Av Start Stop power switch (S1). Press and hold the Start button (S2) while simultaneously pressing the main power switch (S1). -
Page 13: Service Menu Content
Service Manual TD60.C Service menu content Date the software was programmed (Year_Week) Date of manufacture of the control unit (Year_Week) Software version NCP0: Total number of cycles run NCP1: Number of cycles for Programme 1 NCP2 Number of cycles for Programme 2... - Page 14 Service Manual TD60.C Filter interval Sets the display interval for “Clean Lint Filter”. 0 = no display, 1 = display every programme etc. Condenser inter- Sets the display interval for “Clean condenser”. 0 = no display, 1 = display every 100 programmes etc.
-
Page 15: Fault Indicators
Service Manual TD60.C Fault indicators Error message Cause Action Over Flow • A micro switch is opened when a full conden- • Check that the customer has emptied the tank and sed water tank is detected. Detection begins 30 restarted the machine. -
Page 16: Components And Measurement Values
Service Manual TD60.C Components and measurement values Item Component Measurement value Comment number Primary winding: 23.8 Ω 80 618 24 Motor 50 Hz, Auxiliary winding: 28.1 Ω 220/240 V Current: 1.1 A; 270 W; 2850 80 618 95 Motor 60 Hz,... -
Page 17: Technical Data
Service Manual TD60.C Technical data Height: 850 mm Width: 595 mm Depth: 585 mm Weight: 39 kg (vented) 47 kg (condenser) Cylinder volume: 111 l Max. load capacity: EU 7.0 kg US/AU 6.0 kg Speed: 52 rpm Rated power: 1950 W = 10 A... -
Page 18: Wiring Diagram
Service Manual TD60.C Wiring diagram... - Page 19 Service Manual TD60.C 80 901 15 Service Manual TD60.C ASKO Rev. 02...
