HARDWARE INSTALLATION
7
2.3 CPU Installation
So far you have familiarized yourself with the handling precautions, checked you have all of
the necessary hardware for building your system, inspected the motherboard package contents
and looked at the layout of the motherboard. This chapter will take you step by step through
the process of installing the different hardware devices onto it.
Caution!
1. Remember to always make sure the system power is off before installing or removing
any devices.
2. Don't forget the static electricity precautions.
3. Be careful ! Inserting hardware onto your motherboard incorrectly can damage it.
The motherboard has a ZIF Socket A which houses the CPU. A fan is necessary for the CPU
to prevent overheating. If there is no fan on it, please purchase one before you turn on your
system.
Caution!
This kind of CPU will generate tremendous heat while opearting,make sure install the
CPU fan and enough heat-dissipation grease before power up the computer.Never run
the processor without the heatsink properly and firmly attached.
PERMANENT DAMAGE WILL RESULT!
Please follow the steps below to install the CPU:
Step 1:
To install the CPU, first turn off your system and remove its cover. Locate the ZIF socket and
open it by first pulling the lever sideways away from the socket then upwards to a 90-degree
right angle. Insert the CPU in the correct direction, smear the heat dissipation grease over the
CPU die,then put a CPU fan to cover the face of the CPU. With the added weight of the CPU fan,
no force is required to insert the CPU. Once completely inserted, close the socket's lever while
holding down the CPU.
