Installation and Operation Manual
Eastwood 1800
(DB03161 model)
US ENVIRONMENTAL PROTECTION
AGENCY PHASE II CERTIFIED
WOOD STOVE
Safety tested according to ULC S627
and UL 1482 Standards
by an accredited laboratory
www.drolet.ca
Stove Builder International Inc.
250, rue de Copenhague, St-Augustin-de-Desmaures
(Quebec) Canada G3A 2H3
After-sale service: 418-908-8002
E-mail: tech@sbi-international.com
This manual is available for free download on the manufacturer's web site. It is a
copyrighted document. Re-sale is strictly prohibited. The manufacturer may update this
manual from time to time and cannot be responsible for problems, injuries, or damages
arising out of the use of information contained in any manual obtained from unauthorized
sources.
READ AND KEEP THIS MANUAL FOR REFERENCE
45627A
Printed in Canada
10-06-2015
Advertisement
Table of Contents
Related Manuals for Drolet EASTWOOD 1800 DB03161
Summary of Contents for Drolet EASTWOOD 1800 DB03161
- Page 1 US ENVIRONMENTAL PROTECTION AGENCY PHASE II CERTIFIED WOOD STOVE Safety tested according to ULC S627 and UL 1482 Standards by an accredited laboratory www.drolet.ca Stove Builder International Inc. 250, rue de Copenhague, St-Augustin-de-Desmaures (Quebec) Canada G3A 2H3 After-sale service: 418-908-8002 E-mail: tech@sbi-international.com This manual is available for free download on the manufacturer’s web site.
- Page 2 Eastwood 1800 Installation and Operation Manual THANK YOU FOR CHOOSING THIS DROLET WOOD STOVE As one of North America’s largest and most respected wood stove and fireplace manufacturers, Stove Builder International takes pride in the quality and performance of all its products.
-
Page 3: Table Of Contents
Eastwood 1800 Installation and Operation Manual Table of content 1 PART A - OPERATION AND MAINTENANCE ......5 2 Safety Information ..............5 Summary of Operation and Maintenance Cautions and Warnings ......5 3 General Information ..............6 Eastwood 1800 Specifications ................6 Zone Heating and How to Make it Work for You ............ - Page 4 (AC01337) ..............38 Appendix 2: Installation and Use of Optional Blower and Thermodisc ............... 39 Appendix 3: Installation of Secondary Air Tubes and Baffle ... 41 Appendix 4: Exploded Diagram and Parts List ......43 DROLET LIMITED LIFETIME WARRANTY ........46...
-
Page 5: Part A - Operation And Maintenance
Eastwood 1800 Installation and Operation Manual 1 PART A - OPERATION AND MAINTENANCE Please see Part B for installation instructions. 2 Safety Information 2.1 Summary of Operation and Maintenance Cautions and Warnings HOT WHILE IN OPERATION, KEEP CHILDREN, CLOTHING AND FURNITURE •... -
Page 6: General Information
Eastwood 1800 Installation and Operation Manual General Information 3.1 Eastwood 1800 Specifications Fuel Type Cordwood Test Standards (safety) ULC S627 and UL 1482 Test Standard (emissions) EPA Method 28 (40 CFR Part 60) Heating capacity range* 800 to 2000 sq. ft. (74 to 186 m Maximum heat output** 32 400 BTU/h (9,5 kW/h) (EPA test fuel) - Page 7 Eastwood 1800 Installation and Operation Manual...
-
Page 8: Zone Heating And How To Make It Work For You
Eastwood 1800 Installation and Operation Manual 3.2 Zone Heating and How to Make it Work for You Your new Eastwood 1800 wood stove is a space heater, which means it is intended to heat the area it is installed in, as well as spaces that connect to that area, although to a lower temperature. -
Page 9: The Benefits Of Low Emissions And High Efficiency
Eastwood 1800 Installation and Operation Manual 3.3 The Benefits of Low Emissions and High Efficiency The low smoke emissions produced by the special features inside the Eastwood 1800 firebox mean that your household will release up to 90 percent less smoke into the outside environment than if you used an older conventional stove. -
Page 10: Fuel
Eastwood 1800 Installation and Operation Manual 4 Fuel 4.1 Materials That Should Not be Burned GARBAGE OF ANY KIND, • COAL OR CHARCOAL, • • TREATED, PAINTED OR COATED WOOD, • PLYWOOD OR PARTICLE BOARD, • FINE PAPER, COLORED PAPER OR CARDBOARD, SALT WATER DRIFTWOOD, •... -
Page 11: Log Length
Eastwood 1800 Installation and Operation Manual 4.2.3 Log Length Logs should be cut about 1” (25 mm) shorter than the firebox so they fit in easily. Pieces that are even slightly too long make loading the stove very difficult. The most common standard length of firewood is 16”... -
Page 12: How To Dry Firewood
Eastwood 1800 Installation and Operation Manual 4.2.5 How to Dry Firewood Firewood that is not dry enough to burn is the cause of most complaints about wood inserts. Continually burning green or unseasoned wood produces more creosote and involves lack of heat and dirty glass door. See Section 5: Maintaining your wood heating system for concerns about creosote. -
Page 13: Judging Firewood Moisture Content
Eastwood 1800 Installation and Operation Manual Eastwood 1800 Installation and Operation Manual 4.2.6 Judging Firewood Moisture Content Judging Firewood Moisture Content You can find out if some firewood is dry You can find out if some firewood is dry enough to burn by using these guidelines: enough to burn by using these guidelines: •... -
Page 14: Operating Your Stove
Eastwood 1800 Installation and Operation Manual 5 Operating Your Stove 5.1 Your First Fires Two things will happen as you burn your first few fires; the paint cures and the internal components of the stove are conditioned. As the paint cures, some of the chemicals vaporize. The vapors are not poisonous, but they do smell bad. -
Page 15: The Top Down Fire
Eastwood 1800 Installation and Operation Manual 5.2.2 The Top Down Fire The top down fire starting method solves two problems with the conventional method: first, it does not collapse and smother itself as it burns; and second, it is not necessary to build up the fire gradually because the firebox is loaded before the fire is lit. -
Page 16: Maintaining Wood Fires
Eastwood 1800 Installation and Operation Manual 5.3 Maintaining Wood Fires 5.3.1 General Advice Wood heating with a space heater is very different than other forms of heating. There will be variations in the temperature in different parts of the house and there will be variations in temperature throughout the day and night. -
Page 17: Raking Charcoal
Eastwood 1800 Installation and Operation Manual 5.3.3 Raking Charcoal Rekindle the fire when you notice that the room temperature has fallen. You will find most of the remaining charcoal at the back of the firebox, furthest from the door. Rake these coals towards the door before loading. -
Page 18: Turning Down The Air Supply
Eastwood 1800 Installation and Operation Manual 5.3.5 Turning Down the Air Supply Once the firewood, firebox and chimney are hot, you can begin to reduce the air supply for a steady burn. As you reduce the air supply to the fire, two important things happen. First, the firing rate slows down to spread the heat energy in the fuel over a longer period of time. -
Page 19: Building Different Fires For Different Needs
Eastwood 1800 Installation and Operation Manual 5.3.6 Building Different Fires for Different Needs Using the air control is not the only way to match the stove’s heat output to the heat demand. Your house will need far less heat in October than in January to be kept at a comfortable temperature. - Page 20 Eastwood 1800 Installation and Operation Manual The table below provides a very general indication of the maximum burn cycle times you are likely to experience, based on firebox volume. MAXIMUM FIREBOX VOLUME BURN TIME <1.5 cubic feet 3 to 5 hours 1.5 c.f.
-
Page 21: Maintaining Your Wood Heating System
Eastwood 1800 Installation and Operation Manual 6 Maintaining Your Wood Heating System 6.1 Stove Maintenance Your new stove will give many years of reliable service if you use and maintain it correctly. Some of the internal components of the firebox, such as firebricks, baffles and air tubes, will wear over time under intense heat. -
Page 22: Door Adjustment
Eastwood 1800 Installation and Operation Manual 6.1.2 Door adjustment In order for your stove to burn at its best efficiency, the door must provide a perfect seal with the firebox. Therefore, the gasket should be inspected periodically making sure to obtain an air tight fit. -
Page 23: Replacing The Door Gasket
Eastwood 1800 Installation and Operation Manual 6.1.3 Replacing the Door Gasket It is important to maintain the gasket in good condition. After a year or more of use, the door gasket will compress and become hard, which may allow air to leak past it. You can test the condition of the door gasket by closing and latching the door on a strip of paper. -
Page 24: Cleaning And Painting The Stove
Eastwood 1800 Installation and Operation Manual The gasket must be centred on the edge of the glass. To do this easily, peel back a section of the paper covering the adhesive and place the gasket on a table with the adhesive side up. -
Page 25: How Often Should You Clean The Chimney
Eastwood 1800 Installation and Operation Manual 6.2.2 How Often Should You Clean the Chimney? It is not possible to predict how much or how quickly creosote will form in your chimney. It is important, therefore, to check the build-up in your chimney monthly when getting used to the new stove until you determine the rate of creosote formation. -
Page 26: Part B - Installation
Eastwood 1800 Installation and Operation Manual PART B - INSTALLATION 7 Safety Information 7.1 Summary of Installation Cautions and Warnings THE INFORMATION GIVEN ON THE CERTIFICATION LABEL AFFIXED TO THE • APPLIANCE ALWAYS OVERRIDES THE INFORMATION PUBLISHED, IN ANY OTHER MEDIA (OWNER’S MANUAL, CATALOGUES, FLYERS, MAGAZINES AND/OR WEB SITES). -
Page 27: Clearances To Combustible Material
Eastwood 1800 Installation and Operation Manual 8 Clearances to Combustible Material The clearances shown in this section have been determined by test according to procedures set out in safety standards ULC S627 (Canada), UL1482 (U.S.A.) and UL737 (U.S.A.). When the stove is installed so that its surfaces are at or beyond the minimum clearances specified, combustible surfaces will not overheat under normal and even abnormal operating conditions. - Page 28 Eastwood 1800 Installation and Operation Manual Clearances to combustible materials and floor protection...
-
Page 29: Floor Protector
Eastwood 1800 Installation and Operation Manual 8.3 Floor protector If the stove is to be installed on top of a combustible floor, it must be guarded by a non combustible material as shown on figure 1.3 (see the dotted line area). FLOOR PROTECTOR* CANADA 8’’... -
Page 30: Reducing Wall And Ceiling Clearances Safely
Eastwood 1800 Installation and Operation Manual 8.4 Reducing Wall and Ceiling Clearances Safely It is often desirable to reduce minimum installation clearances by placing the stove closer to walls so the installation takes up less floor space. You can safely reduce the minimum clearances permanently installing a shield between the... -
Page 31: Table Of Clearance Reduction Percentages
Eastwood 1800 Installation and Operation Manual 8.4.2 Table of Clearance Reduction Percentages Clearances may be reduced by these percentages Type of shield Sides Top % and rear % (ceiling) Sheet metal, a minimum of 24 gauge (0.61 mm) in thickness , spaced out at least 25 mm (1 in)* by non-combustible spacers Ceramic tiles, or equivalent non-... -
Page 32: The Venting System
Eastwood 1800 Installation and Operation Manual 1800 Installation and Operation Manual 9 The Venting System The Venting System 9.1 General The venting system, made up of the chimney and the connecting pipe between the stove The venting system, made up of the chimney and the connecting pipe between the stove The venting system, made up of the chimney and the connecting pipe between the stove and the chimney, acts as the engine acts as the engine that drives your wood heating system. -
Page 33: Masonry Chimneys
Eastwood 1800 Installation and Operation Manual Eastwood 1800 Installation and Operation Manual 9.2.2 Masonry Chimneys The stove may also be connected to a The stove may also be connected to a masonry masonry chimney, chimney, provided provided chimney complies with the construction chimney complies with the construction rules found in the building code rules found in the building code... -
Page 34: The Relationship Between The Chimney And The House
Eastwood 1800 Installation and Operation Manual 1800 Installation and Operation Manual 9.4 The Relationship Between the Chimney and the House The Relationship Between the Chimney and the House Because the venting system is the engine that drives the wood heating system, it must Because the venting system is the engine that drives the wood heating system, it must Because the venting system is the engine that drives the wood heating system, it must have the right characteristics. -
Page 35: Supply Of Combustion Air
Eastwood 1800 Installation and Operation Manual There are two reasons why the chimney in the house at right will cold backdraft when it is cold outside and there is no fire burning in the stove. First, the chimney runs up the outside of the house, so the air in it is colder and denser than the warm air in the house. -
Page 36: Installing The Chimney Connector
Eastwood 1800 Installation and Operation Manual 1800 Installation and Operation Manual 9.6 Installing the Chimney Connector Installing the Chimney Connector The chimney connector is the single or double wall The chimney connector is the single or double wall pipe installed between the stove flue pipe installed between the stove flue collar and the chimney breech. - Page 37 Eastwood 1800 Installation and Operation Manual The rules below are based on those found in the CSA B365 installation code. Please carefully follow these installation instruction rules, or those enforced where you live. • Maximum overall length of straight pipe: 3 m (10 ft.) including elbows. Minimum clearance from combustible material: 450 mm (18 in.).
-
Page 38: Appendix 1: Installing The Optional Fresh Air Intake Kit (Ac01337)
Eastwood 1800 Installation and Operation Manual Appendix 1: Installing the Optional Fresh Air Intake Kit (AC01337) This mobile home approved stove requires installation of a fresh air intake kit (A) and an insulated fresh air intake pipe (B), sold separately. When installed with a fresh air intake kit, the stove must be anchored to the floor with screws. -
Page 39: Appendix 2: Installation And Use Of Optional Blower And Thermodisc
You can purchase this option through your DROLET dealer. Make sure to specify this part number: # AC03095 When using the optional blower, allow the stove to reach operating temperature (approximately one hour), before turning it on. - Page 40 Eastwood 1800 Installation and Operation Manual CAUTION: ENSURE THAT THE BLOWER’S POWER CORD IS NOT IN CONTACT WITH ANY SURFACE OF THE STOVE TO PREVENT ELECTRICAL SHOCK OR FIRE DAMAGE. DO NOT RUN THE POWER CORD BENEATH THE STOVE.
-
Page 41: Appendix 3: Installation Of Secondary Air Tubes And Baffle
Eastwood 1800 Installation and Operation Manual Appendix 3: Installation of Secondary Air Tubes and Baffle 1- Starting with the rear tube, lean and insert the right end of the secondary air tube into the rear right channel hole. Then lift and insert the left end of the tube into the rear left channel. - Page 42 Eastwood 1800 Installation and Operation Manual Note that secondary air tubes (A) can be replaced without removing the baffle board (B). Important Notes: The air tubes are identified for placement as follows: Model Type of tube Front ► 37 holes of 0.172" Eastwood 1800 Middle front ►...
-
Page 43: Appendix 4: Exploded Diagram And Parts List
Eastwood 1800 Installation and Operation Manual Appendix 4: Exploded Diagram and Parts List... - Page 44 Eastwood 1800 Installation and Operation Manual IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts for your stove, please provide the model number and the serial number. We reserve the right to change parts due to technology upgrade or availability. Contact an authorized dealer to obtain any of these parts.
- Page 45 Eastwood 1800 Installation and Operation Manual Item Description 35 SE45627 EASTWOOD 1800 MANUAL KIT 36 AC03095 120 CFM BLOWER WITH VARIABLE SPEED CONTROL 37 60013 POWER CORD 96" X 18-3 38 44070 CROSSFLOW BLOWER 115V-60Hz-56W 39 44080 RHEOSTAT WITH NUT 40 44087 RHEOSTAT NUT 41 44085...
-
