OWNER`S MANUAL
Escape 1400-I Insert
US ENVIRONMENTAL PROTECTION
AGENCY PHASE II CERTIFIED
WOOD INSERT
Verified and tested following
ULC S628 and UL 1482 Standards
by:
Intertek Testing Services
Manufactured by : STOVE BUILDER INTERNATIONAL INC..
1700, Léon-Harmel, Québec (Québec) G1N 4R9
Tel : (418 ) 527-3060
Fax : (418 ) 527-4311
www.drolet.ca
READ AND KEEP THIS MANUAL FOR REFERENCE
45221
Revised : October 19th, 2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ESCAPE 45221 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Drolet ESCAPE 45221

  • Page 1 Intertek Testing Services Manufactured by : STOVE BUILDER INTERNATIONAL INC.. 1700, Léon-Harmel, Québec (Québec) G1N 4R9 Tel : (418 ) 527-3060 Fax : (418 ) 527-4311 www.drolet.ca READ AND KEEP THIS MANUAL FOR REFERENCE 45221 Revised : October 19th, 2009...
  • Page 2: Introduction

    Registering your warranty online will help us track rapidly the information we need on your insert. KEEP CHILDREN CLOTHING AND FURNITURE AWAY REGISTER YOU WARRANTY ONLINE stove. Keep your sales invoice. We also www.drolet.ca CONTACT MAY CAUSE NAPHTHA OR MOTOR OIL...
  • Page 3: Table Of Contents

    4.5 Secondary Air Tube Replacement ... 20 4.6 Fan Maintenance & Care ... 21 4.7 Removal instructions ... 21 Section 5.0 Specifications ... 22 5.1 Escape 1400-I Insert Model ... 22 DROLET LIMITED LIFETIME WARRANTY ... 23 TABLE OF CONTENTS...
  • Page 4 Escape 1400-I Dimensions 28 25/64" 26 29/32" 13 29/64" 6.000" 13 3/8" 15 1/32" 8 9/64" 6 31/64" 20 31/32" 20 31/32" 8 9/32" 9 61/64" Faceplate fully extended toward the back Faceplate fully extended toward the front...
  • Page 5: Section 1.0 Pre-Installation Requirements

    Section 1.0 Pre-Installation Requirements 1.1 Masonry & Zero Clearance Requirements The masonry fireplace must meet the minimum code requirements, or NFPA 211 or the equivalent for a safe installation. Contact your local Building Inspector for requirements in your area. An inspection of the fireplace should include the following: 1.
  • Page 6: Venting Requirements

    1.2 Venting Requirements The flue is a critical component to a satisfactory installation. Your insert will attain its best performance if installed with a flue that generates its own draft. The minimum venting requirement will be the installation of a flue connector from the insert into the first tile of the chimney (see Figure 2.3). If you are using a masonry chimney, it is important that it be built in compliance with the specifications of the National Building Code or other applicable standard having jurisdiction.
  • Page 7: Section 2.0 Installation

    Section 2.0 Installation 2.1 Clearances To Combustibles (Measured From Insert Body) Sidewall (A) Top mantel (B) Side mantle (C) Shelf (D) Note: If side mantle protrudes more than 1.5” (38mm) in front of face of fireplace, then use sidewall clearance. Escape 1400-I 13”...
  • Page 8: Hearth Requirements

    2.1.1 Hearth Requirements If the non-combustible hearth is flush with the floor, then the hearth must be 16”/406mm (18”/450mm in Canada) in front of the fan housing (see Figure 2.1.2). If the non- combustible hearth is a minimum of 4” (102mm) above the floor, then the hearth can be 6” (152mm) out from the fan housing with a 10”...
  • Page 9: Safety Information

    Floor protection to the front is to be measured from the fuel loading door opening. 5. Drolet recommends that you install a listed smoke detector or alarm in your home. Normal operation of the insert will have no effect on the detector or alarm.
  • Page 10: Installation Instructions

    2.4 Installation Instructions 1. Inspect the fireplace according to the safety information and fireplace requirements and have it cleaned and/or upgraded as necessary. 2. If the installation of the unit renders the existing damper control inaccessible, it will be necessary to either secure the damper wide open or remove it entirely.
  • Page 11: Air Control Plate, Faceplate And Fan Assembly Instructions

    2.5 Air control plate, faceplate and fan Assembly Instructions 1. Place the faceplate panels with the finished side down on a flat, soft, non-abrasive surface. 2. Assemble the faceplate trim, attaching the mitered corners with the corner brackets. (see Figure 2.4) 3.
  • Page 12: Installation Of The Adapter For Fresh Air Kit

    2.6 Installation of the adapter for fresh air kit In order to avoid some combustion problems, it is highly recommended to install an adapter for fresh air kit. To do so, you need to have the accessory #AC01298. Using pliers, remove the metal rectangle (A) located on the side of the insert.
  • Page 13: Section 3.0 Operation

    Misuse is not covered by warranty. Even though your Drolet insert has been specifically designed and tested to prevent smoke spillage, always open the door slowly as this will minimize the likelihood of smoke spillage or a back draft causing flame or smoke to spill into the room.
  • Page 14: Fuel

    Fuel for the insert must not be stored closer than the required clearances to combustibles and not in the space required for ash removal. Your Drolet insert is designed to burn in the unit. Highly flammable items such as trash may ignite creosote in the chimney, resulting in a chimney fire.
  • Page 15: Simple Wood Moisture Test

    An example of the energy values of some common wood fuels is given in Table 3.1 For recommended wood sizes, refer to the specifications. Common Heating Values of Cordwood Hardwoods Birch White Oak Alder 3.2.1 Simple Wood Moisture Test Add one large piece of wood to the top of an established fire. If it starts to burn on three sides within one minute, it is dry and seasoned and right for burning.
  • Page 16: Damper Operation

    Ideally the large kindling should be burned until a thick bed of red embers is obtained. At that point, add cordwood fuel and continue to operate the draft control wide open until the fire is well established. Once the firebox is hot, the draft control can be partially closed by moving the knob to the left to adjust the intensity of the fire.
  • Page 17: Maintaining The Fire

    3.5 Maintaining The Fire Your Drolet insert will work best if a thick bed of hot embers is maintained in the bottom of the firebox, and a minimum of two large pieces of seasoned fuel are added. Combustion efficiency is largely related to establishing a hot ember bed, and hot firebox temperatures.
  • Page 18: Section 4.0 Maintenance

    Section 4.0 Maintenance 4.1 Care And Cleaning Clean the insert frequently so that soot, ash and creosote do not accumulate. Do not attempt to clean the insert, glass or door when the unit is hot. Special care must be taken with plated surfaces in order to maintain the finish at its original brilliance.
  • Page 19: Ash Removal

    If creosote has accumulated, it should be removed to reduce the risk of chimney fire. Call a professional chimney sweep, or go to your local Drolet dealer and purchase a chimney brush, and have the chimney cleaned.
  • Page 20: Figure 4.1 – Baffle Installation & Removal For Escape 1400-I

    4.4 Baffle Installation for Escape 1400-I MIDDLE AND REAR TUBES FRONT TUBE FRONT BAFFLE SUPPORT Figure 4.1 – Baffle installation & removal for Escape 1400-I The baffle assembly must be properly in place for correct burning operation. Have any damaged firebricks replaced.
  • Page 21: Secondary Air Tube Replacement

    4.5 Secondary Air Tube Replacement (see Figure 4.3) Remove cotter pin at RH end of tube. Slide tube to left and lower tube end below RH plenum. Slide tube to right to remove. Reassemble in reverse order using a new cotter pin. The cotter pin is a hammerlock style and locks into place by hitting the head sharply with a hammer.
  • Page 22: Fan Maintenance & Care

    4.6 Fan Maintenance & Care Clean the fan air inlet louvres and squirrel cage impeller regularly. The fan should be kept clean and dust free. Life of the fan will be shortened if operated in a dust filled environment, or if the fan is overheated by restricting air supply.
  • Page 23: Section 5.0 Specifications

    Section 5.0 Specifications 5.1 Escape 1400-I Insert Model Fuel Type Cordwood Test Standards ULC S628 (CSA B366.2) & UL 1482 residential. Recommended surface : 700 to 1600 sq. ft. Heating capacity* – BTU/hr., EPA test wood: 39,000 BTU/h. Heating capacity* – BTU/hr., seasoned cordwood : 60,000 BTU/h. Optimum efficiency: 75% *Why is the information indicated on the EPA label different than the one advertised? You will notice a difference between the BTU output as indicated on the unit’s white EPA label affixed to the glass and the...
  • Page 24: Drolet Limited Lifetime Warranty

    Firebrick *Pictures required Shall your unit or a components be defective, contact immediately your DROLET dealer. Prior to your call make sure you have the following information necessary to your warranty claim treatment: Your name, address and telephone number;...
