Page 1: User Guide
Installation instructions Gas cooktops User guide CG604DW & CG905DW models CG604DW CG905DW HK SG... -
Page 3: Table Of Contents
Contents Safety and warnings Installation instructions Introduction Using your cooktop Cooking guidelines and cookware Care and cleaning Troubleshooting Warranty and service Important! SAVE THESE INSTRUCTIONS The models shown in this document may not be available in all markets and are subject to change at any time. -
Page 4: Safety And Warnings
Safety and warnings Installation WARNING! Electrical Shock Hazard Before carrying out any work on the electrical section of the appliance, it must be disconnected from the mains electricity supply. Connection to a good earth wiring system is absolutely essential and mandatory. -
Page 5: Important Safety Instructions
Safety and warnings Important safety instructions! Installation Read these instructions carefully before installing or using this product. Please make this information available to the person responsible for installing the product as it could reduce your installation costs. This appliance shall only be installed and serviced by an authorised person. Incorrect installation, for which the manufacturer accepts no responsibility, may cause personal injury or damage and could invalidate any warranty or liability claims. - Page 6 Safety and warnings Operation WARNING! Hot Surface Hazard This appliance becomes hot during use. Do not touch the cooktop components, burners, trivets, pan supports or the base when hot. Before cleaning, turn the burners off and make sure the whole cooktop is cool. Failure to follow this advice may result in serious injury.
- Page 7 Safety and warnings Important safety instructions! Operation Keep children away from the cooktop when it is in use. Household appliances are not intended to be played with by children. Children, or persons with a disability which limits their ability to use the appliance, should have a responsible person to instruct them in its use.
-
Page 8: Installation Instructions
Installation instructions Cooktop and cutout dimensions (mm) overall width of cooktop overall depth of cooktop height of chassis below top of bench width of chassis depth of chassis overall width of cutout overall depth of cutout corner radius of cutout max. - Page 9 Installation instructions Clearances (mm) minimum clearance from left edge of cutout to: nearest combustible surface minimum clearance from right edge of cutout to: nearest combustible surface minimum clearance from rear edge of cutout to: nearest combustible surface nearest non-combustible surface minimum height of non-combustible material when used on adjacent walls minimum clearance from pan supports to:...
- Page 10 Installation instructions Before you start Before starting to install the cooktop, make sure that: the cooktop has not been damaged during transport. In case of doubt after unpacking and checking it, contact the retailer the local distribution conditions (nature of gas and pressure) and the adjustment of the cooktop (as detailed on the appliance data label and in the ‘Gas rate and injector size table’...
- Page 11 Installation instructions Fastening the cooktop to the bench This cooktop is suppled with fastening brackets (and screws) that will cope with a bench thickness of 20-50 mm. For benches thicker than 50 mm, recess the underside to a thickness of 20-50 mm. 50 mm recessed to 20 mm...
- Page 12 Installation instructions Special requirements for CG604 and CG905DWFC models Gas connection to these cooktops MUST use the elbow supplied. The regulator will not seal if installed without it. Ensure the fibre washer (supplied) is located between the elbow (supplied) and cooktop gas inlet (Fig.2).
- Page 13 Installation instructions Leak-testing and flame-testing the cooktop Important! The operation of the cooktop, including the ignition system, must be tested before installation is complete. If, after following the instructions below, satisfactory performance cannot be obtained, contact the local gas authority or your local Authorised Repairer for advice and assistance. Checking the connections for leaks After installation and making all connections, check thoroughly for possible leaks and make sure all connections are gas-tight.
- Page 14 Installation instructions Converting to a different gas type Important! Gas conversion may only be carried out by a suitably qualified person. To convert from one gas type to another, you need to replace the injectors and adjust the minimum burner setting. To replace the injectors, you will need a 7 mm box spanner (not supplied).
- Page 15 Installation instructions Adjusting the minimum burner setting This has been adjusted at the factory for Town Gas but may need adjusting for local conditions. When converting to LPG, the minimum setting MUST be re-adjusted for each burner. To adjust the minimum setting, you will need a Ø 2.5 x 45 mm screwdriver. Light the burner and set the control dial to its minimum.
- Page 16 Installation instructions Gas rate and injector size table CG604DWFCX & CG905DWFCX Gas Cooktop This product has been set either for Singapore LPG or Town Gas (this is marked on the product) but the minimum setting may need adjusting for a particular installation. The gas rates and injectors are noted in the table below;...
- Page 17 Installation instructions Final checklist TO BE COMPLETED BY THE INSTALLER Have you securely fastened the cooktop to the bench with the supplied brackets? Have you used the supplied elbow and fibre washer to connect the gas to the inlet on the cooktop? Have you leak-tested all connections? Are the injector sizes correct for the gas type?
-
Page 18: Introduction
Introduction About your new cooktop Thank you for buying a Fisher & Paykel gas cooktop. Once it is installed and ready to use, you will want to know everything about it to make sure you get excellent results right from the start. We recommend you read the whole guide before using your new cooktop, for both safety and cooking success. -
Page 19: Using Your Cooktop
Using your cooktop Control dials The dials control the flow of gas through the valve. OFF (closed valve) NEVER cook or leave the dial between HIGH and O (OFF) HIGH Burner indicator Fig. 7 Control dial for CG604 & CG905DWFC models Using the burners Models with flame failure protection Press the selected burner’s dial down gently and... - Page 20 Using your cooktop If a burner does not light Turn the control dial to O (OFF) and wait at least 1 minute before trying again. This is to allow the gas to disperse. If after trying again the burner still does not light, check that: the cooktop is plugged in and the power supply is switched on there is no power failure in your home or neighborhood the gas is turned on...
- Page 21 Using your cooktop If there is a power failure You can still use your cooktop. Light the burners by holding a match close to the side of the burner and turning the control dial to HIGH. Wait until the flame is burning evenly before adjusting. If the flame is accidentally extinguished The flame failure protection will automatically cut the gas supply to the burner off.
-
Page 22: Cooking Guidelines And Cookware
Cooking guidelines and cookware Cooking guidelines Important! Never leave the cooktop unattended when in use. Boilover causes smoking and greasy spills that may ignite. Take care when deep-frying: oil or fat can overheat very quickly, particularly on a high setting. Start cooking on a high setting. - Page 23 Cooking guidelines and cookware Using a wok – models with wok burner Use your wok only on a wok burner. A wok must always be used with the wok stand supplied. See Fig.13. Make sure the wok does not push any other pans aside. This could make them unstable, or deflect heat onto nearby walls or the benchtop.
-
Page 24: Care And Cleaning
Care and cleaning Important! Before any cleaning or maintenance, always: turn all burners off switch the power to the cooktop off at the wall make sure that the cooktop and its parts are a safe temperature to touch. General advice Clean the cooktop regularly—do not let stains become burnt on. - Page 25 Care and cleaning How? Important! What? How often? Remove the parts that you wish to clean. Make sure you keep the Burner See the Figs. following for illustrations of notches of the flame spreaders parts, pan supports, removable burner parts. clear.
- Page 26 Care and cleaning Replacing the pan supports correctly CG905 models The wok support goes in the centre, over the wok burner. The other two pan supports are interchangeable, but need to be rotated to match the rounded corners of the cooktop base. Fig.14 Correct positioning of pan supports (CG905 models) CG604 models The pan supports are interchangeable, but they can only be placed as shown and need to be...
- Page 27 Care and cleaning Replacing the burner parts correctly Semi-rapid, rapid, and auxiliary burners Flame spreader Probe (some models only) Fig.16 Correct positioning of semi-rapid, rapid, Ignitor and auxiliary burner parts Wok burner with cast iron cap and ring Fit the flame spreader to the housing as shown by the arrow in Fig.17 following. Make sure the burner is not able to rotate.
-
Page 28: Troubleshooting
Troubleshooting Problem Possible solutions A burner does not light. Check that the power to the cooktop is switched on at the wall and there is no power failure. Check the gas supply valve is turned on and the supply to the house is working. -
Page 29: Warranty And Service
Warranty and service Before you call for service or assistance ... Check the things you can do yourself. Refer to the installation instructions and your user guide and check that: Your product is correctly installed. You are familiar with its normal operation. If after checking these points you still need assistance, please refer to the Service &... - Page 37 900mm 800-850mm 250mm...
- Page 38 220-240V 50Hz 900mm...
- Page 39 20-50mm 50mm 20-50mm 50mm 20mm 50mm 27.5 mBar 11" W.C...
- Page 40 CG604 CG905DWFC ¼ 800-850mm 250mm Rp ½" ISO 7-1 " BSP CG604 CG905DWFC...
- Page 41 CG604 CG905DWFC...
- Page 42 70=0.70mm...
- Page 43 Ø2.5 x 45mm...
- Page 44 CG604DWFCX CG905DWFCX 1000 1750 3600 1500 — — — — 1/100mm —...
- Page 46 CG604DWFC CG905DWFC...
- Page 47 HIGH HIGH 7 CG604 CG905DWFC HIGH HIGH HIGH...
- Page 49 HIGH...
- Page 50 12cm — 18cm 26cm 18cm 26cm — 45cm 12cm —...
- Page 53 14-18...
- Page 54 CG905 CG604...
- Page 56 HIGH...
- Page 57 www.fisherpaykel.com Fisher & Paykel Ltd...
- Page 60 www.fi sherpaykel.com Copyright © Fisher & Paykel 2013. The product specifications in this booklet apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time. You should therefore check with your Dealer to ensure this booklet correctly describes the product currently available.
