se and Care& Installation Guide
Contents
Adapter Plug
Air Direction
Appliance
Registration
Air Filter
Outdoor (:oil
Consumer Services
Control Settings
Electrical
Requirements
Energy-Saving '1'ips
Extension Cords
Freezing Up
Grounding
Installation
Instructions
Model and Serial Numbers
Problem Solver
Safety Instructions
User
Maintenance
Instructions
Warranty
Back (;over
GE Answer Centera
800.626.2000
Model AW06
GE Appliances
Room Air Conditioner
5
4,5
7
5
8-14
7
2

Advertisement

loading
Need help?

Need help?

Do you have a question about the AMV06 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GE AMV06

Summary of Contents for GE AMV06

  • Page 1 Outdoor (:oil Consumer Services Control Settings Electrical Requirements Energy-Saving ‘1’ips Extension Cords Freezing Up Grounding Installation Instructions 8-14 Model and Serial Numbers Problem Solver Safety Instructions User Maintenance Instructions Warranty Back (;over GE Answer Centera 800.626.2000 Model AW06 GE Appliances...
  • Page 2 NEXT, if you are still not pleased, Consumer Affairs write all the details—including in this Use and Care Guide. GE Appliances your phone number—to: Appliance Park This air conditioner must be Louisville, KY 40225 Manager, Consumer Relations...
  • Page 3 Electrical Read Carefully. How to connect that mates respectively with a TEMPORARY METHOD 230/208-volt perpendicular, electricity (ADAPTER PLUGS NOT tandem or large tandem type wall PERMITTED IN CANADA outlet. These types of outlets are available at most hardware stores. ALIGN LARGE For personal safety, PRONGS/SLOTS this appliance must be...
  • Page 4 Operating Your Air Conditioner Controls HI FAN LO COOL LO FAN OPEN VENT CLOSE (ON THE LOWER RIGHT SIDE SELECTOR THERMOSTAT OF THE DISCHARGE GRILLE) Ventilation Control Thermostat Control Selector Switch When you move the Ventilation When you move the Thermostat turns air conditioner off.
  • Page 5 To adjust air direction For quieter operation For normal cooling Up and down Set the Selector Switch at LO Set the Selector Switch at COOL position. HI COOL. 2. Set the Thermostat Control at 2. Turn the Thermostat Control to UP-AND-DOWN AIR DIRECTION the desired number.
  • Page 6 30 cleaned, a service available right and left corner and carefully days or as often as it needs cleaning. through your GE service outlet. insert the VENT knob between the lower air direction louver and the Front Grille grille frame, and engage two tabs on the grille’s top inside edge with...
  • Page 7 Moisture removed from indoor air drains to rear of cabinet where it is picked up by a fan and thrown against the outdoor condenser coil. If you need more help...call, toll free: GE Answer Center” 800.626.2000 consumer information service...
  • Page 8 INSTALLATION INSTRUCTIONS WINDOW REQUIREMENTS BEFORE YOU BEGIN Standard double-hung window with actual Read these instructions completely and 25“ to 40”. opening width of carefully. Clear vertical opening of 14“ minimum from bottom of sash to stool. and ordinances. Install the air conditioner in a window where there will be enough clearance around the cabinet instructions with the consumer.
  • Page 9 TOOLS NEEDED SCREWS FURNISHED (see samples) Type A Type B Type C Type D Blade-type screwdriver Sharp knife or razor blade Rule or tape measure Pencil Level Box wrench Qty-3 Qty-2 Qty-4 Qty-6 Type A screw window filler panel Sealer (1 oz.) (continued next page)
  • Page 10 PREPARE CABINED See Front Grille section. Room side - PREPARE CHASSIS. 1. Remove chassis locking bracket and chassis locking screw with a Phillips head screwdriver. (Save for reuse.) 1. Install top mounting rail onto top of cabinet with 3 Type D screws. Type D screw Type D screw...
  • Page 11 Secure top mounting rail with two Type B screws 1. Slide left window filler panel into top and bottom mounting rails. 2. Slide retainer panel into window filler panel and attach to cabinet with 2 Type C screws. 3. Repeat for right side. Top mounting rail Window [ filler panel...
  • Page 12 Slide chassis into cabinet. (Make sure tubing on Seal small openings around cabinet with gum-type unit is not touching wall case. ) sealer, provided. 2. Lock chassis into cabinet by reinstalling chassis locking bracket and chassis locking screw removed in Step 2. INSTALL FRONTGRILIE See Front Grille section.

  • Page 13: Through-The-Wall Installation

    THROUGH-THE-WALL INSTALLATION CABINET MAY BE INSTALLED THROUGH THE WALL IN BOTH EXISTING PREPARE WAll OPENING. BUILDINGS AND NEW CONSTRUCTION. Determine size of opening. Measure width and height of cabinet and add 1/8” to each dimension. Any side louvers must project on the oudoor side of the wall.
  • Page 14 THROUGH-THE-WALL INSTALLATION (...,,.”,,, Line Brick Veneer — Secure cabinet sides to wooden frame with six ---- 1“ long #1 O wood screws and secure cabinet top Trim Lintel Angle to frame with four 1“ long #1 O wood screws. Molding (if desired) Holes for #10 1“...
  • Page 15 With the purchase ofyour new GE appliance, receive the assurance that if you ever need information or assistance from GE, we’ll be there. All you have to do is call–toll-free! Whatever appliance, (;k; Answer (;entel”’” will be answered pr(mlptly and...
  • Page 16 To know what your legal rights are in your state, consult your local or state consumer affairs office or your state’s Attorney General. Warrantor: General Electric Company If further help is needed concerning this warranty, write: Manager—Consumer Affairs, GE Appliances, Louisville, KY 40225 49-7259 11-91...
