Table of Contents
Safety Notice
Hardware Identifier
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
MD-440
Retain This
Manual for
Reference
07-23-05
OWNER'S
MANUAL
MARCY DIAMOND ELITE
UTILITY BENCH
Escalade International Limited
Pleasant Road, Penllergaer, Swansea. SA4 9GE
Tel: 00 44 1792 222 550 Fax 00 44 1792 895 781
www.escaladesports.co.uk
info@escaladesports.co.uk
MD-440
Advertisement
Related Manuals for Marcy MD-440
Summary of Contents for Marcy MD-440
- Page 1 NOTE: Please read all instructions carefully before using this product MARCY DIAMOND ELITE Table of Contents UTILITY BENCH Safety Notice MD-440 Hardware Identifier Assembly Instruction Parts List Warranty Ordering Parts Model MD-440 Retain This Manual for Reference 07-23-05 Escalade International Limited OWNER'S Pleasant Road, Penllergaer, Swansea.
-
Page 2: Table Of Contents
ORDERING PARTS..................BEFORE YOU BEGIN Thank you for selecting the MARCY DIAMOND ELITE UTILITY BENCH MD-440 by IMPEX FITNESS PRODUCTS. For your safety and benefit, read this manual carefully before using the machine. As the distributor, we are committed to provide you complete customer satisfaction. -
Page 3: Important Safety Notices
PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. MARCY ASSUMES NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT. CARE AND MAINTENANCE 1. - Page 4 WARNING LABEL...
-
Page 5: Hardware Pack
HARDWARE PACK... - Page 6 HARDWARE PACK...
-
Page 7: Assembly Instructions
ASSEMBLY INSTRUCTION Tools Required Assembling the Machine: Two Adjustable Wrenches and Allen Wrenches. NOTE: It is strongly recommended this machine be assembled by two or more people to avoid possible injury. STEP 1 (See Diagram 1) A.) Attach the Main Frame (#1) onto the Front & Rear Stabilizers (#2 & 6). Secure each end with two M10 x ¾”... - Page 8 STEP 2 (See Diagram 2) A.) Attach the Backrest Supports (#3) to the pivot on the Main Frame (#1). Secure it with one M12 x 5 ¾” Allen Bolt (#31), two Ø1” Washers (#38), and one M12 Aircraft Nut (#36). Do not over tighten the Nut and Bolt, make sure the Backrest Supports are able to swivel.
- Page 9 STEP 3 (See Diagram 3) A.) Attach the Leg Developer (#5) to the open bracket on the Main Frame (#1). Secure it with one Axle (#42), two M10 x 5/8” Allen Bolts (#30), and two Ø ¾” Washers (#39). Do not over tighten the Bolts, make sure the Leg Developer is able to swivel.
- Page 10 STEP 4 (See Diagram 4) A.) Attach the Arm Curl Pad (#13) to the Arm Curl Stand (#7). Secure it with two M8 x ¾” Allen Bolts (#33) and Ø 5/8” Washers (#40). B.) Insert the Arm Curl Stand into the front opening on the Main Frame. Use a Lock Knob (#16) to secure the Stand at desired height.
-
Page 12: Parts List
PARTS LIST KEY NO. DESCRIPTION Q’ty Main Frame Front Stabilizer Backrest Support Backrest Incline Support Leg Developer Rear Stabilizer Arm Curl Stand Curl Bar Foam Tube U-shaped Pin Seat Backrest Board Arm Curl Pad Olympic Sleeve Spring Clip Lock Knob 2 3/8”... -
Page 13: Warranty
LIMITED WARRANTY Escalade warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of two years on the frame and one year on all other parts and components from the date of purchase. This warranty extends only to the original purchaser. - Page 14 CARE AND MAINTENANCE Inspect and tighten all parts before using the machine. The machine can be cleaned using a damp cloth and mild non- abrasive detergent. DO NOT use solvents. Failure to examine the BENCH regularly may affect the safety level of the equipment.
