TVD-3203 (1.3MPX IP outdoor dome, 2.8-12mm,
NTSC)
TVD-1204 (3MPX IP outdoor dome, 2.8-12mm, PAL)
TVD-3204 (3MPX IP outdoor dome, 2.8-12mm, NTSC)
TVD-1205 (3MPX IP outdoor dome, 8-32mm, PAL)
TVD-3205 (3MPX IP outdoor dome, 8-32mm, NTSC)
Installation
This section provides information on how to install the
cameras.
Installation environment
When installing your product, consider these factors:
•
Electrical: Install electrical wiring carefully. It should be
done by qualified service personnel. Always use a proper
PoE switch or a 12 VDC UL listed Class 2 or CE certified
power supply to power the camera. Do not overload the
power cord or adapter.
•
Ventilation: Ensure that the location planned for the
installation of the camera is well ventilated.
•
Temperature: Do not operate the camera beyond the
specified temperature, humidity or power source ratings.
The operating temperature of the camera without heater
is between -30 to +60°C (-22 to 140°F). Humidity is below
90%. For the outdoor cameras have built-in heaters, the
operating temperature range is -40°C to 60°C(-40°F
to140°F)
•
Moisture: Do not expose the camera to rain or moisture,
or try to operate it in wet areas. Turn the power off
Installation Guide
3
