DOOR/WINDOW SENSORS

The DXS-31 and DXS-32 sensors monitor doors and windows.
They send radio signals to the Console. One type of signal is sent
when the door or window is opened, and a different type of signal
is sent when the door or window is closed. If the Console is armed,
a sensor can trigger the Console's burglary siren when its door or
window is opened. Both sensors are supervised, send hourly status
reports, and monitor their battery condition.
DXS-31

WIRELESS KEYPAD

The DXS-10 wireless keypad is used to operate the Console
remotely. It can be placed in a convenient spot so the user doesn't
have to go to the Console to control the system. The wireless
keypad can also trigger the emergency or fi re siren and actuate
the Automation Output. Pressing
Beeps corresponding to the current operating
mode. The DXS-10 is supervised, it sends
hourly status reports and monitors its battery
condition. IMPORTANT:
emergency use only. Not for use as a UL
Listed Medical Alert System.

SMOKE DETECTOR

The DXS-73 is a high quality smoke detector with a built-in radio
transmitter. As soon as smoke is detected, the unit will sound its local
noisemaker. Then, 20 seconds after the local noisemaker sounds,
the transmitter sends an alarm signal to the Console. The alarm
signal will be repeated every 20 seconds as long
as smoke is still present. A restoral signal will be
sent when the smoke detection chamber clears.
The DXS-73 is supervised, it sends hourly status
reports, and monitors its battery condition.
☞
NOTE: A Model DXS-73 Smoke Detector is required to
create a UL Listed smoke alarm system. See Page 13 for
details on adding a smoke detector sensor to the system.

REMOTE CONTROLS

The DXT-41, DXT-61 single-button and DXT-23, DXT-42 multi-button
remote controls can be used to remotely arm and disarm the Console.
The DXT-42's left button will arm and the right button will disarm
the Console. Pressing both buttons simultaneously will trigger the
emergency siren. Alternately the Console can be programmed to
respond to the DXT-42 by arming and disarming with the left button,
and activating the automation output with the right button. These
transmitters can also be programmed to activate various other
Console zones. These transmitters are not supervised.
DXT-41

GLASS BREAK DETECTOR

The DXS-91 is a glass break detector with an audio sound
discriminator and a built-in radio transmitter. The unit "listens" for the
sound of breaking glass. When glass breakage is detected, the unit
sends an alarm signal to the Console. The DXS-91 is supervised, it
sends hourly status reports and monitors its battery condition.
will cause the Console to sound
For personal
DXT-61‡ DXT-42
DXS-91‡

PANIC BUTTONS

The DXT-21, DXS-21 single-button, and DXT-23, DXS-23 two-button
transmitters can be used as portable "panic buttons". Pressing the
front or top button on the DXT-21 or DXS-21 at any time will trigger
the emergency siren. Pressing both front buttons simultaneously
on the DXT-23 or DXS-23 at any time will trigger the emergency
siren. These transmitters can be programmed to activate various
other system functions. The DXT-21 and DXT-23 transmitters are not
supervised. The DXS-21 and DXS-23 transmitters are supervised.
The DXS-62A transmitter is typically used as a portable "panic
button". Pressing the button on a DXS-62A at any time will trigger
the emergency siren. This transmitter can send hourly status signals
DXS-32
and low battery signals if the battery is low.
DXT-21‡

BILL TRAP

The DXS-81 bill trap can be used with the Console in non-UL small
commercial hold-up installations. The unit is concealed in a cash
drawer under a stack of currency, with a single "bait" bill secured in
its money clip. During a hold-up, the cashier removes the stack of
currency along with the "bait" bill. When a "bait" bill is removed, the
transmitter sends a signal to the Console. Four additional signals
DXS-10
are sent within the fi rst minute after the "bait" bill
is removed. When the "bait" bill is replaced, a
restore signal is sent. The DXS-81 is supervised,
it can send hourly status reports (optional) and
monitors its battery condition.

PASSIVE INFRARED MOTION DETECTOR

The DXS-54 is a passive infrared (PIR) motion detector with a built-in
radio transmitter. The PIR detects motion in its detection pattern by
measuring the infrared emission levels of objects that it "sees". If
the infrared levels change quickly, as when a person moves across
DXS-73
the detection pattern, the PIR will recognize the
change as an intrusion and send an alarm signal to
the Console. An alarm will be triggered if the system
is in the Away Mode. The DXS-54 is supervised, it
sends hourly status reports and monitors its battery
condition.
‡ NOTE: These accessories not listed by UL
DXS-21‡ DXT-23‡ DXS-23‡ DXS-62A
DXS-81‡
DXS-54
3
