  • Page 1 EIKI EIP-25 user manual http://www.manuallib.com/file/2687575 From ManualLib.com ManualLib.com collects and classifies the global product instrunction manuals to help users access anytime and anywhere, helping users make better use of products. Home: http://www.manuallib.com/ Chinese: http://www.shuomingshuku.com/ This Manual: http://www.manuallib.com/file/2687575...
  • Page 2 This Manual: http://www.manuallib.com/file/2687575...

  • Page 3: Table Of Contents

    Table of Contents ···················································································· 1. Introduction ··························································································· 2. Features ··········································································· 3. Operation notice ············································································· 4. Projector figure 4.1 Function list of control panel ···················································································· 5. Accessories 5.1 Remote control 5.2 Function list of remote control panel ·········································································· 6. Operation guide 6.1 Connecting component 6.2 How to connect the projector to your computer...

  • Page 4: Introduction

    1.Introduction Please read this manual carefully before using, to find out: • How to use the projector safely • How to use the remote control • How to set up and connect the projector • How to start and turn off the projector •...

  • Page 5: Operation Notice

    3.Operation notice: Please read and follow the following safety instructions and description carefully. Inappropriate operation method may result in fire, electrical shock, and personal injury or shorten the life span of projector. Warning: Do not cover the lens while the lamp lights up. Warning: To protect your eyes, do not look directly into the projector’s light source.

  • Page 6: Projector Figure

    4.Projector figure Control panel Infrared remote sensor Zoom ring Focus ring Lens Cap 4.1 Function list of control panel: POWER ↑↓←→ MENU SOURCE LAMP LED TEMP LED AUTO/ENTER POWER LED This Manual: http://www.manuallib.com/file/2687575...
  • Page 7 Power LED (Indicator light) • When the projector is on, Power LED will blink. Press “Power” button to enter screen, Power LED remains lit continually. Temp LED (Indicator light) • When fan malfunctions, the screen will shows the message stating “fan error, system is forced to turn off!”.
  • Page 8 (Up and down button) • OSD active: Press to move between menu options. • OSD inactive: Press to select the video input source. (Left and right button) • When using these buttons, press ”Auto/Enter” button then press right key to add setting value;...

  • Page 9: Accessories

    5.Accessories You should check to make sure the accessories below are complete with nothing missing. For any missing accessory, please contact the local distributor. Projector lens cap power cord Component Video cable Composite Video cable PC Audio in/out cable S-Video cable VGA cable USB cable Carry bag...

  • Page 10: Remote Control

    5.1 Remote Control The infrared sensor is located on the top of the projector. The distance between the sensor and remote control should not exceed 10 meters for the remote control to function correctly. How to insert batteries in the remote control: 1) Remove the battery compartment cover.

  • Page 11: Function List Of Remote Control Panel

    5.2Function list of remote control panel: Function key Function description • Freeze/Esc/L OSD inactive: press this button to freeze the display image. Press again to resume motion. • OSD active: press this button to exit. • Mouse active: Use as the left mouse button. •...
  • Page 12 • Press this button, then press right and left button to execute keystone correction. • Press button to correct a display image that is wider at the bottom. • Press button to correct a display image that is wider at the top.(*) •...

  • Page 13: Operation Guide

    6.Operation guide 6.1 Connecting components You can connect the projector to your computer, DVD player or VCR. To connect the projector to a DVD player or VCR, go to “Connecting to a DVD player or VCR” on page 12. VGA In/Out port USB In port S-Video In port Composite Video port...

  • Page 14: How To Connect The Projector To Your Computer

    6.2 How to connect the projector to your computer 1) Plug the VGA cable into the VGA port at the left side of projector, then plug the other end of VGA cable into the computer. Note: If you are connecting to a notebook, you may need to make adjustments to the notebook’s display settings first.

  • Page 15: Turning On The Projector

    After you have connected all components to the projector, you are ready to begin using the projector. 6.4 Turning on the projector: 1) Remove the lens cap. 2) Ensure the cable connectors have connected properly. 3) Plug the power cord, press the main switch on the top of power cord socket of the projector, Power LED blinks steadily and slowly.

  • Page 16: Turning Off The Projector

    6.6 Turning off the projector 1) Press “Power” button to turn off the projector lamp. 2) When you press the “Power ” button, you will see the message stating “Press Power again to turn off the lamp!”. At this time, you only have to press “Power”...

  • Page 17: Adjusting The Image Focus And Zoom

    To lower the projector 1. Press and hold the Adjustor-foot release button. 2. Lower the projector to the height you want, then release the button to lock the foot into position. 6.8 Adjusting the image focus and zoom Zoom Wheel Focus ring You can adjust the zoom ring to magnify or minify the image.

  • Page 18: Osd Menu

    7.OSD Menu Press “Menu” button to open the menu. Press up and down button to choose the OSD options or press Esc to exit. To enter the submenu, please press “Auto/Enter” button or right button. Under the submenu, press “Menu” or the Esc button on the remote control to return to Menu main screen or double click to exit the OSD menu.

  • Page 19: Image (Video Mode)

    Image (Video mode) Submenu Description Operation method options • Adjusts the brightness of the Brightness Press button can reduce the brightness display image. of display image. • Press button can increase the brightness of display image.(*) • Adjusts the contrast of the Contrast Press button can reduce the contrast of display image.

  • Page 20: Display (Computer Mode)

    7.3 Display (Computer mode) Submenu options Description Operation method • Frequency Minimizes any vertical bars Press button to adjust or stripes visible on the (*). screen background. • Removes any horizontal Phase Press button to distortion and clears or adjust(*). sharpens the displayed characters.
  • Page 21 • Switches between a display Proportion Press button to choose. image mode of 4:3 or 16:9. • Activates individual red, User color Choose Yes, and the red gain, green, or blue color green gain, green gain option correction controls. emerges. •...

  • Page 22: Display (Video Mode)

    7.4 Display (Video mode) Submenu options Description Operation method • Corrects a display image Keystone Press button to correct the that is wider at the top or display image that is wider at at the bottom. the bottom. • Press button to correct the display image that is wider at the top.(*)

  • Page 23: Audio

    7.5 Audio Submenu options Description or operation method • Volume Press button to decrease the volume. • Press button to increase the volume.(*) • Balance Press button to decrease the volume of the left speaker. • Press button to increase the volume of the right speaker.(*) •...
  • Page 24 7.6 Management Submenu Description Operation method options • Adjusts the position of the OSD OSD location Press button to within the display image. select (*). • (Projection before the screen) Projection Press button to Default select (*). (Projection behind the screen) Flips the display image so it can be viewed correctly when the projector is set up for rear...
  • Page 25 • Resets the lamp timer after Lamp Reset Press right button, then it replacing the lamp module. will display the message stating “Press Auto/Enter button, reset the lamp timer” to confirm that the user has replaced the lamp. After replacing the lamp, please press “Auto/Enter”...

  • Page 26: Language

    7.7 Language Changes the language of the OSD menu. Choose between English, German, French, Italian, Spanish, Portuguese, Japanese, Traditional, Chinese, and Simple Chinese. This Manual: http://www.manuallib.com/file/2687575...

  • Page 27: Maintenance And Service

    8. Maintenance and service Change the module lamp immediately when the lamp life reaches 1500 hrs to maintain the best projection image. 8.1 Replacing the lamp module When the lamp is within 30 hours of maximum lamp life, projector will display a warning automatically stating, “Lamp has reached its end of life! Lamp replacement is suggested!”.

  • Page 28: Cleaning The Projector Lens

    8.2 Cleaning the projector lens Please follow the following procedures to clean the projector lens: 1 Pour out a little cleaner on a clean soft cloth. Do not use the cleaner with particle, the cleaner that contains solvent or other chemicals of poor quality, they may cause damage to the projector lens.

  • Page 29: Appendix

    9. Appendix 9.1 Common problems and solutions When you encounter problems while using the projector, please refer to the following contents: If the suggestions in the troubleshooting section does not correct the problem, please contact the local distributor or our customer service center. No picture on the screen Make sure that all components are connected correctly and securely in accordance to the connection method and line that is introduced in the previous...
  • Page 30 The focus of display image is blurred Adjust the focus ring on the projector. Make sure the projection screen is 1.4 ~12 meters from the projector. Projected colors don’t match the computer or video player’s colors This is a normal phenomenon; just adjust the brightness, color or contrast value in the menu.
  • Page 31 9.2 The distance proportion between screen and projector (Based on Zoom Ratio 1.18:1, for reference only) Projection distance 1.45M Tele Projection screen size 30” 40” 80” 120” 240” Wide Projection screen size 35” 47” 94” 141” 283” This Manual: http://www.manuallib.com/file/2687575...

  • Page 32: Specifications

    9.3 Specifications EIP-25 Model No. Resolution XGA(1024*768), SXGA(1280*1024) compressed Lamp 250W User Replaceable VIP Lamp Brightness 2500 Lumens Dimensions 330 x 276 x 104 mm Weight 7.5 lbs Projection distance 1.4m--12m Ratio of projection 1.34:1-- 1.6:1 (Distance: Diagonal) screen and distance Zoom ratio 1.2:1 (Manual Zoom/Focus)
  • Page 33 This Manual: http://www.manuallib.com/file/2687575...
