Work Pro neo User Manual page 6

EN
Plastic Wall-mount bracket (NEO 3)
1
62
figure 1
figure 2
figure 3
figure 4
1
2
3
4
5
2
Use the wall mounting part (1) to mark the fixing points on the wall.
Take into account the dimensions between holes and the diameters
marked in figure 1.
Drill wall and insert wall fixings. Screw wall mounting part to wall.
Ensure that suitable screws and wall fixings are used.If in any
doubt contact a suitably qualified expert.
Pass the threaded ball piece (2) through the locking nut (3)
and screw it directly into the loudspeaker.
Tighten M6 nut (5) against the loudspeaker with a spanner.
Do not over tighten.
Attach the complete set (loudspeaker+ threaded ball + locking
nut) to the wall mounting part (1). See figure 3.
Screw the locking nut (3) but not fully tight yet. See figure 4.
Angle the loudspeaker to obtain the desired orientation. Once
the angle is final, fully tighten the locking nut, but do not over
tighten.
5
Rear wall mounting part
Threaded Ball
Locking nut
Fixation screw (x2)
Fixation nut
3
User Manual/Manual de Uso
5
4
NEO Passive/Pasivas
