Page 1: Installation Guide
TruVision IR Turret Camera TVT-2202/TVT-4202 Installation Guide P/N 1072921 • REV A • ISS 10FEB15... -
Page 3: Table Of Contents
Contents Product overview 2 Camera description 3 Installation 4 Programming 6 Specifications 7 Setup menu 8 Regulatory information 9 Installation Guide... -
Page 4: Product Overview
Product overview This is the TruVision IR Turret Camera Installation Guide for models TVT-2202/TVT-4202. This guide describes a standard installation. Package contents: Camera with power 4 M4 screws (4 x and video output 25 mm) and 4 dry cables wall anchors (Ø7.5 x 24.5 mm) for wall... -
Page 5: Camera Description
• WEEE and Battery Installation Guide Disposal Camera description Camera Power cable Enclosure Lock screw Mounting base Zoom and focus Video cable Installation Guide... -
Page 6: Installation
Installation To install the camera: Using the template, place it level against the mounting surface and mark the position of the mounting holes. Following all local codes, drill and prepare the mounting holes. Loosen the lock screw and release the clip plate to release the camera from the mounting base. - Page 7 Clip Plate Fix the mounting base to the mounting surface. Route the cables to the cable hole and connect the corresponding cables. Connect a 75 ohm coaxial video cable to the video cable, and connect a 12 VDC power supply to the power cable.. Adjust the camera according to the figure below to get an optimum angle.
-
Page 8: Programming
Secure the camera to the mounting base by tightening the lock screw. Clip Plate Use a screwdriver to adjust the ZOOM screw and the FOCUS screw until you get the optimum image. Programming Once the camera hardware has been installed, the camera can then be configured by using a TVS- C200 controller (purchase separately). -
Page 9: Specifications
The Setup menu provides access to the camera configuration options. See page 8 for an overview of the menu. Please refer to the configuration manual for further information on setting up the camera. Program the camera by attaching a standard video monitor to the system. -
Page 10: Setup Menu
Setup menu Installation Guide... -
Page 11: Regulatory Information
Regulatory information Copyright: © 2015 United Technologies Corporation. Interlogix is part of UTC Building & Industrial Systems, a unit of United Technologies Corporation. All rights reserved. Trademarks and patents: Trade names used in this document may be trademarks or registered trademarks of the manufacturers or vendors of the respective products. - Page 12 For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info. Contact information: For contact information, see www.interlogix.com or www.utcfssecurityproducts.eu Installation Guide...
