Use and Care & Installation Guide
Contents
Adapter Plug
Air Direction
Air Filter
Care and (Jleaning
Consumer Services
Electrical Requirements
Energy Saver Stitch
Energy-Saving Tips
Extension {lords
Freezing Up
Installation Instructions
Model
and
Serial
Numbers
outdoor (;oil
Problem Solver
Safety Instructions
User Maintenance Instructions 6
Warranty
Back ~;over
GE Answer Centerm
800.626.2000
Model AMD08
GE Appliances
Room Air Conditioner
4,5
15
4
7
5
2,6
7
2
Advertisement
Table of Contents
Related Manuals for GE AMD08
Summary of Contents for GE AMD08
-
Page 1: Room Air Conditioner
Care and (Jleaning Consumer Services Electrical Requirements Energy Saver Stitch Energy-Saving Tips Extension {lords Freezing Up Installation Instructions Model Serial Numbers outdoor (;oil Problem Solver Safety Instructions User Maintenance Instructions 6 Warranty Back ~;over GE Answer Centerm 800.626.2000 Model AMD08 GE Appliances... -
Page 2: Important Safety
NEXT, if you are still not pleased, in this Use and Care Guide. write all the details—including Consumer Affairs your phone number—to: This air conditioner must be GE Appliances properly installed in accordance Appliance Park Manager, Consumer Relations Louisville, KY 40225 with the Installation Instructions GE Appliances before it is used. -
Page 3: How To Connect
Electrical Read Carefully. How to connect that mates respectively with a TEMPORARY METHOD 230/208-volt perpendicular, electricity (ADAPTER PLUGS NOT tandem or large tandem type wall outlet. These types of outlets are available at most hardware stores. For personal safety, this appliance must be properly grounded. -
Page 4: Ventilation Control
Operating Your Air Conditioner Controls THERMOSTAT SELECTOR LOW COOL OPEN VENT CLOSE THE LOWER RIGHT SIDE OF THE DISCHARGE GRILLE) Ventilation Control Thermostat Control Selector Switch When you move the Ventilation When yOLI move the Thermostat OFF turns air conditioner off. Control to CLOSE, the vent door Control to the desired setting, the FAN ONLY permits fan speed... - Page 5 For quieter operation To adjust air direction For normal cooling 1. Set the Selector Switch at LOW Up and down 1. Set the Selector Switch at HIGH COOL position. COOL. 2. Turn the Thermostat Control to 2. Set the Thermostat Control at the desired number.
-
Page 6: Air Filter
Wash the steam cleaned, a service available filter, cleaner side up, under gently through your GE service outlet. Air Direction Louvers flowing water to wash out accumulated dust and lint. If the... - Page 7 Moisture removed from indoor air drains to rear of cabinet where it is picked up by a fan and thrown against the outdoor condenser coil. If you need more help...call, toll free: GE Answer Center’’” 800.626.2000 consumer information service...
-
Page 8: Installation Instructions
INSTALLATION INSTRUCTIONS BEFORE YOU BEGIN Standard double-hung window with actual Read these instructions completely and 25” 40”. opening width of carefully. minimum from Clear vertical opening of 14“ bottom of sash to stool. and ordinances. Install the air conditioner in a window where there will be enough clearance around the cabinet instructions with the consumer. -
Page 9: Window Installation
WINDOW INSTALLATION TOOLS NEEDED SCREWS FURNISHED (see samples) Type A Type B Type C Type D Blade-type screwdriver Sharp knife or razor blade Rule or tape measure Pencil Level Box wrench Qty-3 Qty-2 Qty-4 Qty-6 Type A screw gasket Type screw Type A Left ~... - Page 10 WINDOW INSTALLATION (cont,nue~, PREPARE eABINEr See Front Grille section. Room side + PREPARE CHASSIS. 1. Remove chass;s locking bracket and chass;s locking screw with a Phillips head screwdriver. Type D screw (Save for reuse.) 1. Install top mounting rail onto top of cabinet with 3 Type D screws.
- Page 11 Secure top mounting rail with two Type B screws. 1. Slide left window filler panel into top and bottom mounting rails. Slide retainer panel into window filler panel and attach to cabinet with 2 Type C screws. 3. Repeat for right side. Top mounting rail Window —...
- Page 12 WINDOW INSTALLATION (continued) CHECK FOR AIR LEAKS. Slide chassis into cabinet. (Make sure tubing on Seal small openings around cabinet with gum-type unit is not touching wall case.) sealer, provided. 2. Lock chassis into cabinet by reinstalling chassis locking bracket and chassis locking screw removed in Step 2.
-
Page 13: Tools Required
THROUGH-THE-WALL INSTALLATION THE CABINET BE INSTALLED THROUGH THE WALL IN BOTH EXISTING PREPARE WALL OPENING. BUILDINGS CONSTRUCTION. Measure width and height of cabinet and add 1/8” to each dimension. Any side louvers must project on the oudoor — the wall. side of The room side of the cabinet must project into HEIGHT... - Page 14 THROUGH-THE-WALL INSTALLATION (co”t,nue~) Secure cabinet sides to wooden frame with six 1“ long #1 O wood screws and secure cabinet top Trim to frame with four 1“ long #1 O wood screws. Molding (if desired) Holes for #10 1“ Long INSIDE Wood Screws Drill holes ;n cabinet s;des and top, ;f necessary for...
- Page 15 With the purchase of your new GE appliance, receive the assurance that if you ever need information or assistance from GE, we’ll be there. All you have to do is call–toll-free! will he :mswereci promptly CO Llr(eoLISly.” ~~tl(] YOU Ciln C:ill 2U1J’...
