SAFETY AND WARNINGS Before you install the appliance, please make sure that WARNING! Electrical Shock Hazard the local distribution conditions (nature of gas and pressure) and the adjustment of the ● Before carrying out any work on the electrical section of the appliance, it appliance are compatible.
GAS RATE SUMMARY All appliances are factory set for either Natural Gas or LPG. Check the ‘Gas type’ sticker on the base of the appliance. SEMI-RAPID SEMI-RAPID DUAL WOK RAPID CG905DW BURNER SEMI-RAPID RAPID DUAL WOK GAS TYPE Jet size...
Page 4
PRODUCT & CABINETRY DIMENSIONS Note: Gas inlet connection is located in the rear right corner. FRONT REAR SIDE PRODUCT DIMENSIONS Overall height of product (excluding burners, dials and pan supports) Overall width of product Overall depth of product Height of chassis (below top of counter) Width of chassis Depth of chassis...
CLEARANCE DIMENSIONS FRONT CLEARANCE DIMENSIONS Minimum clearance from left edge of cutout to nearest combustible surface Minimum clearance from right edge of cutout to nearest combustible surface Minimum clearance from rear edge of cutout to: Nearest combustible surface Nearest non-combustible surface Minimum height of non-combustible material when used on adjacent walls Minimum clearance from cooktop surface to: Rangehood...
Page 6
FLUSH MOUNTING INSTALLATION (OPTIONAL) IMPORTANT! Refer to ‘When you you install the appliance’ in the Safety and Warnings section before you flush mount this appliance. Note: Electrical connection is made at the right rear FRONT SIDE REAR PRODUCT AND CABINETRY DIMENSIONS Overall height of product (excluding burners, dials and pan supports) Overall width of product...
Page 7
FLUSH MOUNTING INSTALLATION (OPTIONAL) ROUTER THE BENCHTOP TO THE SPECIFIED DEPTH FIT THE CLAMPING BRACKETS MASK OFF THE AREA TO BE SILICONED 3/4” - 2” (19 mm - 50 mm) REPEAT ON ALL THE OTHER SIDES (Total 6 brackets) 3 mm 5 mm IF REMOVING PRODUCT, CUT AROUND THE SILICONE...
Page 8
DISCARD PACKAGING FIT THE NIPPLE AND WASHER Model may vary from illustrations shown IMPORTANT! - Use gas tape to seal the connection Nipple (1/2” BSPT thread) Nipple (½” NPT thread) Recycle responsibly LOWER GENTLY INTO THE CUTOUT...
SECURE TO COUNTERTOP WITH BRACKETS BASED ON THE COUNTERTOP THICKNESS Place the cooktop into the cutout and tighten it with the supplied clamps. These will cope with the countertop thicknesses 19 - 50 mm when used in the two REPEAT ON ALL THE OTHER SIDES orientations shown.
LEAK TESTING Leak testing of the appliance shall be conducted according to the manufacturer’s instructions. ● The appliance and its individual shut-off valve must be disconnected from the gas supply piping system during ● any pressure testing of that system in excess of 3.5kPa. Maximum inlet gas supply pressure 5 kPa ●...
INSTALLATION INSTRUCTIONS AFFIX DUPLICATE DATA LABEL SOMEWHERE FIT PAN SUPPORTS ACCESSIBLE & PLUG COOKTOP IN Duplicate data label TEST OPERATION To check that the ignition system operates correctly, light each burner by itself, then all burners in combination. ● Check for a well-defined blue flame without any yellow tipping. ●...
FINAL CHECKLIST TO BE COMPLETED BY THE INSTALLER Have you installed the clamping brackets? Have you verified that the type of model (factory-set for NG or LP) matches the type of gas at the site of installation? Have you sealed all connections with gas tape? Have you leak-tested all connections? Is the cooktop set to the correct working pressure? Have you affixed the supplied duplicate data plate label on an adjacent...
