Related Manuals for GE AMV12

Summary of Contents for GE AMV12

  • Page 1: Table Of Contents

    Care and Cleaning Air Filter Grille & Cabinet Outdoor Coil Consumer Services Control Settings Electrical Requirements Extension Cords Freezing Up Grounding Installation Instructions 8-14 Model Serial Numbers Problem Solver User Maintenance Instructions Back Cover Warranty GE Answer Center 800.626.2000 GE Appliances...

  • Page 2: Help Us Help You

    NEXT, if you are still not pleased, Consumer Affairs in this Use and Care Guide. write all the details—including GE Appliances Appliance Park your phone number—to: This air conditioner must be Louisville, KY 40225 Manager, Consumer Relations...

  • Page 3: Adapter Plug

    Electrical Safety—~PORTANT...PleaSe Read Carefully. How to connect that mates respectively with a TEMPORARY METHOD 230/208-volt perpendicular, electricity (ADAPTER PLUGS NOT tandem or large tandem type wall outlet. These types of outlets are available at most hardware stores. For personal safety, this appliance must be properly grounded.

  • Page 4: Ventilation Control

    Operating Your Air Conditioner Controls -— HI FAN LO COOL LO FAN CLOSE VENT OPEN — — (ON THE GRILLE FRAME ABOVE THE CONTROL PANEL) HI COOL Ventilation Control THERMOSTAT SELECTOR When you move the Ventilation Control to CLOSE, the vent door is closed and only the air inside the Thermostat Control Selector Switch...

  • Page 5: Air Direction

    For quieter operation To adjust air direction For normal cooling Up and down 1. Set the Selector Switch at HI 1. Set the Selector Switch at the LO COOL position. COOL. 2. Set the Thermostat Control at 2. Turn the Thermostat Control to the desired number.

  • Page 6: Care And Cleaning

    Wash the soiled, it may need to be steam filter, cleaner side up, under gently cleaned, a service available through your GE service outlet. accumulated dust and lint. If the Front Grille household detergent in the wash To attach the grille: water.
  • Page 7 Moisture removed from indoor air drains to rear of cabinet where it is picked up by a fan and thrown against the outdoor condenser coil. If you need more help...call, toll free: GE Answer Center 800.626.2000 consumer information service...

  • Page 8: Electrical Requirements

    WINDOW REQUIREMENTS BEFORE YOU BEGIN Standard double-hung window with actual Read these instructions completely and 26” 42”. opening width of carefully. 51\2° Clear vertical opening of 1 minimum from bottom of sash to stool. and ordinances. Install the air conditioner in a window where there will be enough clearance around the cabinet instructions with the consumer.

  • Page 9: Window Installation

    WINDOW INSTALLATION SCREWS FURNISHED (see samples) TOOLS NEEDED Type D Type C Type B Type A Phillips head screwdriver Blade-type screwdriver Sharp knife or razor blade Rule or tape measure Box wrench Level Pencil Qty-6 Qty-2 Qty-3 Type A screw window filler panel Type B...
  • Page 10 WINDOW INSTALLATION (co”t,n”ed) PREPARE CABINET REMOVE FRONTGRILLE See Front Grille section. Top mounting rail Room side + r 1. Remove chassis locking bracket and chassis locking screw with a Phillips head screwdriver. (Save for reuse.) 1. Install top mounting rail onto top of cabinet with 3 Type D screws.
  • Page 11 AWACH wINDowFILLER PANELs. Secure top mounting rail with two Type B screws. 1. Slide left window filler panel into top and bottom mounting rails. 2. Slide retainer panel into window filler panel and attach to cabinet with 2 Type C screws. 3.
  • Page 12 WINDOW INSTALLATION (Cont, n ued) CHECK FOR AIR LEAKS. Seal small openings around cabinet with gum-type Slide chassis into cabinet. (Make sure tubing on sealer, provided. unit is not touching wall case.) 2. Lock chassis into cabinet by reinstalling chassis locking bracket and chassis locking screw removed in Step 2.

  • Page 13: Through-The-Wall Installation

    THROUGH-THE-WALL INSTALLATION – – – — — — THE CABINET MAY BE INSTALLED THROUGH THE WALL IN BOTH EXISTING PREPARE WALL OPENING. BUILDINGS AND NEW CONSTRUCTION. Determine size of opening. Measure width and height of cabinet and add 1 /8” to each dimension. side louvers must project on the oudoor side of the wall.
  • Page 14 THROUGH-THE-WALL INSTALLATION (...,,.”,,) INSTALL CABINETIN WALL (continued). Secure cabinet sides to wooden frame with six 1“ long # 10 wood screws and secure cabinet top Trim to frame with four 1“ long #1 O wood screws. Molding (if desired) Holes for #10 1“...

  • Page 15: User Maintenance Instructions

    With the purchase ofyour new GE appliance, receive the assurance that if 800.626.2000 will In-Home Repair Service Contracts A (;E (onsumer will provide exJJcrt t-cpilir scIwice, a.m. 10 Parts andAccessories own appliances Special Needs... User maintenance instructions contained in this booktet cover proce- dures intended to be performed by any user.
  • Page 16 To know what your legal rights are in your state, consult your local or state consumer affairs office or your state’s Attorney General. Warrantor: General Electric Company If further help is needed concerning this warranty, write: Manager—Consumer Affairs, GE Appliances, Louisville, KY 40225 49-7263 11-91...
