GE AME18 Use And Care & Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Contents
Model
and
Serial
Numbers
User
Maintenance
Instructions
Warranty
Back Cover
m
GE Answer Center
800.626.2000
Model AME18
GE Appliances
2
6
6
6
15
4,5
3
7
3
4
3
8-14
2,6
7
2
6

Air Conditioner

Advertisement

Table of Contents
loading

Related Manuals for GE AME18

Summary of Contents for GE AME18

  • Page 1: Table Of Contents

    Care and Cleaning Air Filter Grille & Cabinet Outdoor Coil Consumer Services Electrical Requirements Energy-Sating Tips Extension Cords Freezing Up Installation Instructions 8-14 Model Serial Numbers Problem Solver User Maintenance Instructions Warranty Back Cover GE Answer Center 800.626.2000 Model AME18 GE Appliances...

  • Page 2: Appliance Registration

    Care Guide. NEXT, if you are still not pleased, Consumer Affairs write all the details—including This air conditioner must be GE Appliances your phone number—to: properly installed in accordance Appliance Park Louisville, KY 40225 with the Installation hstructions...

  • Page 3: Adapter Plug

    Electrical Read Carefuuy. that mates respectively with a How to connect TEMPORARY METHOD 230/208-volt perpendicular, electricity (ADAPTER PLUGS NOT tandem or large tandem type wall PERMITTED IN CANAOA outlet. These types of outlets are ALIGN LARGE available at most hardware stores For personal safety, this appliance must be properly grounded.

  • Page 4: Conwol Settings

    Operating Your Air Conditioner Controls TIMER ONLY COOL THERMOSTAT -w-n-n-m-m-n-n-m-m OFF= SELECTOR Timer Control Thermostat Control Selector Switch (on models so equipped) When you move the Thermostat OFF turns air conditioner off. When you turn the Timer Control Control to the desired setting, the FAN ONLY provides air to the MANUAL setting, the air thermostat will automatical&...

  • Page 5: Air Direction

    For maximum cooling To adjust air direction 1. Set the Selector Switch at Up and down HI COOL. OPEN VENT CLOSE 2. Turn the Thermostat Control (ON THE LOWER RIGHT SIDE 3. Be sure the Ventilation Control OF THE DISCHARGE GRILLE) is in the CLOSE position.

  • Page 6: Care And Cleaning

    GE service outlet. accumulated dust and lint. If the filter is very dirty, use a mild Front Grille...

  • Page 7: Energy-Sating Tips

    Moisture removed from indoor air drains to rear of cabinet where it is picked up by a fan and thrown against the outdoor condenser coil. If you need more help... call, toll free: GE Answer Center ’ 800.626.2000 consumer information service...

  • Page 8: Installation Instructions

    WINDOWREQUIREMENTS Standard double-hung window with actual Read these instructions completely and opening width of 29” to 46”. carefully. Clear vertical opening of 18“ minimum from bottom of sash to stool. ordinances. Install the air conditioner in a window where sure to leave these there will be enough clearance around the cabinet instructions with the consumer.
  • Page 9 TOOLS NEEDED SCREWS FURNISHED see samples) Type D Type E Type F Type A Type B Type C Phillips head screwdriver Blade-type screwdriver Sharp knife or razor blade Pencil Level Box wrench Qty-3 Qty-2 Qty-4 Qty-7 Qty-3 Qty-8 Type A screw Type A screw...
  • Page 10 WINDOW INSTALLATION (cont,n.e~, See Front Grille section. Room side + 1. Remove chassis locking bracket and chassis locking screw with a Phillips head screwdriver. Type D screw (Save for reuse.) 1. Install top mounting rail onto top of cabinet with 3 Type D screws.
  • Page 11 5. Secure top mounting rail with two Type E screws. 1. Slide left window filler panel into top and bottom mounting rails. 2. Slide retainer panel into window filler panel and attach to cabinet with 2 Type F screws. 3. Repeat for right side. Top mounting rail Window —...
  • Page 12 (Continued) lMSW[[ SASH GASKEZ /NSMLL CHASSIS IN CABINED Cut foam sash gasket to window width and stuff Slide chassis into cabinet. (Make sure tubing on between top of lower sash and glass panes of unit is not touching wall case. ) upper sash Make sure foam gasket flush with 2.

  • Page 13: Tools Required

    THROUGH-THE-WALL INSTALLATION THE CABINET MAY BE INSTALLED THROUGH THE WALL IN BOTH EXISTING PREPARE WALL OPENING. BUILDINGS AND NEW CONSTRUCTION. Determine size of opening. Measure width and height of cabinet and add 1 /8” to each dimension. louvers must project on the oudoor Any side side of the wall.
  • Page 14 ‘\ (continued)..-:. Brick Veneer — 3. Secure cabinet sides to wooden frame with six 1“ long #10 wood screws and secure cabinet top Trim Lintel Angle to frame with four 1“ long #10 wood screws. Molding -— —-— required) ‘...

  • Page 15: Consumer Services

    With the purchase of your new GE appliance, receive the assurance that if you ever need information or assistance from CTE, we’ll be there. All you have to do is call–toll-free! In-Home Repair Service Contracts Service will provide exrcrt rcpiiir service, service ;~t tod;iy’s prices.
  • Page 16 To know what your legal rights are in your state, consult your local or state consumer affairs office or your state’s Attorney General. Warrantor: General Electric Company If further help is needed concerning this warranty, write: Manager—Consumer Affairs, GE Appliances, Louisville, KY 40225 49-7270 11-91...
