Printed: 08.07.2013 | Doc-Nr: PUB / 5129884 / 000 / 01
C 4/36,
C 4/36-ACS
Bedienungsanleitung
Operating instructions
Használati utasítás
Návod k obsluze
Návod na obsluhu
Instrukcja obsługi
Upute za uporabu
Navodila za uporabo
Ръководство за обслужване
Инструкция по зксплуатации
Пайдалану бойынша басшылы қ
de
en
hu
cs
sk
pl
hr
sl
bg
ru
kk
ja
ko
zh
cn
ar
Advertisement
Table of Contents
Related Manuals for Hilti C 4/36
Summary of Contents for Hilti C 4/36
- Page 1 C 4/36, C 4/36-ACS Bedienungsanleitung Operating instructions Használati utasítás Návod k obsluze Návod na obsluhu Instrukcja obsługi Upute za uporabu Navodila za uporabo Ръководство за обслужване Инструкция по зксплуатации Пайдалану бойынша басшылы қ Printed: 08.07.2013 | Doc-Nr: PUB / 5129884 / 000 / 01...
- Page 2 C 4/36-ACS, C 4/36 C 4/36-ACS, TPS Company Card TPS-Theft Protection System TPS-K Printed: 08.07.2013 | Doc-Nr: PUB / 5129884 / 000 / 01...
- Page 3 C 4/36-ACS, C 4/36 LED4 LED2 LED3 LED1 C 4/36-ACS, TPS Printed: 08.07.2013 | Doc-Nr: PUB / 5129884 / 000 / 01...
-
Page 4: Table Of Contents
In these operating instructions, the designation Always keep these operating in- "the appliance" always refers to the C 4/36 or structions together with the appli- C 4/36‑ACS charger. ance. -
Page 5: Description
2 Description 2.1 Use of the product as directed The appliance is designed to charge Hilti Li-ion batteries with a rated voltage of 4 to 36 volts. The working environment may be as follows: construction site, workshop, renovation, conversion or new construction. -
Page 6: Technical Data
LEDs blink Charge status in % LED 1 < 25 % 3 Technical data Right of technical changes reserved. appliance C 4/36 C 4/36‑ACS Cooling Cooling by convection Active cooling AC supply voltage 100…127 V / 220…240 V 100…127 V / 220…240 V Mains frequency 50…60 Hz... -
Page 7: Safety Instructions
THESE INSTRUCTIONS! 4.1.4 Battery charger use and care 4.1.1 Work area safety a) Use the charger only to charge the Hilti batteries approved for use with this char- a) Keep work area clean and well lit. ger. -
Page 8: Before Use
(including children) with re- electric shock. Dirty or dusty appliances duced physical, sensory or mental cap- should thus be checked at a Hilti service abilities, or lack of experience and know- center at regular intervals, especially if used... -
Page 9: Operation
In order to achieve maximum battery life, stop discharging the battery as soon as a significant Depending on the type of Hilti battery, push or drop in performance is noticed. slide the battery into the interface provided. - Page 10 Hilti Service for repair. 6.4 LED display on the battery 5 6.5 TPS theft protection system (optional) with the C 4/36‑ACS TPS charger 6 6.4.1 Charging status display NOTE When the green LED on the charger lights con-...
- Page 11 3. Hold the Company Card against the lock 5. Depending on the type of Hilti battery, symbol on the appliance within one minute. push or slide the battery into the interface The yellow TPS LED blinks rapidly (pro- provided.
-
Page 12: Care And Maintenance
Never operate the appliance when the ventil- the controls do not function correctly. If neces- ation slots are blocked. Clean the ventilation sary, the appliance should be repaired by Hilti slots carefully using a dry brush. Do not per- Service. -
Page 13: Manufacturer's Warranty - Tools
Dispose of the batteries in accordance with national regulations or return them to Hilti. Most of the materials from which Hilti tools or appliances are manufactured can be recycled. The materials must be correctly separated before they can be recycled. In many countries, Hilti has already made arrangements for taking back old tools and appliances for recycling. -
Page 14: Ec Declaration Of Conformity (Original)
10 EC declaration of conformity (original) Technical documentation filed at: Designation: Charger Type: C 4/36 / C 4/36‑ACS Hilti Entwicklungsgesellschaft mbH Zulassung Elektrowerkzeuge Year of design: 2006 Hiltistrasse 6 We declare, on our sole responsibility, that this 86916 Kaufering product complies with the following directives... - Page 15 Tel.: +423 / 234 21 11 Fax:+423 / 234 29 65 www.hilti.com Hilti = registered trademark of Hilti Corp., Schaan W 3159 | 0713 | 00-Pos. 8 | 1 Printed in Liechtenstein © 2013 Right of technical and programme changes reserved S. E. & O 272433 / A3 Printed: 08.07.2013 | Doc-Nr: PUB / 5129884 / 000 / 01...
