Dell PowerEdge T630 Owner's Manual page 18

Item Indicator, Button, or
Connector
5 System identification
button
6 iDRAC Enterprise port
7 Power supply (PSU1)
8 USB connectors (6)
9 Video connector
10 Serial connector
11 Power supply (PSU2)
12 PCIe expansion card
slots full height (4)
(processor 2)
18
Icon Description
The identification buttons on the front and back
panels can be used to locate a particular system
within a rack. When one of these buttons is
pressed, the LCD panel on the front and the
system status indicator on the back flash until one
of the buttons is pressed again.
Press to toggle the system ID on and off.
If the system stops responding during POST, press
and hold the system ID button for more than five
seconds to enter the BIOS progress mode.
To reset iDRAC (if not disabled in F2 iDRAC setup),
press and hold for more than 15 seconds.
Dedicated management port.
NOTE: The port is available for use only if the
iDRAC Enterprise license is installed on your
system.
AC
or
DC
Allows you to connect USB devices to the system.
Four ports are USB 2.0-compliant and two ports
are USB 3.0-compliant.
Allows you to connect a VGA display to the
system.
Allows you to connect a serial device to the
system.
AC
or
DC
Connects up to four full-height PCI Express
expansion cards.
495 W, 750 W, 1100 W, or
1600 W
1100 W
495 W, 750 W, 1100 W, or
1600 W
1100 W
